Non Woven Fabric Inspection Machine
Unwind Inspect Count And Rewind Non Woven At Up To 120 M Per Minute
What This Machine Does
The AQ-I(1600) Non Woven Fabric Inspection Machine unwinds, inspects, counts and rewinds non woven web with neat side surfaces, at an effective breadth of 1650 mm. Automatic meter counting with infrared detection stops the machine at the set length, and step-less transmission lets the operator hold a comfortable inspection speed up to 100-120 m/min depending on the material. Four air cylinders handle pneumatic material feeding so jumbo rolls up to 800 mm diameter are loaded without a crane crew.
- Spunbond non woven
- Spunlace non woven
- Melt blown media
Why Buyers Choose This Model
Inspection and metering in one pass means defects are found before the material reaches converting
Automatic infrared counting and stop removes manual length measurement errors that cause short shipments
Step-less speed control lets the operator slow down over a suspect area without stopping the line
Knurled and plated rewinding rollers keep long service life under continuous use
Factories Running This Machine
- Non woven mills checking finished production
- Traders who must certify roll length and quality
- Converters protecting a high-speed downstream line from defects
- Medical disposable makers with incoming inspection requirements
What It Removes From Your Line
- Defects discovered only after material has been converted and value added
- Disputes over roll length between supplier and buyer
- Manual rewinding that damages edges and produces untidy side surfaces
- Inspection tables that cannot handle large jumbo rolls
Where This Machine Is Used
- Incoming inspection of purchased non woven jumbo rolls
- Outgoing quality check before shipping rolls to customers
- Length verification and re-rolling for trading companies
- Defect mapping before hygiene or medical converting
How The Machine Is Built
- Effective breadth 1650 mm
- Jumbo roll diameter up to 800 mm
- Inspection speed up to 100-120 m/min depending on raw material
- Rewinding diameter range 70-150 mm
- Automatic meter counting and stop with infrared technology
- Four air cylinders for pneumatic feeding, total power 3.5 kW, stainless steel and anti-rust surfaces
| Machine Model | AQ-I(1600) |
|---|---|
| Warranty Period | 1 year |
| Delivery Time | about 35 days |
| Customization | Yes (as your requests) |
| HS Code | 8451500000 |
Production Sequence On This Line
Pneumatic feeding
Unwinding
Inspection
Meter counting
Rewinding
What We Check Before Shipment
- Meter counter calibrated against a measured length before shipment
- Infrared stop function tested at full speed
- Roller surface and knurling inspected before crating
- Edge alignment of rewound rolls checked during run-off
What We Build To Your Specification
- Effective breadth built to your jumbo roll width
- Lighting arrangement of the inspection screen on request
- Counter unit set to metres or yards
- Voltage and frequency configured for your plant
Machine And Product Detail
Photographs taken in our own factory and of output produced on this machine family.
How This Model Compares
Compared With Slitting and rewinding machines
A slitter changes the roll width. This machine leaves the width alone and concentrates on inspection, metering and neat rewinding.
Compared With Manual inspection tables
A table shows the fabric but does not count length or rewind it. This machine returns a saleable, measured roll at the end of the check.
Setting The Machine For A Production Run
Load the jumbo roll with the pneumatic feeding cylinders
Set the target length on the meter counter and enable the infrared stop
Run at inspection speed and mark defects as the web passes the screen
Confirm rewind diameter is inside the 70-150 mm range before doffing
Industries Using This Machine
Further Reading
How To Choose A Non Woven Slitting And Rewinding Machine
Five questions that decide which rewinder you should buy: jumbo roll width, finished roll format, material fam...
Pocket Filter Pitch And Why Servo Registration Decides Filter Performance
Pocket pitch sets the filter surface area. Here is how registration drift changes a filter's rating and what h...
GSM Core Size And Roll Diameter What Your Machine Needs To Know
The four material figures every machine quotation depends on, and what happens when the material you actually ...
Other Machines In This Family
Non Woven Slitting And Rewinding Machine
Slit And Rewind Jumbo Non Woven Rolls Into Retail Size Without Telescoping
Model AQ-R(1800)
Non Woven Fabrics Slitting And Rewinding Machine
Adjustable Width Slitting With Automatic Tension Controlled Rewinding
Model AQ-FR
Woven Fabrics Slitting And Rewinding Machine
PP Woven And Non Woven Slitting With Four Selectable Tension Modes
Model AQ-R (1200-3500)
Non Woven Soft Towel Rewinding Machine
Soft Towel Rolls Rewound With Controlled Tension And Clean Perforation
Model AQ-FRNon Woven Fabric Inspection Machine FAQ
How fast can the machine inspect?
It reaches 100-120 m/min depending on the raw material. Lighter webs usually run at the upper end of that range.
What roll sizes does it take?
Effective breadth is 1650 mm, jumbo rolls up to 800 mm diameter are accepted, and rewinding diameter runs from 70 to 150 mm.
Does it stop automatically at a set length?
Yes. Automatic meter counting with infrared detection stops the machine when the set length is reached.
What is the installed power?
Total power is 3.5 kW. The frame uses stainless steel and anti-rust surface treatment for a clean inspection area.
Get A Quotation For The AQ-I(1600)
Tell us your finished product size, fabric weight, output target and voltage, and we confirm the Non Woven Fabric Inspection Machine specification, price and delivery.
