C9300-48S-E
The Cisco Catalyst 9300 Series switches are Cisco's lead stackable enterprise switching platform built for security, IoT, mobility, and cloud. They ar
Cisco · Cisco Catalyst 9300
C9300L-24T-4G-E
Cisco Catalyst 9300 Series is the next generation of the industry's most widely deployed stackable switching platform. Built for security, IoT, and the cloud, these network switches form the foundation for Cisco's Software-Defined Access, Cisco's leading enter...
- Throughput
- 56 Gbps - 176 Gbps
- Stacking
- 320 Gbps
- MAC Table
- 32,000
- New factory sealed in the original vendor carton
- Serial list issued before shipment
- 12 months replacement warranty as standard
- Worldwide courier or freight from Hong Kong
Product Overview
C9300L-24T-4G-E Overview
Cisco Catalyst 9300 Series is the next generation of the industry's most widely deployed stackable switching platform. Built for security, IoT, and the cloud, these network switches form the foundation for Cisco's Software-Defined Access, Cisco's leading enterprise architecture. Cisco Catalyst 9300L switches are the Catalyst 9300 switches with fixed modules. The published specification for C9300L-24T-4G-E lists a published switching capacity of 56 Gbps - 176 Gbps. It is supplied new factory sealed, with the serial list issued before shipment and 12 months replacement warranty as standard.
Key Benefits
What Owning C9300L-24T-4G-E Changes
Rated Performance Written Into the Quotation
56 Gbps - 176 Gbps published for C9300L-24T-4G-E as its switching capacity, confirmed against the current datasheet revision when the line is quoted.
One Managed Unit Instead of Several
stacking bandwidth of 320 Gbps on this model lets a multi switch closet be configured monitored and upgraded as a single device, which cuts the work in every change window.
Table Sizes Checked Against the Design
A Total number of MAC addresses of 32,000 on this model, the kind of ceiling that only becomes visible once a flat segment has grown.
Serials Issued Before It Ships
The serial list for your C9300L-24T-4G-E consignment is released before despatch, so it can be checked on the manufacturer portal while the goods are still with us.
A Complete Bill of Materials
Modules optics rails and power options are reviewed against C9300L-24T-4G-E before the quotation is issued, so the install crew is not blocked by a line nobody costed.
Problems It Solves
Pain Points C9300L-24T-4G-E Removes
- Long factory lead times on a project already committed to a go live date
- Grey market stock that cannot be registered for support or warranty
- Port count and PoE budget that no longer cover new access points and cameras
- Network modules ordered late and delivered after the change window closed
- Performance taken from a family datasheet rather than from this part number, where the published switching capacity is 56 Gbps - 176 Gbps
Who It Is For
Who Benefits Most From C9300L-24T-4G-E
Campus Network Teams
Running one access standard across buildings of very different ages
Hosting Providers
Building repeatable nodes where every batch has to match the last one
Maintenance and Support Companies
Holding spares against generations the mainstream channel has already dropped
System Integrators
Bidding work that needs firm pricing and a written lead time before the end client is quoted
Specifications
C9300L-24T-4G-E Manufacturer Specification
As published by Cisco for this part number. Full electrical, port and performance specifications are issued with the quotation against the current datasheet revision.
| Designed to replace | Catalyst 3850 |
|---|---|
| Supported IOS | Network Advantage, Network Essentials |
| Network modules options | Fixed Modules |
| Stack Technology | StackWise-320 |
| Stacking bandwidth | 320 Gbps |
| Total number of MAC addresses | 32,000 |
| Total number of IPv4 routes (ARP plus learned routes) | 32,000 (24,000 direct routes and 8000 indirect routes) |
| IPv4 routing entries | - |
| IPv6 routing entries | 16,000 |
| Multicast routing scale | 8,000 |
| QoS scale entries | 5,120 |
| ACL scale entries | 5,120 |
| Packet buffer per SKU | 16 MB buffer for 24 and 48 port Gigabit Ethernet models |
| Flexible NetFlow (FNF) entries | 64,000 flow on 24- and 48-port Gigabit Ethernet models |
| DRAM | 8 GB |
| Flash | 16 GB |
| VLAN IDs | 4094 |
| Total Switched Virtual Interfaces (SVIs) | 1000 |
| Jumbo frames | 9198 bytes |
| Switching capacity | 56 Gbps - 176 Gbps |
| Forwarding rate | 41.66 Mpps - 130.95 Mpps |
Supply Terms
How C9300L-24T-4G-E Is Supplied
| Part Number | C9300L-24T-4G-E |
|---|---|
| Brand | Cisco |
| Category | Cisco Catalyst 9300 |
| Product Condition | New factory sealed |
| Serial Traceability | Full serial list supplied before shipment |
| Warranty | 12 months replacement plus optional vendor support contract |
| Packaging | Original vendor carton with export grade outer |
| Lead Time | Confirmed in writing per line at quotation |
| Delivery | Worldwide courier or freight from Hong Kong |
Comparison
C9300L-24T-4G-E Against Other Models in Cisco Catalyst 9300
Values are taken from each manufacturer specification. A blank means the manufacturer does not publish that attribute for that model.
| Attribute | C9300L-24T-4G-E | C9300-48S-E | C9300-48T-A | C9300-48T-E |
|---|---|---|---|---|
| Throughput | 56 Gbps - 176 Gbps | 640 Gbps | 256 Gbps on 48-port Gigabit Ethernet model | 256 Gbps on 48-port Gigabit Ethernet model |
| Stacking | 320 Gbps | Yes | Yes | Yes |
| MAC Table | 32,000 | - | 32,000 | 32,000 |
| Ports | - | 48x 5 Gbps UPOE ports (100M, 1G, 2.5G, 5G) | 48 | 48 |
| PoE Power | - | 645W | - | - |
| Uplinks | - | Modular Uplinks | - | - |
| Product page | View C9300L-24T-4G-E | View C9300-48S-E | View C9300-48T-A | View C9300-48T-E |
Use Guide
Deployment Guide for C9300L-24T-4G-E
Confirm the Full Part Number
Check C9300L-24T-4G-E character for character including any suffix. On this class of hardware a single trailing character commonly changes the software tier, the power option, or whether a bundle is included.
Check Site Prerequisites
Confirm rack space, power feed, cabling and any uplink or accessory dependency before the order rather than on the day of installation.
Record It on Arrival
Photograph the sealed carton, reconcile the serial against the list supplied before shipment, then open and confirm the unit matches the label.
Bench Power Before Racking
Power the unit, capture the software version and the port or drive inventory, and record it while the unit is still accessible.
Register Support Entitlement
Register the support contract under the end user name so the entitlement sits with the organisation that owns the outage.
Related Products
Other Models in Cisco Catalyst 9300
C9300-48T-A
The Cisco Catalyst 9300 Series Switches are Cisco's lead stackable enterprise switching platform built for security, IoT, mobility, and cloud. C9300-4
C9300-48T-E
The Cisco Catalyst 9300 Series Switches are Cisco's lead stackable enterprise switching platform built for security, IoT, mobility, and cloud. C9300-4
C9300-48U-A
The Cisco Catalyst 9300 Series Switches are Cisco's lead stackable enterprise switching platform built for security, IoT, mobility, and cloud. C9300-4
C9300-48U-E
The Cisco Catalyst 9300 Series Switches are Cisco's lead stackable enterprise switching platform built for security, IoT, mobility, and cloud. C9300-4
C9300-NM-2Q
C9300-NM-2Q is the support optional network modules for uplink ports of the Cisco Catalyst 9300 Series Switches. The default switch configuration does
C9300-NM-2Q=
C9300-NM-2Q= is the support optional network modules for uplink ports of the Cisco Catalyst 9300 Series Switches. The default switch configuration doe
C9300-NM-2Y
Catalyst 9300 2 x 25G Network Module. It is supplied new factory sealed, with the serial list issued before shipment and 12 months replacement warrant
Where It Goes
Industries That Deploy It
Healthcare
Hardware supplied with the traceability and change discipline a clinical environment requires.
Manufacturing and Logistics
Connectivity for plant floors, warehouses and distribution sites built for continuous operation rather than office hours.
Data Center
Top of rack switching, compute and storage delivered in the phased increments a cabinet build actually consumes.
Solutions
Programmes It Is Supplied Under
Network Refresh Programme
Most refresh projects fail on supply rather than on design. A phased programme only works if every phase arrives complete on the date the change window was booked.
Campus Wireless Deployment
Wireless projects are rarely stopped by the access point. They are stopped by a mount, a PoE class or a licence count that nobody confirmed before the order went out.
Data Center Switching Build
A cabinet is commissioned as a unit, so it should be supplied as one. Switches, optics, rails and power leads belong in the same consignment.
Reference
Project Cases and Guides
University Campus Wi-Fi Density Upgrade
Lecture theatres and the library could not carry the client counts actually present, while the work could only happen during vacations
System Integrator Data Center Tender
The tender required a firm price and date at submission, months before any award, across a bill of materials of several hundred lines
How to Read Cisco Catalyst Part Numbers
A Catalyst part number encodes the port count, the port type, the uplink arrangement and the software tier. Misreading one character changes what arrives.
PoE Budget Planning for Access Switches
Port count and power budget are two separate limits. Most PoE shortfalls come from planning only the first one.
Choosing Optical Transceivers for Reach
Coding, fibre type, reach and connector are four independent decisions, and any one of them can stop a link coming up.
FAQ
C9300L-24T-4G-E Frequently Asked Questions
Is C9300L-24T-4G-E New or Refurbished
Standard supply is new factory sealed in the original vendor carton. If a quotation offers another condition that is stated explicitly in writing before you commit.
Can I Get the Serial Numbers for C9300L-24T-4G-E Before Payment Clears
Yes. Serials are issued before shipment so you can check them on the manufacturer portal while the goods are still with us.
What Is the Lead Time for C9300L-24T-4G-E
Availability is confirmed in writing per line at quotation rather than as a project average, because one late line is what moves an installation date.
What Warranty Does C9300L-24T-4G-E Carry
12 months replacement as standard. A vendor support contract is available separately and is registered under the end user name.
What Performance Is C9300L-24T-4G-E Rated For
The published switching capacity is 56 Gbps - 176 Gbps. Full port and performance specifications are issued with the quotation against the current datasheet revision.
Can C9300L-24T-4G-E Be Stacked With Other Switches
The manufacturer lists stacking bandwidth of 320 Gbps for this model. Stacking cables are a separate line and are quoted with the switches so a multi switch closet arrives complete.
What Table Sizes Does C9300L-24T-4G-E Carry
The published Total number of MAC addresses is 32,000. Table ceilings usually only become visible once a flat segment has grown, so they are worth checking against the design rather than against today's estate.
Can You Ship C9300L-24T-4G-E to My Country
Yes. Consignments go worldwide by courier or freight from Hong Kong, with the routing chosen against the destination clearance regime and your deadline.
Can You Drop Ship C9300L-24T-4G-E to My Customer
Yes. Consignments can be released directly to an end customer address under your own documentation.
Request Pricing for C9300L-24T-4G-E
Send the quantity and destination country. Availability and lead time come back in writing, with the serial list before shipment.
