Installation Power And Shipping Checklist For Imported Converting Machines
What to confirm before a machine leaves China: voltage, compressed air, floor space, core size, documentation and the settings your operators will need.
Confirm Voltage And Frequency In Writing
Our machines are built for supplies such as 220 V / 50 Hz and 380 V / 50 Hz depending on the model, and cabinets are configured before crating. Confirm your actual plant supply, not the national standard, because plants often differ from it.
Check Compressed Air And Installed Power
Pneumatic machines need air supplied by the customer, for example about 0.8 MPa on the AQ-280 alcohol pad machine. Installed power ranges from 1.5 kW on an impulse sealer to 10 kW on a 3.2 m mulch line, so plan the supply from the machine specification rather than an estimate.
Plan Floor Space From The Layout Drawing
Machine footprints in our range run from about 2600 mm for a cotton pad machine to about 18 m for a mulch folding line. We send dimensioned layout drawings before shipment. Include space for roll handling and finished goods, not just the machine itself.
Match Core Size And Roll Diameter Before Shipment
Shaft core size, commonly 76 mm, and maximum roll diameter, commonly 1000 mm, have to match the material you buy locally. Confirming this before production avoids a machine that cannot accept your rolls.
Ask For The Settings Not Just The Manual
Operation and technical manuals are supplied in English. More useful on day one are the settings recorded during factory run-off on your own material: tension values, bonding parameters, fold sizes and speeds. Ask for them with the machine.
Machine Families In This Guide
Machines Mentioned Here
Impulse Sealing Machine
450 mm Impulse Sealing For PE And PP Packaging
Model AQ-450
Non Woven Mulch Machine
W Folding And Cutting Agricultural Mulch Up To 3.2 M Wide
Model AQ-G(3200)
Alcohol Pads Making Machine
Individually Sachet Packed Alcohol Pads With Touch Screen Liquid Dosing
Model AQ-280
Round Bottle Labeling Machine
Automatic Wrap Around Labeling For Round Bottles And Canisters
Model AQ-822BContinue Reading
How To Choose A Non Woven Slitting And Rewinding Machine
Five questions that decide which rewinder you should buy: jumbo roll width, finished roll format, material fam...
Tension Control Modes For Non Woven Converting Explained
Magnetic powder, lateral, conveyor belt and servo tension control: what each one does, and which non woven mat...
Ultrasonic Bonding Versus Sewing For Disposable Non Woven Products
Why disposable bed covers, dust bags, filters and glove liners moved from thread to ultrasonic welding, and wh...
Questions On This Topic
What documentation ships with the machine?
Operation and technical manuals in English, plus the recorded run-off settings where a customer material sample was supplied.
Do you support installation?
Yes, remotely through WhatsApp video or on site by arrangement. Layout, power and air requirements are sent before shipment.
What warranty applies?
One year on the machine. Wear parts such as blades, nozzles and belts are consumables and held in stock for fast dispatch.
Apply This To Your Own Line
Send your product and material details and we will tell you which machine and settings fit, with the specification in writing.
