ESD Plastic Tubes
ESD Plastic Tubes are extruded protective channels made from PVC, PS, PC, PETG, or ABS to hold electronic components in fixed orientation during shipping and handling.
ESD Plastic Tubes in One Paragraph
ESD Plastic Tubes are extruded protective channels made from PVC, PS, PC, PETG, or ABS to hold electronic components in fixed orientation during shipping and handling. They protect against electrostatic discharge, mechanical shock, dust, and moisture. Available in oval or square profiles with internal dimensions matched to the device body, they are used for through-hole, SMT, and leadless packages including QFN, MLF, LPCC, and others. Standard profiles are stocked with over a thousand open tools; custom profiles are made to drawing or sample. Tubes are cut to length from 50mm to 600mm and feature critical dimension control within 5 mils on PVC, and tighter +/-2 mils on PC tubes.
Why Buyers Specify ESD Plastic Tubes
- Protects components from ESD, dust, moisture, and mechanical damage during transit and storage
- Critical dimension control within 5 mils on PVC ensures consistent part flow without jamming
- Tighter +/-2 mil tolerance on PC tubes enables high-speed, unattended feeding with minimal scrap
- Oval or square profiles matched to device body prevent rotation, piggybacking, and shingling
- Available in multiple materials to balance cost, clarity, impact strength, and environmental impact
- Short lead time of 5-15 days for standard profiles allows fast replacement of stock tubes
- Custom profiles made from drawings or physical samples ensure perfect fit for unique device geometries
ESD Plastic Tubes on the Line
Shipping relays, switches, and connectors from a component manufacturer to an overseas EMS or SMT plant
Protecting QFN, MLF, and LPCC packages during transport where tape and reel is not feasible
Feeding MSOP and TSSOP devices into high-speed pick and place machines with minimal rework
Storing sensitive components in a warehouse between incoming inspection and production build
Re-packing bulk devices into fixed-count tubes for traceability and kitting
Using green materials like PS, PC, and PETG to meet environmental compliance requirements
ESD Plastic Tubes Is Built For
- IC distributors re-packaging bulk devices for their customers
- Semiconductor and passive component makers packaging finished goods
- EMS and SMT plants receiving tube-packed components and needing spares for rework
- Connector and relay manufacturers shipping large or heavy bodies that cannot fit in tape and reel
- Medical instrument and LED producers requiring ESD-safe packaging with visual inspection clarity
- Purchasing teams replacing a supplier whose tube profile no longer matches the device
What Goes Wrong Without ESD Plastic Tubes
- Devices jam or rotate inside tubes due to inconsistent internal profile or poor dimensional control
- Electrostatic discharge damages sensitive components during handling and transport
- Bulk-packed parts arrive in random orientation, increasing manual loading time and error risk
- Tubes crack on drop during transit, spilling components and risking contamination
- Standard stock tubes do not match custom device profiles, leading to feeder jams and line stops
- Anti-static performance degrades after repeated handling or wiping when surface treatment is used
Technical Detail of ESD Plastic Tubes
- Extruded oval or square internal profile matched to device body and lead span
- Anti-static protection via surface treatment or additives built into the resin
- Critical dimension control within 5 mils on PVC tubes; +/-2 mils on PC tubes
- Smooth internal surface to prevent binding and allow consistent part movement
- Good impact strength to resist cracking during carton handling and drop testing
- Available in transparent, blue, black, red, yellow, purple, or customized colors for line identification
- Optional rubber end plugs, plastic pins, nails, caps, or EPE plugs for closure
- Surface printing of part numbers, symbols, or handling marks available
- Compatible with tube feeders used in insertion and pick and place machines
The Numbers for ESD Plastic Tubes
Values are taken from the SEWATE product data for this item.
| Model Number | SE-IC-011 |
|---|---|
| Length | 50mm-600mm as customized |
| Wall Thickness | 0.30mm-1.85mm |
| Profile | Oval or square or customized |
| Material | PVC / PS / PC / PETG / ABS |
| Colour | Transparent, Blue, Black, Red, Yellow, Purple and customized etc |
| Dimension Control | Within 5 mils on PVC, +/-2 mils on PC |
| Certification | RoHS |
| MOQ | 10000 pieces |
| Sample Time | 3-5 days or according to customers’ requirements |
| Lead Time | 5-15 days or depending on quantity |
| Capacity | 50000 pcs per week |
| Supply Ability | Monthly output of final products is 150 tons |
| Payment Terms | T/T, L/C, etc |
| Application | ICs, relays, switches, connectors, sensors, toys, power modules, LEDs, medical instruments, etc |
Resins Used in ESD Plastic Tubes
- PVC provides high strength, good flexibility, stable geometry, and long storage life; standard choice for general-purpose ESD tubes
- PS is halogen free, low cost, and offers improved clarity and impact strength over some alternatives; suitable for environmentally sensitive applications
- PC is used when high impact strength, thermal stability, and tight dimensional tolerances are required, especially for MSOP and TSSOP packages
- PETG offers the strongest impact resistance and excellent clarity; ideal for heavy-duty or large packages like microprocessor heat sinks
- ABS is selected when maximum impact resistance is needed, though transparency is lower than other materials
Production Route for ESD Plastic Tubes
- Review of application requirements and tube functionality during quotation
- Drawing created from purchase order and sent for customer approval before tooling
- Mould making and tooling trial on the approved profile
- Sample production with 20-50 free tubes for fit testing on the actual device
- Extrusion of the approved profile followed by cutting to the ordered length
- Anti-static treatment applied via surface layer process or built-in additive as specified
- Plug fitting, counting, and packing into cartons or as per customer packaging requirements
How ESD Plastic Tubes Is Checked
- Critical dimension control within 5 mils on PVC tubes to prevent jamming
- Fit testing of sample tubes against the actual device or drawing before mass production
- Anti-static value verified to remain stable after handling and storage
- Drop and pressure tests performed on tube bodies before packing
- Quality management system compliant with ISO14001 with after-sales support on shipped lots
What Can Change on ESD Plastic Tubes
- Tube length customized from 50mm to 600mm to match magazine pitch or carton layout
- Internal profile designed from device drawing, tube drawing, or physical sample
- Material selected from PVC, PS, PC, PETG, or ABS based on cost, clarity, impact, and environmental needs
- Color chosen from transparent, blue, black, red, yellow, purple, or customized for traceability
- Anti-static method specified as surface treatment or additive-loaded resin based on storage and handling
- Surface printing of part numbers, symbols, or handling marks available
- Closure type selected from rubber end plugs, plastic pins, nails, plastic caps, or EPE plugs
Comparing ESD Plastic Tubes
| Tape and reel | Tubes handle larger, heavier, or leadless packages that tape pockets cannot support, but tape is better for high-volume SMD placement |
|---|---|
| Vacuum formed trays | Trays offer better protection for fragile or fine-pitch packages, but tubes are lower cost and load directly into tube feeders |
| Bulk bag packing | Tubes eliminate random orientation and ESD exposure, but cost more per unit than bulk bags |
| Standard stock tubes | Custom profiles require one-time tooling and 4-6 weeks lead time, but stock profiles ship in 5-15 days and fit only standard device geometries |
Working With ESD Plastic Tubes
- Provide a tube drawing, device drawing, or physical sample to define the internal profile
- If no drawing exists, send the physical component for profile measurement
- Confirm tube length against the magazine or carton pitch of your placement machine
- Specify storage duration and handling frequency to choose the right anti-static method
- Select closure type: rubber plugs for repeated use, pins for one-way shipping
- Store tubes flat and dry in cartons, away from direct sunlight to prevent deformation
- Plan for 4-6 weeks lead time and one-time tooling cost when designing a new custom profile
