Single Sprocket Roller Bearings
End caps with a single moulded sprocket, used to chain-drive a roller from the one before it. The standard choice for driven roller groups on medium loads where a chain is preferred to a belt.
Single Sprocket Roller Bearings models we manufacture
Plastic Single Sprocket End Cap for Sprocket type:08B14T-Shaft:15
Plastic Single Sprocket End Cap for Sprocket type:08B14T-Shaft:12
Plastic Single Sprocket End Cap for Sprocket type:08B11T-Shaft:15
Plastic Single Sprocket End Cap for Sprocket type:08B11T-Shaft:12
Plastic Single Sprocket End Cap for Sprocket type:08B9T-Shaft:15
Plastic Single Sprocket End Cap for Sprocket type:08B9T-Shaft:12
The problem this group solves
Chain drive tolerates dirt and oil that would make a belt slip, which is why it survives in workshop and foundry environments where poly-V groups do not.
How to choose
Quote the chain pitch and tooth count, for example 08B with 14 teeth, and keep the same combination across the group.
Typical applications
- Driven roller groups in workshop and machining areas
- Oily and dusty environments unfriendly to belts
- Medium-load powered transport sections
- Retrofit of chain drive into existing roller frames
Where Single Sprocket Roller Bearings is specified
Automotive and General Manufacturing
Ball transfer tables for die handling, sprocket-driven roller groups and heavy metal flow track for press and weld shops.
Comparison GuideChain Poly-V or O-Belt Drive Between Rollers
Once one roller in a zone is powered, the rest are slaved to it. Three drive profiles do that job, and they fail in different environments.
Other Drive Roller Plastic Bearings families
Frequently Asked Questions
What chain do single sprocket end caps use?
Standard roller chain matched to the sprocket pitch and tooth count on the cap — the model page lists the combination.
Single or double sprocket?
Single carries drive to the next roller only. Double lets drive pass through a roller to the one beyond it.
