DIP Shipping Tubes
DIP Shipping Tubes are extruded plastic channels designed for through-hole DIP packages with specific high and low profile dimensions including 300 Mil, 400 Mil, 600 Mil, 750 Mil, and 900 Mil variants.
Where DIP Shipping Tubes Fits
DIP Shipping Tubes are extruded plastic channels designed for through-hole DIP packages with specific high and low profile dimensions including 300 Mil, 400 Mil, 600 Mil, 750 Mil, and 900 Mil variants. They are available in PVC, PS, PC, PETG, and ABS materials, with wall thickness from 0.30mm to 1.85mm and lengths from 50mm to 1000mm. The tubes maintain device orientation from vendor to feeder, prevent ESD damage, and support high-speed automated loading. Critical dimension control is within 5 mils on PVC and +/- 2 mils on PC, ensuring consistent feed performance.
The Case for DIP Shipping Tubes
- High and low profile options match DIP package body height and lead span for secure fit
- Critical dimension control within 5 mils on PVC and +/- 2 mils on PC ensures reliable feeder feeding
- Wall thickness from 0.30mm to 1.85mm allows trade-off between cost and drop resistance
- Available in multiple materials to match environmental, clarity, and impact needs
- Lengths from 50mm to 1000mm cut to match magazine pitch or carton spacing
- Stock profiles ship in 5-15 days, reducing line stoppage risk during supply gaps
Typical Uses for DIP Shipping Tubes
Shipping DIP ICs, relays, switches, and connectors from a component plant to an overseas EMS
Feeding high-profile and low-profile DIP packages into automatic insertion machines
Storing DIP devices in a warehouse between incoming inspection and production build
Re-packing bulk DIP devices into fixed count tubes for kitting and traceability
Protecting long-lead DIP semiconductors in buffer stock against allocation risk
The Buyer of DIP Shipping Tubes
- IC distributors re-packaging bulk DIP devices for their customers
- Semiconductor and passive component makers packaging finished DIP goods
- EMS and SMT plants receiving DIP-packed devices and needing spares for re-work
- Relay, switch, and connector manufacturers shipping bodies too large for tape and reel
- Purchasing teams replacing a tube supplier whose profile no longer matches the DIP device
DIP Shipping Tubes Against the Failure Modes
- DIP devices jam mid-tube due to internal profile drift across a production run
- Electrostatic discharge damages sensitive DIP devices during transport and handling
- Bulk-packed DIP parts arrive in random orientation and require manual loading
- Tubes crack on drop in transit and spill devices inside the carton
- High or low profile DIP packages are too large or too heavy for tape and reel
- Anti-static performance degrades after wiping when surface treatment is used
Inside the DIP Shipping Tubes Specification
- High and low profile options for 300 Mil, 400 Mil, 600 Mil, 750 Mil, and 900 Mil DIP packages
- Internal profile matched to device body and lead span to prevent rotation or piggybacking
- Anti-static achieved by surface layer treatment or built-in additives in the resin
- Smooth internal surface for consistent device sliding without binding
- Good impact strength and drop resistance to survive carton handling
- Stable dimensions and consistent geometry across production runs
DIP Shipping Tubes Data Sheet
Values are taken from the SEWATE product data for this item.
| Model Number | SE-IC-DIP |
|---|---|
| Length | 50mm-1000mm or as customized |
| Wall Thickness | 0.30mm-1.85mm |
| Profile | High Profile and Low Profile DIP 300 Mil, 400 Mil, 600 Mil, 750 Mil, 900 Mil |
| Material | PVC / PS / PC / PETG / ABS |
| Colour | Transparent, Blue, Red, Yellow, Purple, and customized |
| Dimension Control | Within 5 mils on PVC, +/- 2 mils on PC |
| Certification | RoHS |
| MOQ | 10000 pieces |
| Sample Time | 3-5 days or according to customers’ requirements |
| Lead Time | 5-15 days or depend on final quantity |
| Capacity | 50000 pcs per week |
| Supply Ability | 150 tons per month |
| Packaging | Cartons or as customer requirement |
| Payment Terms | T/T, L/C, etc. |
| Place of Origin | Shenzhen, China |
Choosing Material for DIP Shipping Tubes
- PVC provides high strength, good flexibility, stable geometry, and long storage life; standard choice for DIP tubes
- PS is halogen free, low cost, and easy to process; offers improved clarity and impact strength over PVC
- PC is used when tight tolerances, high impact strength, or high-temperature resistance are required
- PETG offers the strongest impact strength and excellent clarity; ideal for heavy-duty or large packages
- ABS is selected when high impact resistance is needed and transparency is less critical
From Resin to Packed DIP Shipping Tubes
- Review of application requirements and tube functionality during quotation
- Drawing created from purchase order and issued for customer approval before tooling
- Mould making and tooling trial on the approved profile
- Sample production with 20-50 free tubes for fit testing on the actual DIP device
- Extrusion of the approved profile followed by cutting to ordered length
- Anti-static treatment applied via surface layer process or built-in additive as specified
- Plug fitting, counting, and packing into cartons according to customer needs
Inspection of DIP Shipping Tubes
- Critical dimension control within 5 mils on PVC and +/- 2 mils on PC ensures consistent device feed
- Sample tubes tested for fit against the actual DIP device before mass production
- Anti-static value verified to remain stable after handling and storage
- Drop and pressure tests performed on tube bodies before packing
- ISO14001 quality management system in place with after-sales support on shipped lots
DIP Shipping Tubes Options
- Profile selected from high or low profile DIP options: 300 Mil, 400 Mil, 600 Mil, 750 Mil, 900 Mil
- Internal profile designed from device drawing, tube drawing, or physical sample
- Material chosen from PVC PS PC PETG or ABS based on impact, clarity, and environmental needs
- Colour from transparent blue red yellow purple or customized for line identification
- Anti-static method specified as surface treatment or additive-loaded resin
- Length cut to match magazine pitch or carton spacing from 50mm to 1000mm
- Closure selected from rubber end plugs plastic pins nails plastic caps or EPE plugs
When Not to Use DIP Shipping Tubes
| Tape and reel | Tubes handle larger and heavier DIP packages that tape pockets cannot hold, but tape is better suited for high-volume SMD placement |
|---|---|
| Vacuum formed trays | Trays offer better protection for fragile or fine-pitch DIPs, but tubes are lower cost and load directly into tube feeders |
| Bulk bag packing | Tubes cost more per unit than bulk bags but eliminate random orientation, ESD exposure, and manual loading time |
| Standard stock tubes | Custom profiles require one-time tooling and 4-6 weeks lead time, while stock profiles ship in 5-15 days but only fit pre-defined devices |
Handling and Storing DIP Shipping Tubes
- Send a device drawing, tube drawing, or physical sample to match the internal profile
- If no drawing exists, send the physical DIP component for profile measurement
- Confirm length against the magazine pitch on your insertion or placement machine before tooling
- Specify storage duration and handling frequency to choose the right anti-static method
- Choose closure type: rubber plugs for repeated opening, pins for one-way shipping
- Store tubes flat and dry in cartons, avoid direct sunlight to prevent deformation
- Plan for one-time tooling cost and 4-6 weeks lead time when introducing a new custom profile
Related Products
Other items in the IC Tubes line that buyers compare with dip shipping tubes.
SOIC, SOJ Tubes
These tubes are designed for SOIC and SOJ (Small Outline Gull wing and J-Bend) devices, covering Mini SOIC, 8 Pin SOIC, 150 Mil SOIC, 208 Mil SOIC/SOJ, 220 Mil SOIC/SOJ, 300 Mil SOIC/SOJ, 300 Mil SOJ, 330 Mil SOIC/SOJ, 400 SOJ, 450 SOY, and 525 SOZ body widths.
View Details
IC Shipping Tubes
IC Shipping Tubes are extruded plastic channels designed to protect electronic components during transport and storage, preventing electrostatic discharge, mechanical shock, and environmental damage.
View Details
SOP, SSOP, TSSOP Tubes
SOP, SSOP, and TSSOP tubes are anti-static plastic shipping tubes designed for through-hole and surface-mount devices with narrow lead pitches and small body widths.
View DetailsRelated Guides
Background reading before you specify dip shipping tubes.
Materials For Anti Static IC Tubes
IC shipping tubes are made from several plastics including PVC, PS, PET, PC, and ABS.
Read Guide
Why IC Shipping Tube MOQ Is High
The minimum order quantity for custom anti-static IC shipping tubes is high because each production run requires machine re-molding, setup adjustment and dimensional verification.
Read Guide
How To Choose IC Tube Stoppers
An anti-static IC tube is a precision profile designed to hold components during transport and feeding.
Read GuideWhere It Is Used
Where dip shipping tubes is used in production.
Semiconductor And IC Distribution
IC distributors and semiconductor plants handle devices that are sensitive to electrostatic discharge, mechanical shock, and orientation changes during transit.
See ApplicationConnectors Relays And Switches
Connectors, relays, terminal blocks, switches and power modules are too large or heavy for standard tape and reel packaging.
See ApplicationWhat Buyers Ask About DIP Shipping Tubes
What is the minimum order quantity for DIP shipping tubes?
10000 pieces on standard profiles. The MOQ reflects extrusion setup cost; short runs are not economical due to changeover time and material waste.
How long does a stock tube order take?
5-15 days depending on quantity. Sample tubes for fit testing are delivered in 3-5 days.
What is the lead time for a custom DIP profile?
Basic low volume projects take 25-day ARO. Typical lead time is 4-6 weeks. Complex or high-volume tools take 10-12 weeks.
What do I need to provide to get a quote?
One of: a device drawing, tube drawing, or a physical sample. If none exists, send the actual DIP component for profile measurement.
Which material should I choose for my DIP tube?
PVC is standard for strength and stability. PS is halogen free and lower cost. PC offers tight tolerances and high impact. PETG has the strongest impact strength. ABS is used when impact resistance is critical.
Is the anti-static property permanent?
It depends on the method. Surface treatments can degrade with wiping or long storage. Additives built into the resin maintain anti-static performance longer. Specify your storage and handling needs.
Do the tubes come with plugs?
Yes. Rubber end plugs, plastic pins, nails, plastic caps, and EPE plugs are available and selected based on the tube profile and opening frequency.
Send the Device and Get DIP Shipping Tubes Quoted
A drawing, a sample or the physical component is enough. Sales and engineering come back within 24 hours.
