EPC Type TransducerT1500 Electro Pneumatic Transducer Order
A catalogue order across the three standard output ranges of the T-1500.
Marsh Bellofram Type Transducer Standard range T-1500, 3-15, 3-27 and 6-30 psig outputs
What The Customer Needed
Space was the constraint. The positions available would not take a full-size transducer, and the ports had to be reachable after mounting because the installation left no room to work behind the instrument.
How It Was Built
The T-1500 has a small footprint and carries supply and output ports on both the front and the back of the unit, so it can be plumbed from whichever side the installation leaves free.
What The Photographs Show
Units were calibrated after mounting orientation was fixed, since the datasheet asks for calibration after mounting. Unused ports were plugged before despatch.
How It Finished
Instruments that fitted the positions available and could still be piped and adjusted once they were in place.
The Models Behind This Order
Marsh Bellofram Type TransducerT1500 Electro Pneumatic Transducer
Compact force balance transducer, manifold mountable, 3-15 to 6-30 psig
View specifications →
Marsh Bellofram Type TransducerT1000 Electro Pneumatic Transducer
Force balance I/P transducer with a built-in volume booster, four build classes
View specifications →
Marsh Bellofram Type TransducerT1500 Electro Pneumatic Converter
Zero based T1500 build, 0-15 to 0-120 psig, regulates down to 0 psig
View specifications →
Controlair Type Transducer500X Electro Pneumatic Transducer
Controlair pattern I/P transducer, 4-20 mA in, 3-15 to 3-120 psi out
View specifications →Questions About OEM Orders
Can this configuration be supplied under our own brand
Yes. Nameplates are printed to customer artwork and part numbering and checked against the build before fitting.
How is a batch kept consistent
The whole quantity is built in one run and calibrated consecutively on the same bench against the same standard current generator and 0.1 class pressure gauge.
What is the specification on this order
Standard range T-1500, 3-15, 3-27 and 6-30 psig outputs.
Can we order a different range in the same body
Yes. The published selection table or coding system for this pattern lists the available input signals, output ranges and terminations.
Order The Same Configuration
Send the range, the termination and the quantity, and the quotation comes back against the published selection table for this pattern.
