Industrial USB Keyboard With Touchpad Mouse KY-PC-F2-449
KY-PC-F2-449 is an 89 key panel style embedded metal keyboard with an integrated touchpad mouse, so keyboard and pointer share one 392*135 mm cutout.
Product Overview
KY-PC-F2-449 is an 89 key panel style embedded metal keyboard with an integrated touchpad mouse, so keyboard and pointer share one 392*135 mm cutout. The stainless steel build is water and vandal proof and rated IP65 for exposed industrial terminals. It runs over USB or PS/2 and is listed with RoHS, IP65, FCC and CE approvals.
- Keyboard and mouse are integrated, saving console space on a single 392*135 mm face
- 60x44mm touchpad gives pointer control with no moving parts to clog
- Stainless steel water and vandal proof construction rated IP65
- 2mm key trip with 280g±20g operation force gives a defined press through gloves
- Rear mounting or front mounting to fit the existing console design
- Approvals RoHS, IP65, FCC and CE support export projects
Application Scenarios
- Self-service terminals
- Security equipment consoles
- Mine safety detection stations
- Industrial PC numerical control platforms
- Fixed offshore platforms and explosion-proof equipment
- Metallurgy, power and transportation control rooms
Who It Is For
- Self-service terminal manufacturers
- Industrial PC and CNC platform builders
- Offshore and mining equipment suppliers
- Power and transportation control integrators
Problems It Solves
- Two cutouts for keyboard and mouse waste console area, avoided by the integrated design
- Trackballs collect dust in mines and plants, so a sealed 60x44mm touchpad is used instead
- Water ingress kills open keyboards, prevented by IP65 sealing
- Export approvals slow projects, addressed by listed RoHS, IP65, FCC and CE approval
Technical Features
- 89 buttons in a panel style embedded metal keyboard
- Touchpad diameter 60x44mm
- Power supply DC5V±5% and working current <150mA
- Key trip 2mm with operation force 280g±20g
- Durability ≥2million
- Operation temperature -20℃~55℃ and storage -30℃~85℃
- Laser or etching procedure for key labeling optional
Specifications
| Model | KY-PC-F2-449 |
|---|---|
| Keys | 89 |
| Front panel | 392*135 mm |
| Overall | 412*159 mm |
| Touchpad | 60x44mm |
| Power supply | DC5V±5% |
| Working current | <150mA |
| Interface | USB, PS/2 |
| Key trip | 2mm |
| Operation force | 280g±20g |
| Durability | ≥2million |
| Mounting way | Rear mounting or Front mounting |
Materials
- Stainless steel panel and buttons
- Sealed touchpad surface
Manufacturing Process
- Sheet metal forming of the 392*135 mm front panel
- CNC machining of the 60x44mm touchpad aperture
- Laser or etching of key legends
- Touchpad module bonding and IP65 sealing
- Assembly for rear or front mounting and function test
Quality Control
- Touchpad cursor tracking across the 60x44mm area
- IP65 water and dust ingress test
- Operation force sampling against 280g±20g
- Conformity checks for RoHS, FCC and CE
Approvals And Test Documentation
- RoHS
- IP65
- FCC
- CE
Customisation Options
- Compact layout customized for free
- Laser or etching procedure for key labeling
- Rear or front mounting arrangement
- USB or PS/2 interface
How It Compares
| Keyboards with separate mice | Keyboard and mouse are integrated into one 392*135 mm panel, saving console space |
|---|---|
| Trackball keyboards | A 60x44mm touchpad has no ball to clean in dusty mine and plant air |
| Unsealed industrial keyboards | IP65 water and vandal proof sealing suits exposed public and plant terminals |
Use Guide
- Cut the console for the 412*159 mm overall body and choose rear or front mounting
- Supply DC5V±5% and allow for the <150mA working current
- Connect USB or PS/2 to the terminal PC
- Keep the touchpad face clean and dry for accurate cursor tracking
Related Products
Questions About This Model
How many keys does it have?
89 buttons.
What size is the touchpad?
60x44mm.
What approvals are listed?
RoHS, IP65, FCC and CE.
How is it mounted?
Rear mounting or front mounting.
What is the key travel?
2mm with 280g±20g operation force.
Which interfaces are supported?
USB and PS/2.
Request A Quote On KY-PC-F2 -449
Tell us quantity, interface and mounting method. Drawings and panel cutouts are welcome by WhatsApp or email.
