Hairline Finish Stainless Steel Sheet
A hairline finish is a directional surface where the metal carries a straight, fine grain running the length of the sheet. The standard market hairline is 180 to 240 grit, and varying the roughness of the polished grain…
What This Product Is For
A hairline finish is a directional surface where the metal carries a straight, fine grain running the length of the sheet. The standard market hairline is 180 to 240 grit, and varying the roughness of the polished grain changes how the surface reads. Crossing the grain produces a cross hairline, and polishing in a circular pattern produces a circular hairline, which is why this is the most widely used decorative treatment for stainless steel.
Key Benefits
- Directional grain hides fingerprints and minor handling marks better than a mirror finish
- Standard 180 to 240 grit is repeatable, so panels from different batches match
- Cross hairline and circular hairline variants available from the same process
- Four grades from 201 through 430 let cost and corrosion resistance be balanced
- Sheet, plate, coil and strip all supplied with the same finish
Who It Is For
- Architectural metalwork fabricators matching a specified finish
- Appliance and kitchen equipment manufacturers
- Shopfitters and signage producers
- Distributors supplying decorative stainless in coil and sheet
Problems It Solves
- Visible fingerprints and scuffs on polished stainless in public areas
- Panel to panel mismatch when grit and grain direction are not controlled
- Cost pressure where 304 is specified but 201 or 430 would serve
- Sourcing sheet, coil and strip in one consistent finish
Application Scenarios
- Architectural wall panels, lift interiors and door frames
- Commercial kitchen and appliance panels
- Signage and shopfitting metalwork
- Equipment cladding where a matt directional surface is specified
Specifications
Every value below is taken from the published product data. Where a figure is not published it is left out rather than estimated.
| Grade | 201, 304, 304L, 430 |
|---|---|
| Process | Hot rolled and cold rolled |
| Type | Sheet, plate, coil, strip |
| Polish | 180 to 240 grit, No.4 satin or hairline |
| Width | 500 to 2000 mm or customised |
| Length | 1000 to 6000 mm or customised |
| Cold Rolled Thickness | 0.3 to 3 mm |
| Hot Rolled Thickness | 3 to 20 mm |
| Standard | ASME, ASTM, EN, GB, DIN, JIS |
| Delivery | 15 to 20 days according to order quantity |
| Shipping | FCL, LCL, bulk |
| Loading Port | Shanghai |
Technical Features
- Polish 180 to 240 grit, No.4 satin or hairline
- Grain direction can be straight, crossed or circular
- Grades 201, 304, 304L and 430
- Hot rolled and cold rolled processing
- Supplied as sheet, plate, coil and strip
Materials
- 201, 304, 304L and 430 stainless steel
Manufacturing Process
- Hot rolling
- Cold rolling
- Belt polishing
- Protective film application
Quality Control
- Grit checked against the ordered 180 to 240 band
- Grain direction confirmed consistent across the batch
- Thickness measured against the cold or hot rolled range
- Surface inspected for polish skips and film damage before packing
Customisation Options
- Straight, cross or circular hairline grain
- Grit varied within and around the 180 to 240 range
- Sheet, plate, coil or strip form with width and length cut to order
Use Guide
- Fix grain direction on the drawing so adjacent panels run the same way
- Keep the protective film on until installation is complete
- Match grit between orders by quoting the 180 to 240 band explicitly
- Choose 304 or 304L for exterior work and 201 or 430 for dry interior use
How It Compares With the Alternatives
| Mirror finish sheet | Hairline hides fingerprints and handling marks, while a mirror surface shows every touch and needs more protection on site |
|---|---|
| 2B mill finish | 2B is a functional mill surface, hairline is a controlled decorative grain that can be matched panel to panel |
| Cross hairline | A cross hairline is made by crossing the grain and reads as a woven texture rather than a straight brushed line |
Related Products
409 Stainless Steel Plate and Sheet
Grade 409 is a thermostable ferritic stainless steel with better oxidation and corrosion resistance than carbon steel. This…
View specifications →
316L Stainless Steel Sheet
Grade 316 is the standard molybdenum bearing austenitic stainless steel, second only to 304 in importance. The molybdenum gives it…
View specifications →
2205 Duplex Stainless Steel Sheet
2205 duplex stainless steel, UNS S32205 and S31803, is a 22 percent chromium, 3 percent molybdenum, 5 to 6 percent nickel and…
View specifications →
Mirror Finish Stainless Steel Sheet
A mirror finish is a bright non directional surface polished with a 1000 grit abrasive belt and then buffed. EN 10088-2 classifies…
View specifications →Hairline Finish Stainless Steel Sheet Questions
What grit is a standard hairline finish
Which grades can be supplied with this finish
Can you produce cross hairline or circular hairline
What thicknesses are available
What is the lead time
Which forms can carry a hairline finish
Quote Hairline Finish Stainless Steel Sheet
Send the size, wall or thickness, quantity and destination port. Certificates, packing and lead time are confirmed on the quotation.
