600MM Steel Sphere Water Fountain World Map
600mm(24″) Stainless Steel Sphere Water Fountain World Map
- Material
- 304 stainless steel, 316 stainless steel
- Diameter
- 600mm
- Thickness
- 1mm
- Finish
- Brushed, Mirror Polished, Sandblasting
- Weight
- 40 kg
- Packed dimensions
- 98 × 98 × 106 cm
- Minimum order
- 1 piece on this category unless a small-size minimum applies
- Lead time
- 1 to 3 days from stock, 7 to 15 days for scheduled production
Product Overview
A sphere water feature is a hollow steel ball sitting on a pedestal tube with water rippling and flowing over the mirror surface. Ours are made from AISI 304 or AISI 316 stainless steel.
An inner pipe runs through the ball and ends in a funnel at the top. That funnel is what makes the flow even, so the water sheets over the whole sphere rather than running down one side. The pipe exits at the bottom, usually with a further 10 inch length, and attaches to a square stainless base plate for mounting.
Key Benefits
- Durable AISI304 stainless steel alloy water pressured with sandblasted world Map.
- Inner water flow tube welding with funnel.
- Easy Installing with tube base.
- MOQ:1PCS.
- Delivery Time:7days for Scheduled production.
Application Scenarios
- City squares and public plazas
- Shopping centres and lobbies
- Science museums and tourist destinations
- Gardens and courtyards
Who It Is For
- Landscape architects designing plaza and garden water features
- Shopping centre and hotel developers
- Science museums and visitor attractions
- Private garden clients through their contractor
Problems It Solves
- Water running down one face instead of sheeting evenly. The funnel top fixes the flow distribution.
- Mounting a heavy wet sphere. A square base plate and extended pipe are built into the assembly.
- Water marks on a mirror finish. A brushed surface hides mineral deposits and adds texture.
Technical Features
- Wall thickness available: 1mm
- Diameter: 600mm
- Surface finish options: Brushed, Mirror Polished, Sandblasting
- Alloy: 304 stainless steel, 316 stainless steel
- Drilling and tapping in metric and unified threads on request
- Base plates, pedestal tubes and hanging fittings fabricated with the piece
- Sheet development calculated in house, so non-standard sizes are possible above ∅200mm
Specifications
- Weight
- 40 kg
- Dimensions
- 98 × 98 × 106 cm
- Diameter (Mm)
- 600mm
- Thickness
- 1mm
- Material
- 304 stainless steel, 316 stainless steel
- Finish
- Brushed, Mirror Polished, Sandblasting
Category range: Material AISI 304 / AISI 316 stainless steel · Construction Internal pipe with funnel top, bottom outlet, square base plate · Common finish Mirror polished or brushed
Materials
We form spheres and hemispheres in AISI 304, AISI 316 and AISI 316L stainless steel, Q235 carbon steel, H62 brass alloy and A6061 aluminium alloy. The alloy decides corrosion resistance, weight and how the surface takes a polish.
For this product the standard specification is 304 stainless steel, 316 stainless steel. Tell us the site conditions and we will confirm whether a different grade is worth the cost.
Manufacturing Process
Forming happens by stamping press, water pressuring, spinning or hand assembling. Two halves are joined at the equator, the weld is ground, and the surface is finished last, after any cutting or drilling has been done.
Quality Control
Incoming material
Alloy and sheet thickness are checked against the order before any blank is cut.
Forming check
Diameter and wall are measured after pressing, spinning or water pressuring.
Weld and grind
The equator weld is inspected, then welds and burrs are ground off before finishing.
Surface inspection
Every piece is inspected for scratches, dents and polish consistency under light.
Packing
Protective packing is built around the diameter and weight, and photographs are sent before dispatch.
Customisation Options
- Diameter and wall thickness to your drawing, with no mould limit above ∅200mm
- Metric and unified threaded holes, drilled apertures and perforated patterns
- Welded base tubes, base plates, internal ribs and pedestals
- Mirror, brushed, sandblasted, etched, electroplated, PVD colour or spray painted finishes
- Logos, lettering and world maps by sandblasting, etching, laser cutting or plasma cutting
- LED kits fitted inside the sphere
- Segmentation into quarters or eighths for sizes above container limits
Comparison With Other Products
| Product | Material | Diameter | Thickness |
|---|---|---|---|
| 600MM Steel Sphere Water Fountain World Map | 304 stainless steel, 316 stainless steel | 600mm | 1mm |
| 1000mm Hollow Ball Fountain Stainless Steel Sphere Water Feature | — | Made to order | — |
| 150mm-800mm Stainless Steel Ball Water Fountain | — | Made to order | — |
Comparing forming routes rather than products? The process guide sets out size, thickness, seam and mould limit for each.
Use Guide
Confirm the diameter first
Diameter drives the forming route, the wall thickness, the price and the freight mode. Settle it before anything else.
Match the alloy to the site
304 inland, 316 near salt water or pools, Q235 where a rust patina is wanted, brass or aluminium where weight or colour matters.
Choose the finish last
Finishing always happens after forming, welding, cutting and grinding, so pattern edges stay clean.
Plan the fixing
Tell us whether the piece is bolted, threaded, welded to a base tube or suspended, and we build the fitting into the part.
Check the shipping limit
∅2200mm fits a container, ∅3500mm fits a flat rack, and larger spheres are segmented with bolted ribs.
FAQ
Do you supply the pump?
Mirror or brushed for a fountain?
Can I order 600MM Steel Sphere Water Fountain World Map in a different size?
How is it packed and shipped?
What do you need from me to quote?
Related Products
1000mm Hollow Ball Fountain Stainless Steel Sphere Water Feature
Made to order
150mm-800mm Stainless Steel Ball Water Fountain
Made to order
800mm Silver Ball Water Feature
800mm
Brushed Stainless Steel Sphere Water Feature
Made to orderRelated Cases
Related articles
Industry applications
Order 600MM Steel Sphere Water Fountain World Map
Send the diameter, wall thickness, finish and quantity. Drawings are welcome and quotations usually come back the same working day.
