QFN, MLF, LPCC Tubes
These tubes are designed for QFN, MLF, and LPCC devices, providing ESD protection during semiconductor packaging, storage, and shipping.
QFN, MLF, LPCC Tubes in One Paragraph
These tubes are designed for QFN, MLF, and LPCC devices, providing ESD protection during semiconductor packaging, storage, and shipping. SEWATE extrudes them in PVC, PS, PC, PETG and ABS, from 50mm to 1000mm long and 0.30mm to 1.85mm wall thickness, in oval or square profiles. The tubes protect components between the vendor and the pick and place machine, reducing damage from electrostatic discharge and mechanical shock.
Why Buyers Specify QFN, MLF, LPCC Tubes
- Stable dimensions improve unattended device loading and unloading
- Critical dimension control within 5 mils reduces scrap and rework
- Impact resistant material prevents device damage during transit
- Smooth internal interfacing allows devices to slide without binding
- Tube length from 50mm to 1000mm cut to your machine magazine pitch
- Wide material choice balances cost, clarity and environmental impact
QFN, MLF, LPCC Tubes on the Line
Shipping QFN, MLF, and LPCC components from a component plant to an EMS
Storing sensitive devices in a warehouse between incoming inspection and build
Protecting devices during transport between assembly and test operations
Re-packing bulk devices into a fixed count per tube for traceability
Providing ESD protection for components in a buffer stock against allocation risk
QFN, MLF, LPCC Tubes Is Built For
- Semiconductor and passive component makers packing their own finished goods
- IC distributors who repackage bulk devices for their customers
- EMS and SMT plants receiving tube-packed devices and needing spares
- Connector and relay manufacturers shipping small-form-factor components
- Purchasing teams replacing a tube supplier with inconsistent dimensions
What Goes Wrong Without QFN, MLF, LPCC Tubes
- Electrostatic discharge damages sensitive devices during transport and handling
- Devices jam during loading due to inconsistent tube dimensions
- Fragile components break during transit due to insufficient protection
- Bulk-packed parts arrive in random orientation and require manual loading
- A device body is too small or too delicate for tape and reel packaging
- Standard tubes do not fit the specific dimensions of QFN, MLF, or LPCC devices
Technical Detail of QFN, MLF, LPCC Tubes
- Oval or square extruded profile matched to the device body
- Anti-static properties protect devices from electrostatic discharge
- Critical dimension control within 5 mils on PVC tubes
- Material options include PVC, PS, PC, PETG, and ABS
- Available in transparent, blue, white, red, yellow, and purple
- Impact resistant material protects devices during handling and shipping
The Numbers for QFN, MLF, LPCC Tubes
Values are taken from the SEWATE product data for this item.
| Model Number | SE-IC-QFN, MLF, LPCC |
|---|---|
| Size | 50mm-1000mm as customized |
| Color | Transparent, Blue,white, Red, yellow, purple and customized etc |
| Material | PVC / PS / PC / PETG / ABS |
| Thickness | 0.30mm-1.85mm |
| Shape | Oval or square or customized |
| MOQ | 10000 pieces |
| Sample Time | 3-5 days |
| Capacity | 100000pcs/week |
| Monthly Output | 150 tons |
| Payment Terms | T/T, L/C |
Resins Used in QFN, MLF, LPCC Tubes
- PVC is a common default for strength, stability, and long storage life
- PS is halogen free and offers improved clarity and impact strength
- PC is chosen when tight tolerances are required for high-speed loading
- PETG is used where clarity and reduced environmental impact are priorities
- ABS provides good impact strength and is suitable for demanding applications
Production Route for QFN, MLF, LPCC Tubes
- Review of application requirements and tube functionality during quotation
- Drawing creation from purchase order and approval before tooling
- Mould making and tooling trial on the approved profile
- Sample production with free tubes for fit testing
- Extrusion of the approved profile and cutting to the ordered length
- Quality control checks to ensure dimensional accuracy and anti-static properties
- Packing into cartons according to customer requirements
How QFN, MLF, LPCC Tubes Is Checked
- Critical dimension control within 5 mils on PVC tubes
- Fit testing of sample tubes against the device or drawing
- Visual inspection for defects and dimensional accuracy
- Drop and pressure checks on the tube body
- ISO14001 quality management system
What Can Change on QFN, MLF, LPCC Tubes
- Tube length cut to your magazine or carton pitch from 50mm to 1000mm
- Internal profile designed from your tube drawing or a physical sample
- Material chosen from PVC, PS, PC, PETG, or ABS
- Colour chosen from transparent, blue, white, red, yellow, or purple
- Custom printing of symbols, part numbers, or handling marks
Comparing QFN, MLF, LPCC Tubes
| Tape and reel | Tubes accommodate larger and heavier components than tape pockets |
|---|---|
| Vacuum formed trays | Tubes are more cost-effective for high-volume applications |
| Standard stock tubes | Custom profiles offer a precise fit for specific device dimensions |
| Bulk bag packing | Tubes provide ESD protection and prevent device damage during transport |
Working With QFN, MLF, LPCC Tubes
- Provide a tube drawing, device drawing, or sample tube for profile matching
- Confirm length against the magazine on your insertion or placement machine
- Specify material based on cost, clarity, and impact needs
- Choose the appropriate closure for your application
- Store tubes flat and dry in the carton and avoid direct sunlight
- Allow 3-5 days for sample production and 5-15 days for standard orders
