EPC Type Transducer550ACD Electro Pneumatic Transducer Order
A catalogue order for the 4-20 mA to 3-15 psig miniature transducer with a DIN connector.
Controlair Type Transducer 550-A-C-D configuration for a standard 20-100 kPa spring
What The Customer Needed
The valves in question sit on a 20-100 kPa spring, which is exactly what the C output code covers, but earlier replacements had been fitted with the wrong output range and the valves were not reaching full travel.
How It Was Built
Ordering by code rather than by description fixed the problem: A for the 4-20 mA input, C for the 3-15 psig output, D for the connector. The spring and the output range were matched on paper before anything was built.
What The Photographs Show
The batch was calibrated to 3-15 psig and then checked for full travel against a test actuator, since an output range that does not suit the spring shows up as incomplete stroke rather than as a calibration error.
How It Finished
Valves reaching full open and full close, with the selection fault removed at the order stage.
The Models Behind This Order
Controlair Type Transducer550ACT Electro Pneumatic Transducer
550-A-C-T built configuration: 4-20 mA, 3-15 psig, terminal block
View specifications →
Controlair Type Transducer500X Electro Pneumatic Transducer
Controlair pattern I/P transducer, 4-20 mA in, 3-15 to 3-120 psi out
View specifications →
Controlair Type Transducer500X Electro Pneumatic Converter
Controlair pattern E/P converter, 0-5 V, 1-9 V and 0-10 V inputs
View specifications →
Controlair Type Transducer500AC Electro Pneumatic Transducer
500-AC configuration, 4-20 mA in, 3-15 psi out, 180 ohms
View specifications →Questions About OEM Orders
Can this configuration be supplied under our own brand
Yes. Nameplates are printed to customer artwork and part numbering and checked against the build before fitting.
How is a batch kept consistent
The whole quantity is built in one run and calibrated consecutively on the same bench against the same standard current generator and 0.1 class pressure gauge.
What is the specification on this order
550-A-C-D configuration for a standard 20-100 kPa spring.
Can we order a different range in the same body
Yes. The published selection table or coding system for this pattern lists the available input signals, output ranges and terminations.
Order The Same Configuration
Send the range, the termination and the quantity, and the quotation comes back against the published selection table for this pattern.
