KY-PC-N Kiosk Keyboard With 25mm Optical Trackball
KY-PC-N is a stainless steel kiosk keyboard with a 25mm optical trackball built into the panel. Its operating range starts at -20℃, which is lower than most of the range and suits terminals in unheated lobbies and outdoor…
Product Overview
KY-PC-N is a stainless steel kiosk keyboard with a 25mm optical trackball built into the panel. Its operating range starts at -20℃, which is lower than most of the range and suits terminals in unheated lobbies and outdoor shelters. It is used in financial equipment, communication equipment and military equipment where the keyboard must also be water and vandal proof.
- 25mm optical trackball has no mechanical ball rollers to clog with lint
- Operation temperature starts at -20℃ for unheated and outdoor terminals
- Stainless steel keyboard with water and vandal proof design for public exposure
- 330*100 mm front panel fits a standard kiosk fascia band
- RoHS, IP65, FCC and CE approvals support financial and government tenders
- Compact layout customized for free including national character sets
Application Scenarios
- Financial equipment such as branch self-service terminals
- Communication equipment cabinets
- Military equipment control panels
- Unheated lobby kiosks operating near -20℃
- Industrial control stations
Who It Is For
- Financial self-service equipment manufacturers
- Communications infrastructure integrators
- Defence equipment suppliers
- Kiosk OEMs deploying in cold climates
Problems It Solves
- Mechanical trackballs that seize with dust and hair in public use
- Keyboards that stop responding in sub-zero lobbies
- Loose mice on financial terminals
- Fixed layouts that do not match a localized banking interface
Technical Features
- Stainless steel keyboard with water and vandal proof design
- Optical trackball with 25mm ball diameter
- Key Trip 2mm with Operation Force 280g±20g
- Power Supply DC5V±5% and Working Current <150mA
- Operation Temperature -20℃~55℃, Storage Temperature -30℃~85℃
- Rear mounting or Front mounting with USB and PS/2 interfaces
Specifications
| Front Panel | 330*100 mm |
|---|---|
| Overall | 354*124mm |
| Trackball Diameter | 25mm |
| Trackball Type | Optical |
| Power Supply | DC5V±5% |
| Working Current | <150mA |
| Interface | USB, PS/2 |
| Key Trip | 2mm |
| Operation Force | 280g±20g |
| Durability | ≥2million |
| Operation Temperature | -20℃~55℃ |
| Approval | RoHS, IP65, FCC, CE |
Materials
- Stainless steel panel
- Stainless steel buttons
Manufacturing Process
- Panel forming of the 330*100 mm stainless face
- CNC machining of the 25mm trackball seat
- Laser or etching procedure for key labeling
- Optical sensor alignment to the trackball
- Sealing and IP65 verification
Quality Control
- Cold start test at the -20℃ lower operating limit
- Operation force sampling at 280g±20g
- Optical trackball tracking accuracy check
- IP65 ingress test
Approvals And Test Documentation
- RoHS
- IP65
- FCC
- CE
Customisation Options
- Free layout customization on the compact key field
- Laser or etching key labeling
- Rear or front mounting hardware
- Interface choice between USB and PS/2
- Function and combination key definitions
How It Compares
| Mechanical trackball keyboard | The optical 25mm ball has no rollers to clean, which cuts service calls on high traffic kiosks |
|---|---|
| Keyboard rated from -10℃ | KY-PC-N operates from -20℃, so it starts in unheated outdoor shelters |
Use Guide
- Check the 354*124mm overall size against the cabinet before cutting the 330*100 mm aperture
- Choose rear or front mounting at design stage
- Operate within -20℃~55℃ and store within -30℃~85℃
- Keep the trackball aperture free of debris despite the optical sensing
Related Products
Questions About This Model
What size is the trackball on KY-PC-N?
25mm diameter, and it is an optical trackball.
How cold can it operate?
Operation temperature is -20℃~55℃.
What are the panel dimensions?
Front panel 330*100 mm, overall 354*124mm.
Which approvals apply?
RoHS, IP65, FCC and CE.
What is the key force?
Operation force is 280g±20g with a 2mm key trip.
Can KEYU supply matching pointing devices?
Yes, KEYU also provides kiosk metal touchpads, keypads, pinpads and trackballs.
Request A Quote On KY-PC-N
Tell us quantity, interface and mounting method. Drawings and panel cutouts are welcome by WhatsApp or email.
