KY-PC-NT-BL Black Panel Mount Steel Keyboard With Trackball
KY-PC-NT-BL is a black stainless steel panel mount keyboard with an integrated trackball on a 330*100 mm front panel and a 354*124 mm body.
Product Overview
KY-PC-NT-BL is a black stainless steel panel mount keyboard with an integrated trackball on a 330*100 mm front panel and a 354*124 mm body. A 3mm aluminum back panel gives the vandal proof design its stiffness and the layout can be customized for free. It is used in medical equipment industrial facilities prisons food service and kiosk solutions.
- Compact 330*100 mm front panel carries both keys and the trackball
- 3mm aluminum back panel supports the vandal proof design
- Black keys can be laser marked while etching is possible for all colours
- Approvals cover RoHS IP65 FCC and CE
- Light 120g plus or minus 15g touch with operation force under 2N
- Rear mounting or front mounting for either fascia
Application Scenarios
- Medical equipment consoles
- Industrial facilities operator panels
- Prison and secure facility terminals
- Food service order and preparation stations
- Kiosk solutions in public spaces
- Terminals needing a dark fascia finish
Who It Is For
- Medical equipment manufacturers
- Secure facility equipment suppliers
- Food service terminal builders
- Kiosk and self service OEMs
Problems It Solves
- Separate keyboard and mouse do not fit a narrow fascia
- Bright steel keyboards clash with dark equipment styling
- Coloured legends are not possible with laser marking alone
- Unsupported panels flex and can be forced
Technical Features
- Front panel 330*100 mm with overall 354*124 mm
- Integrated trackball on a stainless steel panel mount keyboard
- DC5V plus or minus 5 percent supply with working current under 150mA
- Operation force under 2N at 120g plus or minus 15g
- Durability of at least 2Million operations
- Operation temperature -10 to 55 degrees C and storage -30 to 85 degrees C
Specifications
| Front Panel | 330*100 mm |
|---|---|
| Overall | 354*124 mm |
| Power Supply | DC5V±5% |
| Working Current | <150mA |
| Interface | USB、PS/2 |
| Operation Force | <2N 120g±15g |
| Durability | ≥2Million |
| Mounting Way | Rear Mounting or Front mounting |
| Back panel | 3mm Aluminum |
| Operation Temperature | -10℃~55℃ |
| Storage Temperature | -30℃~85℃ |
| Approval | RoHS、IP65、FCC、CE |
Materials
- Stainless steel panel
- Stainless steel keys
- 3mm aluminum back panel
Manufacturing Process
- Panel forming to the 330*100 mm face
- CNC punching of key apertures and the trackball seat
- Laser marking for black legends or etching for other colours
- 3mm aluminum back panel fitting
- Sealing assembly for the IP65 approval
- USB and PS/2 functional test
Quality Control
- Operation force checked at 120g plus or minus 15g
- Trackball tracking test on each unit
- Ingress check against the IP65 approval
- Legend contrast inspection on laser and etched keys
- Life sampling to at least 2Million operations
Approvals And Test Documentation
- RoHS
- IP65
- FCC
- CE
Customisation Options
- Free layout customization of the key field
- Laser marking for black legends or etching for any colour
- USB or PS/2 output
- Rear or front mounting build
- Panel fixing pattern to the enclosure
How It Compares
| KY-PC-D-BL | A 330*100 mm panel with an integrated trackball rather than the 66 key embedded layout |
|---|---|
| Laser marked only keyboards | Etching allows legends in all colours where laser marking covers black |
| Keyboard and mouse pairs | One 354*124 mm unit replaces both devices on a narrow fascia |
Use Guide
- Cut the fascia for the 330*100 mm front panel
- Allow 354*124 mm overall clearance
- Choose laser or etched legends by colour requirement
- Operate between -10 and 55 degrees C
- Supply DC5V plus or minus 5 percent
Related Products
Industrial Metal USB LED Backlit Keyboard KY-PC-F4-LED-BL
View Specification
KY-PC-DT-BL Panel Mount Stainless Steel Keyboard With Trackball
View Specification
KY-PC-MINI-T-BL Compact Stainless Steel Keyboard With Trackball
View Specification
KY-PC-NT340-BL Black Metal Keyboard With Touchpad Mouse
View SpecificationQuestions About This Model
What size is the panel?
Front panel 330*100 mm and overall 354*124 mm.
How are the legends marked?
Laser is used when the letter colour is black and etching is possible for all colours.
Which approvals apply?
RoHS IP65 FCC and CE.
What is the back panel?
A 3mm aluminum back panel forming part of the vandal proof design.
How is it mounted?
Rear mounting or front mounting.
What is the operation force?
Under 2N at 120g plus or minus 15g.
