Name: Segmented Diamond Blade for Ceramics
Brand: Bello Diamond Tools
SKU: TA180SG

Laser-cut slots for faster tile cutting

Special laser-cut slots clear swarf on thick and double-loaded tile bodies where a closed rim would stall. Item IDs TA180SG-TA350SG are silver-welded for continuous production duty.

Request A Quote Talk To An Engineer

Ceramic Tile
TA180SG to TA450SG
8 sizes listed

Segmented Diamond Blade for Ceramics — Laser-cut slots for faster tile cutting

Product Overview

What Segmented Diamond Blade for Ceramics Is For

The plant specification sheet describes this tool as for smooth, fast and chip-free cutting ceramic tiles, porcelain tiles, glazed floor with special laser cut slot. That is exactly where it belongs, and where it stops.

The specification table lists 8 sizes, Item IDs TA180SG to TA450SG.

Inside Diamond Cutting Blades there are 2 items to choose between. This one is the laser-cut slots for faster tile cutting option — the comparison further down this page sets it against the others.

Technical Features

How It Is Built

Manufacturing route

Silver welded. This is what holds the diamond in place under working load.

Bond selected per enquiry

We do not ship a single general-purpose bond. Please tell us your tiles and working condition, we will choose the best bonding for you.

Item ID series

Ordering runs on the TA180SG to TA450SG series, so repeat orders return the same specification.

Sizes beyond the standard list

Other sizes are available upon customer's request.

Export handling

Packed for export and shipped from Shangqiu, Henan. Give us your destination port with the enquiry.

Specifications

Sizes and Item IDs

Taken from the plant specification sheets. Where a value is not published we say so rather than fill it in.

Segmented Diamond Blade for Ceramics — Specification table
Item ID	Diameter	Bore size	Segment	Grit size
mm	inch	mm	thickness (mm)	height (mm)
TA180SG	180	7	60	1.8/2.0	10	126#, 151#, 181#, 213#, 252#, 301#, 427#
TA200SG	200	8	60	1.8/2.0	10
TA250SG	250	10	60	1.8/2.0/2.2/2.4	10
TA300SG	300	12	60	1.8/2.0/2.2/2.4	10
TA350SG	350	14	60/50	2.4/2.6/2.8	10
TA400SG	400	16	60/50	2.4/2.6/2.8	10
TA450SG	450	18	75/50	2.6/3.0	10

Product family: Ceramic Tile
Category: Diamond Cutting Blades
Manufacturing route: Silver welded.
Bond: Please tell us your tiles and working condition, we will choose the best bonding for you.
Country of manufacture: China (Shangqiu, Henan)
Private label: Laser marking on the steel core available for OEM orders

Product Photography

More Views of Segmented Diamond Blade for Ceramics

Photographs supplied by the plant. What you see is the tool as produced, not a render.

Segmented Diamond Blade for Ceramics — view 2

Who It Is For

Ceramic tile plants cutting to format
Tile processors making step and skirting pieces
Tile retailers cutting to order

Every one of these buyers gets the same first question from us: what material, what machine, what size.

The Problem It Solves

Chipped tile edges get rejected at the packing line, not at the saw.

Segmented Diamond Blade for Ceramics is the answer to that in the diamond cutting blades part of the range: laser-cut slots for faster tile cutting.

For smooth, fast and chip-free cutting ceramic tiles, porcelain tiles, glazed floor with special laser cut slot.

Key Benefits

Why This Version and Not Another

Continuous rim for chip-free edges, segmented for speed on thick tiles

Applies across the diamond cutting blades series, including this item.

Hot-press sintered and silver-welded versions

Part of how this category is built.

Dia 105-450 mm across the two series

Part of how this category is built.

Use Guide

Confirm the fit
Check diameter, bore and segment dimensions against the table above and against your machine.
Set the parameters
Start at the machine builder's figures for your material, then adjust feed until the cut runs quiet and the surface stays clean.
Keep it free-cutting
If the tool stops cutting and the face goes shiny, it has glazed. Dress it, then tell us — that means the bond should change.
Order by Item ID
Quote the Item ID on repeat orders so you get the same specification as last time.

Compared With the Rest of the Category

Diamond Cutting Blades holds 2 items in the programme. The difference between them is geometry and construction, not marketing.

Continuous Rim Blade for Ceramics — chip-free cutting on porcelain and glazed tiles
Continuous Rim Diamond Cylinderical Wheels — continuous rim rough grinding after calibration
Segmented Diamond Cylinderical Wheels — segmented cylindrical wheel for faster removal
Magnesium Oxide Bond Silicon Carbide Abrasive — magnesium oxide bond for graded tile grinding
Resin Bond Silicon Carbide Abrasive — resin bond abrasive for matt tile finishes
Metal Bond Diamond Chamfering Wheels — metal bond chamfering for hard tile edges

See the whole diamond cutting blades category

Questions Buyers Ask

Segmented Diamond Blade for Ceramics — Questions We Get Asked

What sizes does Segmented Diamond Blade for Ceramics come in

The standard programme lists 8 sizes on this page, Item IDs TA180SG to TA450SG. Other sizes are available upon customer's request.

Which bond will you supply for my material

The bond is set per enquiry rather than per catalogue number. Please tell us your tiles and working condition, we will choose the best bonding for you.

What do you need to quote Segmented Diamond Blade for Ceramics

The material you process, the machine and its power, the size and bore you need, and the quantity. With those four we quote a specification rather than a guess.

What is the lead time and minimum order for Segmented Diamond Blade for Ceramics

Lead time and minimum order depend on whether the size is in the standard programme or needs a production batch. Ask the sales office for this item — we do not publish a single figure that would be wrong half the time. (TBC)
