KY-PC-DT-BL Panel Mount Stainless Steel Keyboard With Trackball
KY-PC-DT-BL is a panel mount stainless steel keyboard with an integrated trackball and a compact 392*110 mm front panel.
Product Overview
KY-PC-DT-BL is a panel mount stainless steel keyboard with an integrated trackball and a compact 392*110 mm front panel. A 3mm aluminium back panel gives the vandal proof structure needed in prisons, kiosks and food service sites. Approvals listed for the product are RoHS, IP65, FCC and CE.
- IP65 approval supports washdown and outdoor exposed installations
- 3mm aluminium back panel gives a vandal proof structure behind the keys
- Compact 392*110 mm front panel fits narrow kiosk fascias
- Trackball included so no external mouse is exposed to abuse
- Rear or front mounting lets you adapt to an existing enclosure
- Key labelling can be laser marked in black or etched in any colour
Application Scenarios
- Kiosk solutions in public halls and streets
- Prisons and secure facility terminals
- Food service ordering and kitchen stations
- Medical equipment operator panels
- Industrial facilities with washdown routines
Who It Is For
- Kiosk manufacturers needing a compact sealed keyboard
- Correctional and secure facility equipment suppliers
- Medical device and food service equipment OEMs
- Industrial facility maintenance and automation teams
Problems It Solves
- Sealed enclosures fail inspection when a non rated keyboard is fitted
- Externally connected mice are removed or damaged in secure sites
- Wide keyboards do not fit a narrow kiosk fascia
- Colour coded legends are not possible with laser marking alone
Technical Features
- Stainless steel panel mount keyboard with integrated trackball
- Front panel 392*110 mm with overall 416*134 mm
- 3mm aluminium back panel for vandal proof construction
- Power supply DC5V plus or minus 5 percent, working current under 150mA
- Operation force under 2N at 120g plus or minus 15g
- Durability of 2 million operations or more
- Rear mounting or front mounting
Specifications
| Front panel | 392*110 mm |
|---|---|
| Overall | 416*134 mm |
| Power supply | DC5V±5% |
| Working current | <150mA |
| Interface | USB, PS/2 |
| Operation force | <2N 120g±15g |
| Durability | ≥2Million |
| Back panel | 3mm aluminium |
| Mounting way | Rear Mounting or Front mounting |
| Operation temperature | -10℃~55℃ (Relative humidity 20%~85%) |
| Storage temperature | -30℃~85℃ |
| Approval | RoHS, IP65, FCC, CE |
Materials
- Stainless steel front panel and keys
- 3mm aluminium back panel
Manufacturing Process
- Stainless panel blanking to the 392*110 mm front size
- CNC machining of the compact key field and trackball aperture
- Aluminium back panel machining at 3mm thickness
- Laser marking for black legends or etching for other colours
- Sealing and assembly to meet the IP65 rating
Quality Control
- Sealing verified against the IP65 approval before dispatch
- Every key and the trackball tested on a live host
- Operation force sampled against the 120g±15g figure
- Panel and overall dimensions checked to 392*110 mm and 416*134 mm
Approvals And Test Documentation
- RoHS
- IP65
- FCC
- CE
Customisation Options
- Layout customized at no extra charge
- Laser procedure for key labeling when the letter colour is black
- Etching for key labels in all colours
- Rear or front mounting configuration
- USB or PS/2 interface selected at order
How It Compares
| Desktop metal keyboards | KY-PC-DT-BL mounts into the panel with an IP65 approval rather than sitting loose on a surface. |
|---|---|
| Keyboards with steel back plates | The 3mm aluminium back panel keeps the vandal proof structure without adding the weight of steel. |
| Keyboards without a pointer | The trackball is built into the same sealed panel, so no external mouse is exposed. |
Use Guide
- Machine the fascia for a 392*110 mm front panel with 416*134 mm overall clearance
- Choose rear or front mounting to suit the enclosure wall
- Seat the gasket evenly so the IP65 rating is maintained
- Connect by USB or PS/2 and test the trackball and all keys
- Operate within -10℃~55℃ and store within -30℃~85℃
Related Products
Industrial Metal USB LED Backlit Keyboard KY-PC-F4-LED-BL
View Specification
KY-PC-MINI-T-BL Compact Stainless Steel Keyboard With Trackball
View Specification
KY-PC-NT340-BL Black Metal Keyboard With Touchpad Mouse
View Specification
KY-PC-D-BL Black 66 Key Panel Mount Metal Keyboard
View SpecificationQuestions About This Model
What approvals does KY-PC-DT-BL carry?
The approvals listed are RoHS, IP65, FCC and CE.
What is behind the stainless panel?
A 3mm aluminium back panel provides the vandal proof structure.
Can it be front mounted?
Yes. Rear mounting or front mounting are both supported.
Can key legends be produced in colour?
Laser procedure is used when the letter colour is black, and etching is possible for all colours.
What is the operation force?
Operation force is under 2N at 120g±15g.
Where is it typically installed?
Kiosk solutions, prisons, food service, medical equipment and industrial facilities.
Request A Quote On KY-PC-DT-BL
Tell us quantity, interface and mounting method. Drawings and panel cutouts are welcome by WhatsApp or email.
