KY-PC-S1 Brushed 304 Stainless Steel Industrial Keyboard
KY-PC-S1 is a panel mounted keyboard in brushed 304 stainless steel with keys shaped to follow the human finger. A 3mm aluminium alloy base plate carries the key matrix, giving a 1.8Kg net weight assembly that does not flex when…
Product Overview
KY-PC-S1 is a panel mounted keyboard in brushed 304 stainless steel with keys shaped to follow the human finger. A 3mm aluminium alloy base plate carries the key matrix, giving a 1.8Kg net weight assembly that does not flex when struck. Key trip is 1.75mm with a contact force of 3N+/-0.3N, and the unit runs over USB or PS/2.
- Keys shaped to the finger reduce mis-hits during long shifts at a fixed station
- A 3mm aluminium alloy base plate stops the key field flexing under heavy use
- 1.75mm key trip balances positive feedback against typing speed
- Brushed 304 stainless steel resists riot damage and corrosion
- USB and PS/2 output keeps older control PCs in service
Application Scenarios
- Panel mounted operator stations on production lines
- Control rooms running Linux or Ubuntu software
- Fixed workstations requiring a non removable keyboard
- Industrial cabinets where a desktop keyboard would be damaged
- Legacy control PCs still using PS/2 input
Who It Is For
- Machine builders fitting keyboards into control panels
- Industrial automation integrators
- Facilities replacing consumer keyboards on plant floors
Problems It Solves
- Flat metal keys cause finger fatigue and typing errors over a full shift
- Thin backing plates deform when a keyboard is hit
- Desktop keyboards get contaminated and removed from industrial areas
- New keyboards often drop PS/2 that legacy controllers still need
Technical Features
- Keys designed according to the shape of human fingers
- Anti-riot and anti-corrosion 304 stainless steel keys with brushed finish
- 3mm aluminium alloy back panel and base plate
- Power supply 5V±5% with working current under 100mA
- Key size 13*∅13*6.5 / 31*∅13*6.5 with 1.75mm key trip
- Operation force 3N+/-0.3N contact force
- Panel mounting with 1.8Kg net weight and 2 Kg gross weight
Specifications
| Power Supply | 5V±5% |
|---|---|
| Working Current | <100mA |
| Interface | USB / PS/2 |
| Key Size | 13*∅13*6.5 / 31*∅13*6.5 |
| Key Trip | 1.75mm |
| Operation Force | 3N+/-0.3N |
| Mounting Way | Panel mounting |
| Net Weight | 1.8Kg |
| Gross Weight | 2 Kg |
| Back Panel | 3mm Aluminium alloy |
| Operation Temperature | -10℃~45℃ |
| Storage Temperature | -30℃~85℃ |
Materials
- 304 stainless steel keys with brushed finish
- 3mm aluminium alloy base plate
Manufacturing Process
- Brushing of the 304 stainless steel key surfaces
- CNC machining of the 3mm aluminium alloy base plate
- Key forming to the finger shaped profile
- Key legend etching or laser marking
- Matrix assembly and panel mounting hardware fitting
- Electrical test over USB and PS/2
Quality Control
- Key trip measured against the 1.75mm specification
- Contact force sampling against 3N+/-0.3N
- Base plate thickness and flatness verification
- Weight check against the 1.8Kg net figure
- Full key matrix function test
Customisation Options
- Customized layout across the key field
- Customized function keys or combination keys
- Panel mounting hole pattern to your cabinet
- Choice of USB or PS/2 termination
- Key legend content and marking method
How It Compares
| Flat faced metal keyboards | Keys follow the shape of the finger, which reduces slips during long entry sessions |
|---|---|
| Thin backed metal keyboards | A 3mm aluminium alloy base plate keeps the key field rigid |
| Short travel keypads | 1.75mm key trip gives clearer confirmation than a shallow click |
Use Guide
- Support the panel for the 1.8Kg net weight before fixing
- Use panel mounting and check the cutout matches the base plate
- Confirm 5V±5% supply and under 100mA draw at the host
- Select USB or PS/2 at order time
- Operate within -10℃~45℃ and store no colder than -30℃
Related Products
Questions About This Model
What is the key travel on KY-PC-S1?
1.75mm with a contact force of 3N+/-0.3N.
How is the keyboard mounted?
Panel mounting.
What backs the key field?
A 3mm aluminium alloy base plate.
How heavy is it?
Net weight is 1.8Kg and gross weight is 2 Kg.
Which interfaces are supported?
USB and PS/2.
Why are the keys shaped?
The keys are designed according to the shape of human fingers.
