Garland String Light
LED String Light
The core commercial string line, welded, glued and cased on automated machines at around 3000 sets a day. It is specified by run length, bulb spacing, cable type and colour rather than sold as a fixed product, which is what makes it usable on any job.
- Custom shapes in 20-30 days
- Low MOQ on project work
- OEM and ODM private label
- Samples before bulk order
Key benefits
Why Buyers Choose This Product
Specified per job
run length, spacing, cable type and colour all to order
Welding, gluing and casing by full-automation machine for a repeatable finish
About 3000 sets a day of output, so peak-season volume is covered
Bullet cap glued for a bigger, brighter light spot
Who It Is For
- Distributors and wholesalers
- General decoration contractors
- Importers running private label lines
Problems It Solves
- Fixed-length products that never match the run you actually have
- Specification drift between shipments on a catalogue line
- Factories that cannot cover peak-season volume
Where It Is Used
- General contractor stock
- Trade counter and resale lines
- Large-volume municipal orders
- Private label programmes
Technical
How It Is Built
Bullet cap with a gluing technique for a bigger, brighter light spot
Welding, gluing and casing done by full-automation machine for a consistent finish
Extendable
one power cord carries up to 200 m
Cold-resistant flexible copper core, so the cable still bends in winter
IP65 joints, glued and sealed with a rubber ring at each connector
3000 sets a day of output, so peak-season volume is covered
| Bulb | Epistar LED bulb |
|---|---|
| Wire | PVC or rubber cable, 0.5 mm2 pure copper core |
| Bulb Spacing | 5 cm to 50 cm to requirement |
| Bulb Colour | Red, green, yellow, blue, white, warm white, pink, purple, multi colour, RGB |
| Wire Colour | Clear, white, green, dark green, blue, pink, black, yellow, purple |
| Ingress Protection | IP65, glued joints with a rubber ring on the connectors |
| Max Run | 200 m from one power cord |
| Options | With or without controller, with or without end plug |
| Standards | Built to CE, RoHS and REACH requirements |
Materials
- 0.5 mm2 pure copper conductor
- Environmentally friendly rubber and PVC cable
- Epistar LED bulbs
- PC bullet caps
Customisation
- Any shape, size, colour and material to your drawing
- Private label OEM and ODM with your brand on product and packaging
- Standard items in 7-9 days, custom work in 20-30 days after sample approval
- Sample orders welcome before a bulk order, and low MOQ on project work
How It Is Made
Copper core cable cut to the ordered length
LED bulbs welded on at the agreed spacing by automatic machine
Bullet caps glued and cased
Connectors fitted with rubber rings and sealed to IP65
Controller and end plug fitted if ordered
Ageing test, coil, label and carton
Quality Control
- Automated weld and glue inspection on the line
- Connector waterproof test
- Continuity and brightness check over the full run length
- Ageing test under current before packing
Certification
- CE EMC Directive 2014/30/EU — certificate HTT202404615E
- CE Low Voltage Directive — certificate HTT202404615L
- RoHS with amending Annex EU 2015/863 — certificate HTT202404615CH
- Covered models: UPL-S01, UPL-S07, UPL-S08, UPL-S10, UPL-S50, UPL-S100
Comparison
How It Compares With The Alternatives
Compared With Waterproof string light
Both share the construction; the waterproof line is specified and tested for permanent exposed installation.
Compared With Rubber cable string light
This is the general line in PVC or rubber; the rubber line is specified for repeat handling.
Use Guide
- Specify run length, spacing, cable colour and controller explicitly on the order
- Ask for a sealed golden sample at first order so repeats can be matched
- Confirm the maximum run per feed before planning power positions
Related
Other Products In This Range
LED Fairy Light
Fine-wire warm white string with closely spaced bulbs, supplied in bundles for interior and close-range decoration.
View productWaterproof String Light
The outdoor-specified string in the garland range, with glued joints and a rubber ring at every connector.
View product
Rubber Cable String Light
The same string construction on environmentally friendly rubber cable instead of PVC.
View product
PVC Tinsel Motif Decoration Material
PVC tinsel is the surface that turns a bare welded frame into a motif that reads as an object in daylight.
View productIndustries
Project showcase
Questions
LED String Light Questions
What do you need to quote a string light order?
Run length, bulb spacing, bulb colour, cable type and colour, whether you want a controller and end plug, and the quantity.
How do you keep repeat orders consistent?
A sealed golden sample retained at the factory, matched physically rather than against a written specification.
What output can you cover in peak season?
The line runs about 3000 sets a day. Confirm the date you need goods on the water and we will schedule against it.
