Triangle Belt FOR Circular Knitting Machines

Toothed timing belts, punched belts and joint or jointless TT5 belts that drive the positive feeders around the machine.

Part groupBelt Series
Supplied byHUAXIATEX, Beijing

Request a Quote Email Us

Send a photo of the old part beside a ruler and we will confirm the match before you order.

Product Overview

Triangle Belt FOR Circular Knitting Machines is listed in our belt series group for circular knitting machine maintenance. Toothed timing belts, punched belts and joint or jointless TT5 belts that drive the positive feeders around the machine.

What This Part Does

The feeder drive belt sets the delivery rate of every positive feeder on the machine, so its pitch, width and length have to match the machine and the feeders. TT5 is a common tooth pitch on circular knitting machines, and belts are supplied either as a continuous loop or with a joint.

Punched belts are used where the belt has to engage feeder wheels through holes rather than teeth. Belt length is normally quoted in millimetres, which is why references such as 10TT5 8600 carry both the width and the length.

Key Benefits

Correct pitch and length for the feeder drive, so delivery rate is what it was set to
Joint and jointless options
Punched belt types for machines that need them
Belt references quoted with width and length so reordering is unambiguous

Application Scenarios

Positive feeder drives on single and double jersey machines
Machines with two belt layers
Belt replacement during planned machine service

Who It Is For

Maintenance teams on a planned belt change cycle
Mills chasing feeder delivery variation
Machine dealers refitting used machines

Problems It Solves

Feeder slip and weight variation from a stretched or worn belt
Belt jumping teeth on the drive pulley
Wrong belt length ordered because only the width was quoted

Specifications

Specifications for Triangle Belt FOR Circular Knitting Machines
Product name	Triangle Belt FOR Circular Knitting Machines
Part group	Belt Series
Machine type	Circular knitting machines
Supplier	Beijing Huaxiatex Co. Ltd., Beijing, China
Listed reference photo	Supplied from our own product records

Only values printed on the product name and in our own records are listed here. Dimensions, material and hardness are confirmed against your machine before you order, not assumed.

What to Send Us When You Order

Belt reference from the old belt, for example the width and length markings
Tooth pitch and belt width
Belt length in millimetres, measured around the machine if the old marking is unreadable
Whether you need a jointless loop or a jointed belt

Chat on WhatsApp

Use Guide

Confirm the reference against the old part and the machine plate before ordering a full machine set.
Order one complete set per machine where the part is fitted in multiples, so wear is even across the fabric.
Clean the mounting position before fitting. Fly and old oil are the most common cause of a new part not seating.
Check the machine on a short run and measure the fabric before returning it to full production.
Record the reference against the machine so the next reorder does not have to be identified again.

Belt Series Questions

What does a reference like 10TT5 8600 mean?

It reads as belt width, tooth pitch type and belt length in millimetres. Quote the full marking from the old belt and the replacement will match.

How do I measure belt length if the marking is gone?

Measure the path the belt takes around the machine with a tape, following the same route as the belt, and tell us the machine diameter as a cross check.

Jointed or jointless?

A jointless loop runs more smoothly. A jointed belt is easier to fit on some machine layouts. Tell us which the machine currently uses.
