EPC Type TransducerT1500 Electro Pneumatic Transducer OEM Order
An OEM batch of the compact T-1500 built for a customer who assembles multi-loop cabinets.
Marsh Bellofram Type Transducer Standard range T-1500, customer branded, manifold-ready
What The Customer Needed
The customer mounts several transducers on one manifold. Units that vary slightly in calibration behaviour make a manifold assembly harder to commission than the same number of separate instruments.
How It Was Built
The batch was built and calibrated as a set, and supplied with the customer's nameplate. DIN rail and manifold assemblies are available in kits providing three, five or ten mounting points, which is how the customer builds them.
What The Photographs Show
Calibration was performed with the units grouped as they would be mounted, so that the set was verified in the configuration it would ship in.
How It Finished
Manifold sets that commissioned as a group rather than unit by unit.
The Models Behind This Order
Marsh Bellofram Type TransducerT1500 Electro Pneumatic Transducer
Compact force balance transducer, manifold mountable, 3-15 to 6-30 psig
View specifications →
Marsh Bellofram Type TransducerT1000 Electro Pneumatic Transducer
Force balance I/P transducer with a built-in volume booster, four build classes
View specifications →
Marsh Bellofram Type TransducerT1500 Electro Pneumatic Converter
Zero based T1500 build, 0-15 to 0-120 psig, regulates down to 0 psig
View specifications →
Controlair Type Transducer500X Electro Pneumatic Transducer
Controlair pattern I/P transducer, 4-20 mA in, 3-15 to 3-120 psi out
View specifications →Questions About OEM Orders
Can this configuration be supplied under our own brand
Yes. Nameplates are printed to customer artwork and part numbering and checked against the build before fitting.
How is a batch kept consistent
The whole quantity is built in one run and calibrated consecutively on the same bench against the same standard current generator and 0.1 class pressure gauge.
What is the specification on this order
Standard range T-1500, customer branded, manifold-ready.
Can we order a different range in the same body
Yes. The published selection table or coding system for this pattern lists the available input signals, output ranges and terminations.
Order The Same Configuration
Send the range, the termination and the quantity, and the quotation comes back against the published selection table for this pattern.
