Buses and Coaches application for vehicle camera systems

Industry Application

Buses and Coaches

Interior Door and Flank Views for Passenger Vehicles

Get A Custom Solution See All Products

Industry Pain Points

What Goes Wrong in This Sector

Pain Points

  • The driver cannot see the rear saloon, the boarding door and the near side flank at once
  • Interior cameras that look intrusive create passenger complaints
  • Connectors on a bus run long cable lengths and work loose with vibration
  • Retrofit work has to be done between services with no time for rework

What Buyers Need

  • Dome housings that are discreet in a passenger saloon
  • Screw locking connectors suitable for long cable runs
  • A 7 inch screen large enough for a switched multi camera view
  • A camera range where the flank, rear and interior parts come from one supplier

Recommended Products

Parts That Answer These Problems

Each product page sets out the mounting position it was designed for and the specification we publish.

Dome Camera - Ceiling Mount Dome With a 4 Pin Aviation Connector Vehicle CamerasDome CameraCeiling Mount Dome With a 4 Pin Aviation Connector View Product Mini Dome Camera - Compact Interior Dome With RCA and DC Leads Vehicle CamerasMini Dome CameraCompact Interior Dome With RCA and DC Leads View Product Side Camera - Wedge Housing Camera for Corner and Kerb Side Views Vehicle CamerasSide CameraWedge Housing Camera for Corner and Kerb Side Views View Product Vehicle Side Camera - Smooth Wedge Housing for Exposed Flank Positions Vehicle CamerasVehicle Side CameraSmooth Wedge Housing for Exposed Flank Positions View Product 7 Inch Vehicle Monitor - 7 Inch Commercial Vehicle Display for Multi Camera Systems Vehicle Monitors7 Inch Vehicle Monitor7 Inch Commercial Vehicle Display for Multi Camera Systems View Product Backup Camera - Heavy Duty Bracket Camera for Trucks Trailers and Machines Vehicle CamerasBackup CameraHeavy Duty Bracket Camera for Trucks Trailers and Machines View Product

Typical Scenarios

Typical Application Scenarios

  • Watching the boarding door while the driver is selling tickets
  • Reversing a coach into a stand at a terminal
  • Covering the near side flank when pulling away from a stop
  • Monitoring a luggage bay during loading

Solution Flow

Solution Process From Survey to Rollout

  1. 01

    Map the views

    Decide which views the driver needs live and which are for recording only.

  2. 02

    Choose interior housings

    Full size dome for saloons with a headliner, mini dome where clearance is tight.

  3. 03

    Plan the cable runs

    Route to the driver area and confirm connector type for the run length.

  4. 04

    Fit and commission one vehicle

    Set screen switching and camera angles on a single vehicle first.

  5. 05

    Repeat across the fleet

    Order the fleet quantity with matched cameras monitors and cables.

Delivery Capability

What We Can Deliver

  • Dome cameras supplied with 4 pin aviation or RCA termination as required
  • Monitors and cameras dispatched as a matched set
  • OEM and ODM service on housing colour and cable length
  • IP68, CE, FCC, RoHS and E-mark certificates held on the product range

See the Supply Programme

Solutions

Solutions That Apply Here

SolutionOEM and ODM ManufacturingYour Brand Built on a Product Line Running Since 2005SolutionCamera and Monitor System MatchingOne Supplier for the Camera the Screen and the Cable Between ThemSolutionSourcing and Supply ProgrammeFrom First Sample to Repeat Container Orders

Knowledge

Related Knowledge Articles

Design GuideRCA and 4 Pin Aviation Connectors ExplainedTwo connector standards dominate vehicle camera systems. Choosing the wrong one for the vehicle is the most common cause of an installation that has to be redone.TroubleshootingWhy a Reversing Monitor Shows No ImageWork from the screen back to the camera, not the other way round. Most no image faults are found in the first two checks.Material GuideIP68 and What Waterproof Ratings Actually MeanThe two digits in an IP code describe different things. Knowing which digit matters for your mounting position is the difference between a camera that lasts and one that does not.

FAQ

Buses and Coaches FAQ

Which cameras do you recommend for buses and coaches?

The recommended products on this page are the starting point. The final answer depends on the mounting positions available on your vehicles and how many views the driver needs live, so send photos of the vehicle and we will match the housings.

Can you supply cameras, monitors and cables as one order?

Yes, and it is the recommended way to buy. Sourcing the whole chain from one supplier removes connector and signal format mismatches that otherwise appear at fitting.

Do you support retrofit programmes across a whole fleet?

Yes. The usual sequence is to prove one vehicle first, then place the fleet order together with a spares holding of cameras and cables.

What are your export terms?

Payment by T/T, shipment by express, air, land or sea, with sea shipments loading at Shenzhen or Guangzhou. Our products are already exported to Europe, America, Southeast Asia and most of the Middle East.

Next Step

Specify a System for Buses and Coaches

Send the vehicle types and the views you need covered. We will match the housings, the screen and the cable lengths.
