Diameter 60mm AC Motor Roller
Diameter 60mm AC Motor Roller belongs to the DGAC AC Motor Rollers family built at our Wuxi plant. Material: mild steel & galvanized, mild steel & rubber coated, mild steel & pu coated, SUS304. It runs from 3PH380V, 3PH220V, 1PH220V.
Manufactured by Tianhe Conveying Machine Co., Ltd, Wuxi, Jiangsu, China. Specification confirmed on drawing before production.
Published data for this model
| Power Supply | 3PH380V, 3PH220V, 1PH220V |
|---|---|
| Material | mild steel & galvanized, mild steel & rubber coated, mild steel & pu coated, SUS304 |
Figures above are taken from the manufacturer's published data for this model. Values not listed are confirmed on drawing rather than estimated.
Where it is used
AC motor rollers are strong and simple but they are not made for accumulating lines that start and stop hundreds of times an hour; that duty belongs to the brushless DC family.
- Continuously running transport conveyors
- Powered roller sections in existing AC plants with no 24 V supply
- Stainless and PU-coated rollers for damp areas
- Sprocket-driven groups where one roller slaves several idlers
How to specify it
Confirm the supply first — 1PH220V, 3PH220V or 3PH380V — then pick the type: AS standard, ASs short, or AU accumulation. Rated speed and tractive force move in opposite directions, so choose the slowest speed that meets your throughput.
Ordering
Send the model number with the quantity and destination country to [email protected]. We reply with price, lead time and a drawing to confirm before production.
Other DGAC Motor Roller models
Diameter 50mm AC Motor Roller
Material: mild steel & galvanized, mild steel &…
Diameter 76mm Alternate Current High Torque Motor Roller
DGAC60/76-AS/HAS/HBP-1PH220V/3PH220V/3PH380V-11M/Min-300L-X-T-H1-N
AC Stainless Motorized Roller with Double Sprocket
Motor Power: 22W
AC Stainless Motorized Roller with Multi Groove
Motor Power: 60W
AC PU Coating Motorized Roller with Double Sprocket
Motor Power: 22W
AC Motorized Roller with Straight Groove
Motor Power: 30WApplications and selection guidance
Food and Beverage Packing
Stainless ball transfer units, wash-down motor rollers and drum motors for lines that get hosed down every shift.
Product GuideHow to Read a Motor Roller Model Code
Every dimension you need to order a motor roller is already in the model code. Here is how to read one from left to right.
Frequently Asked Questions
How do I order Diameter 60mm AC Motor Roller?
Send the model number and the quantity to [email protected], or message us on the contact page. We reply with price, lead time and the drawing for confirmation.
Quote Diameter 60mm AC Motor Roller
Email the model and quantity; we reply with price, lead time and drawing.
