SOIC, SOJ Tubes
These tubes are designed for SOIC and SOJ (Small Outline Gull wing and J-Bend) devices, covering Mini SOIC, 8 Pin SOIC, 150 Mil SOIC, 208 Mil SOIC/SOJ, 220 Mil SOIC/SOJ, 300 Mil SOIC/SOJ, 300 Mil SOJ, 330 Mil SOIC/SOJ, 400 SOJ, 450 SOY, and 525 SOZ body widths.
Where SOIC, SOJ Tubes Fits
These tubes are designed for SOIC and SOJ (Small Outline Gull wing and J-Bend) devices, covering Mini SOIC, 8 Pin SOIC, 150 Mil SOIC, 208 Mil SOIC/SOJ, 220 Mil SOIC/SOJ, 300 Mil SOIC/SOJ, 300 Mil SOJ, 330 Mil SOIC/SOJ, 400 SOJ, 450 SOY, and 525 SOZ body widths. SEWATE extrudes these tubes in PVC, PS, PC, PETG and ABS, from 50mm to 1000mm long and 0.30mm to 1.85mm thick. They provide anti-static protection for semiconductor integrated chips during shipping and long-term storage, with custom black conductive options available.
The Case for SOIC, SOJ Tubes
- Stable dimensions ensure reliable device loading and unloading
- Critical dimension control within 5 mils minimizes device jamming
- Good impact strength prevents tube cracking during handling
- Excellent smooth interfacing allows devices to slide without binding
- Supports a wide range of SOIC and SOJ package sizes
- Material options balance cost, clarity and impact resistance
Typical Uses for SOIC, SOJ Tubes
Shipping SOIC and SOJ devices from a component manufacturer to an assembly plant
Storing sensitive SOIC and SOJ components in a dry cabinet
Protecting devices during long-term storage in a warehouse
Feeding SOIC and SOJ devices into automated placement machines
Protecting devices during transport between assembly and test operations
The Buyer of SOIC, SOJ Tubes
- Semiconductor manufacturers shipping SOIC and SOJ devices
- IC distributors repackaging components for smaller customers
- EMS and SMT assembly plants receiving SOIC and SOJ devices
- Connector and relay manufacturers shipping surface mount components
- Purchasing teams seeking alternatives to existing tube suppliers
SOIC, SOJ Tubes Against the Failure Modes
- Devices jam inside tubes with inconsistent internal dimensions
- Electrostatic discharge damages sensitive SOIC and SOJ components
- Devices are damaged during shipping due to insufficient protection
- Manual handling of unpackaged devices is time consuming and prone to error
- Finding tubes that fit less common SOIC and SOJ package sizes
- Maintaining anti-static protection during long-term storage
Inside the SOIC, SOJ Tubes Specification
- Extruded plastic tubes designed for SOIC and SOJ packages
- Available in PVC, PS, PC, PETG and ABS materials
- Anti-static properties protect sensitive components
- Tube lengths from 50mm to 1000mm to match magazine pitch
- Wall thickness from 0.30mm to 1.85mm for varying levels of protection
- Critical dimension control within 5 mils on PVC tubes
SOIC, SOJ Tubes Data Sheet
Values are taken from the SEWATE product data for this item.
| Model Number | SE-IC-SOIC |
|---|---|
| Size | 50mm-1000mm as customized |
| Colour | Transparent, Blue,Red, Yellow and customized etc |
| Material | PVC / PS / PC / PETG / ABS |
| Thickness | 0.30mm-1.85mm |
| Application | ICs, relays, switches, connectors, sensors, toys, power modules, LEDs, medical instruments, etc |
| Certificates | RoHS |
| Payment Terms | T/T, L/C, etc |
| Capacity | 50000pcs/week |
| MOQ | 10000 pieces |
| Sample Time | 3-5 days or according to customers’ requirements |
| Lead Time | 5-15 days or depend on final quantity |
| Packaging Details | Cartons Or |
Choosing Material for SOIC, SOJ Tubes
- PVC provides good impact strength and is a cost-effective option
- PS is a halogen-free material with lower impact strength than PVC
- PC offers high performance and tight tolerances for critical applications
- PETG provides clarity and stable dimensions
- ABS offers high impact strength for robust protection
From Resin to Packed SOIC, SOJ Tubes
- Review of application requirements and tube functionality during quotation
- Drawing creation and approval before tooling
- Mould making and tooling trial
- Sample production with 20-50 free tubes for fit testing
- Extrusion of the approved profile and cutting to length
- Anti-static treatment if specified
- Packing into cartons
Inspection of SOIC, SOJ Tubes
- Critical dimension control within 5 mils on PVC tubes
- Fit testing of sample tubes against devices or drawings
- Inspection for defects and dimensional accuracy
- Quality management system to ISO14001
SOIC, SOJ Tubes Options
- Tube length cut to customer's required pitch
- Material selection from PVC, PS, PC, PETG or ABS
- Colour options including transparent, blue, red and yellow
- Anti-static treatment to meet specific requirements
- Custom packaging options available
When Not to Use SOIC, SOJ Tubes
| Tape and reel | Tubes accommodate larger SOIC and SOJ packages that cannot be tape and reeled |
|---|---|
| Vacuum formed trays | Tubes are more cost-effective for high-volume applications |
| Bulk packaging | Tubes provide physical protection and prevent electrostatic damage |
| Standard catalog tubes | Custom tubes offer a precise fit for specific device dimensions |
Handling and Storing SOIC, SOJ Tubes
- Provide a tube drawing, device drawing, or sample tube for accurate profiling
- Confirm tube length based on magazine or carton pitch
- Specify anti-static requirements for long-term storage
- Choose appropriate closure type based on application
- Store tubes flat and dry in cartons, away from direct sunlight
