409 Stainless Steel Plate and Sheet
Grade 409 is a thermostable ferritic stainless steel with better oxidation and corrosion resistance than carbon steel. This titanium stabilised sheet was developed for automotive exhaust systems, and its formability,…
What This Product Is For
Grade 409 is a thermostable ferritic stainless steel with better oxidation and corrosion resistance than carbon steel. This titanium stabilised sheet was developed for automotive exhaust systems, and its formability, weldability and corrosion resistance carry it into other applications. It is supplied cold rolled from 0.3 to 3 mm and hot rolled from 3 to 120 mm, in widths to 2000 mm and lengths to 12000 mm.
Key Benefits
- Titanium stabilisation keeps the weld zone sound, which matters on a continuously welded exhaust
- Ferritic structure costs less than an austenitic grade where chloride pitting is not the main risk
- Good formability lets the sheet be pressed and rolled into exhaust sections
- Cold and hot rolled ranges meet from 3 mm, so there is no thickness gap
- Four standard finishes plus customer specific polishing
Who It Is For
- Automotive exhaust fabricators and tier suppliers
- Sheet metal shops pressing hot end components
- Buyers replacing coated carbon steel with a stabilised ferritic grade
- Stockists carrying 409 in both cold and hot rolled thicknesses
Problems It Solves
- Carbon steel exhaust parts that rust through within a few seasons
- Weld zone corrosion in unstabilised ferritic sheet
- Cost pressure when an austenitic grade is specified but not needed
- Width and length limits that force extra joints in a pressed part
Application Scenarios
- Automotive exhaust systems, silencers and tail pipes
- Heat shields and hot end sheet metal work
- Agricultural and general fabrication where carbon steel rusts too quickly
- Containers and ducting at moderate temperature
Specifications
Every value below is taken from the published product data. Where a figure is not published it is left out rather than estimated.
| Grade | 409 |
|---|---|
| Width | 500 to 2000 mm or customised |
| Length | 1000 to 12000 mm or customised |
| Cold Rolled Thickness | 0.3 to 3 mm |
| Hot Rolled Thickness | 3 to 120 mm |
| Standard | ASTM A167, A176, A240/A240M, A263, A264, A265, A666, A480/A480M, EN 10088-2, JIS G4305 |
| Surface Finish | 2B, No.4, BA, No.1 hot rolled annealed and pickled, plus customer specific polish |
| Structure | Ferritic |
Technical Features
- Thermostable ferritic stainless steel stabilised with titanium
- Better oxidation and corrosion resistance than carbon steel
- Good formability and weldability
- Cold rolled 0.3 to 3 mm and hot rolled 3 to 120 mm
- Surface finishes 2B, No.4, BA and No.1 hot rolled annealed and pickled
Materials
- 409 titanium stabilised ferritic stainless steel
Manufacturing Process
- Hot rolling
- Cold rolling
- Annealing and pickling
- Polishing
Quality Control
- Thickness measured across width against the ordered cold or hot rolled range
- Surface finish checked against the ordered 2B, No.4, BA or No.1 condition
- Tensile strength recorded against the grade specification
- Width and length verified before cutting
Customisation Options
- Width and length cut to your requirement outside the standard ranges
- Customer specific polish in addition to the four standard finishes
- Cold rolled or hot rolled condition selected by thickness
Use Guide
- Select cold rolled below 3 mm and hot rolled above it
- Form with generous radii, as ferritic grades have less elongation than austenitic sheet
- Weld with a stabilised or matching filler to protect the heat affected zone
- State the finish on the order, since 2B, No.4, BA and No.1 behave differently in forming
How It Compares With the Alternatives
| 304 stainless sheet | 409 is a ferritic grade with far less nickel, so it costs less and suits exhaust duty, but it does not match 304 in wet chloride service |
|---|---|
| Aluminised carbon steel | 409 resists oxidation and corrosion without a coating that can be damaged in forming |
| 439 or 441 ferritic grades | 409 is the baseline titanium stabilised exhaust grade, with higher alloyed ferritics used where the hot end runs hotter |
