Garland String Light
Waterproof String Light
The outdoor-specified string in the garland range, with glued joints and a rubber ring at every connector. Connector sealing is where seasonal string light actually fails, so this is the line to specify for anything staying outdoors through a winter.
- Custom shapes in 20-30 days
- Low MOQ on project work
- OEM and ODM private label
- Samples before bulk order
Key benefits
Why Buyers Choose This Product
Glued joints with a rubber ring at every connector, tested to IP65
Up to 200 m from one power cord, cutting power positions
Cold-resistant cable that stays flexible at winter temperatures
Built to CE, RoHS and REACH requirements
Who It Is For
- Municipal street tree contractors
- Facade decoration installers
- Hotel and resort grounds teams
Problems It Solves
- Consumer-grade string failing in the first wet week
- Joints letting water in and taking out a whole run
- Runs too short to reach, so installers over-chain them
Where It Is Used
- Street tree wrapping
- Building facade grids
- Outdoor terrace and garden runs
- Permanent architectural installations
Technical
How It Is Built
Bullet cap with a gluing technique for a bigger, brighter light spot
Welding, gluing and casing done by full-automation machine for a consistent finish
Extendable
one power cord carries up to 200 m
Cold-resistant flexible copper core, so the cable still bends in winter
IP65 joints, glued and sealed with a rubber ring at each connector
3000 sets a day of output, so peak-season volume is covered
| Bulb | Epistar LED bulb |
|---|---|
| Wire | PVC or rubber cable, 0.5 mm2 pure copper core |
| Bulb Spacing | 5 cm to 50 cm to requirement |
| Bulb Colour | Red, green, yellow, blue, white, warm white, pink, purple, multi colour, RGB |
| Wire Colour | Clear, white, green, dark green, blue, pink, black, yellow, purple |
| Ingress Protection | IP65, glued joints with a rubber ring on the connectors |
| Max Run | 200 m from one power cord |
| Options | With or without controller, with or without end plug |
| Standards | Built to CE, RoHS and REACH requirements |
Materials
- 0.5 mm2 pure copper conductor
- Environmentally friendly rubber and PVC cable
- Epistar LED bulbs
- PC bullet caps
Customisation
- Any shape, size, colour and material to your drawing
- Private label OEM and ODM with your brand on product and packaging
- Standard items in 7-9 days, custom work in 20-30 days after sample approval
- Sample orders welcome before a bulk order, and low MOQ on project work
How It Is Made
Copper core cable cut to the ordered length
LED bulbs welded on at the agreed spacing by automatic machine
Bullet caps glued and cased
Connectors fitted with rubber rings and sealed to IP65
Controller and end plug fitted if ordered
Ageing test, coil, label and carton
Quality Control
- Automated weld and glue inspection on the line
- Connector waterproof test
- Continuity and brightness check over the full run length
- Ageing test under current before packing
Certification
- CE EMC Directive 2014/30/EU — certificate HTT202404615E
- CE Low Voltage Directive — certificate HTT202404615L
- RoHS with amending Annex EU 2015/863 — certificate HTT202404615CH
- Covered models: UPL-S01, UPL-S07, UPL-S08, UPL-S10, UPL-S50, UPL-S100
Comparison
How It Compares With The Alternatives
Compared With LED fairy light
This line is built to survive outdoors; fairy light is built to look right at close range indoors.
Compared With Rubber cable string light
Waterproof string is for fixed outdoor installation; rubber cable is for stock that is handled and re-rigged repeatedly.
Use Guide
- Dress connectors horizontally and keep them off the ground
- Do not exceed 200 m from one feed, or the far end dims
- Fix the run to the structure so the cable never carries its own tension
Related
Other Products In This Range
LED Fairy Light
Fine-wire warm white string with closely spaced bulbs, supplied in bundles for interior and close-range decoration.
View product
Rubber Cable String Light
The same string construction on environmentally friendly rubber cable instead of PVC.
View product
LED String Light
The core commercial string line, welded, glued and cased on automated machines at around 3000 sets a day.
View product
PVC Tinsel Motif Decoration Material
PVC tinsel is the surface that turns a bare welded frame into a motif that reads as an object in daylight.
View productIndustries
Project showcase
Questions
Waterproof String Light Questions
How is the connector sealed?
Glued and fitted with a rubber ring, tested to IP65. That joint is where cheap string fails first, which is why the automated line spends its time there.
What is the maximum run from one cord?
200 m. Past that you need a second feed.
Is it suitable for permanent installation?
Yes, and it is built to CE, RoHS and REACH requirements. Check the fixing rather than the cable for a permanent run.
