KY-PC-F1-LED Compact LED Stainless Steel Keyboard 319x135mm
KY-PC-F1-LED is a compact LED backlit stainless steel keyboard with a 319*135 mm front panel and 343*159 mm overall dimension. Its operating range starts at -20℃, which suits unheated outdoor kiosks and cold storage areas.
Product Overview
KY-PC-F1-LED is a compact LED backlit stainless steel keyboard with a 319*135 mm front panel and 343*159 mm overall dimension. Its operating range starts at -20℃, which suits unheated outdoor kiosks and cold storage areas. The water and vandal proof design carries ROHS, IP65, FCC and CE approvals.
- Operating temperature from -20℃ covers unheated outdoor and cold store kiosks
- LED backlight keeps the layout readable on unlit machines at night
- 319*135 mm front panel suits narrow vending and kiosk fascias
- IP65 approval allows exposure to splash and dust
- Durability ≥ 2Million supports continuous public operation
- Compact layout is customized for free with laser or etching labeling
Application Scenarios
- Kiosks and vending machines in unheated locations
- Industrial automation stations in cold plants
- Transportation and automotive service terminals
- Pharmaceutical, medical and healthcare kiosks
- Agricultural and oil and gas field equipment
- Self-service terminals operating overnight
Who It Is For
- Vending and kiosk manufacturers
- Cold climate terminal integrators
- Medical and pharmaceutical equipment OEMs
- Oil, gas and agricultural equipment suppliers
Problems It Solves
- Keyboards rated only to -10℃ fail in unheated outdoor cabinets
- Unlit keyboards cause entry errors on overnight machines
- Large keyboards do not fit narrow vending fascias
- Unsealed keyboards fail when rain or dust reaches the panel
Technical Features
- Stainless steel keyboard with LED and water and vandal proof design
- Front panel 319*135 mm and overall 343*159 mm
- Power supply DC5V±5% with working current <150mA
- Interface USB, PS/2 and RS232
- Durability ≥ 2Million
- Operating temperature -20℃~55℃
- Packing dimension 160*160*60mm
Specifications
| Front panel | 319*135 mm |
|---|---|
| Overall | 343*159 mm |
| Power supply | DC5V±5% |
| Working current | <150mA |
| Interface | USB, PS/2, RS232 |
| Durability | ≥ 2Million |
| Packing dimension | 160*160*60mm |
| Mounting way | Rear mounting or front mounting |
| Operating temperature | -20℃~55℃ (relative humidity 20%~85%, atmospheric pressure 60~106Kpa) |
| Storage temperature | -30℃~85℃ (relative humidity 5%~90%, atmospheric pressure 60~106Kpa) |
| Compatible systems | Windows XP, 7, 8, Linux, Ubuntu, Android |
| Approvals | ROHS, IP65, FCC, CE |
Materials
- Stainless steel front panel
- Stainless steel keys
- LED backlight layer
Manufacturing Process
- Sheet-metal forming of the 319*135 mm front panel
- Brushing of the stainless steel face
- Laser marking or etching of key labels
- LED backlight assembly
- IP65 sealing of the key field
- Low temperature function check
Quality Control
- Backlight output checked at low temperature
- IP65 sealing verified before packing
- Panel dimensions measured against 319*135 mm and 343*159 mm
- Full keymap tested on Windows and Linux hosts
Approvals And Test Documentation
- ROHS
- IP65
- FCC
- CE
Customisation Options
- Compact layout customized for free
- Laser or etching procedure for key labeling
- USB, PS/2 or RS232 interface build
- Rear or front mounting hardware
- Panel branding etched to artwork
How It Compares
| KY-PC-F2-LED | A smaller 319*135 mm front panel and a -20℃ lower limit suit narrow and colder installations |
|---|---|
| Non-backlit metal keyboard | The LED keeps legends visible on machines that run unattended after dark |
| Plastic vending keyboard | IP65 rated stainless steel resists the weather and handling that crack plastic fascias |
Use Guide
- Size the fascia aperture to the 343*159 mm overall dimension
- Confirm rear or front mounting before cutting the panel
- Supply DC5V±5% with at least 150mA available
- Operate within -20℃~55℃ and store within -30℃~85℃
- Keep the gasket seated to maintain the IP65 rating
Related Products
Questions About This Model
How cold can it operate?
Operating temperature runs from -20℃ to 55℃.
What are the panel dimensions?
Front panel 319*135 mm and overall 343*159 mm.
Is it backlit?
Yes, it is a stainless steel keyboard with LED.
Which approvals does it carry?
ROHS, IP65, FCC and CE.
Which interfaces are available?
USB, PS/2 and RS232.
How long do the keys last?
Durability is rated at ≥ 2Million operations.
Request A Quote On KY-PC-F1-LED
Tell us quantity, interface and mounting method. Drawings and panel cutouts are welcome by WhatsApp or email.
