Carbon Fiber Prototypes
Full carbon fiber samples that carry the strength and stiffness of the production part, not just its shape.
Every Carbon Prototypes Product in This Category
2 products in this category, each with a full specification table, manufacturing route and application notes.
Carbon Fiber Structural Arm
A full carbon fiber arm made as a verification sample, carrying the strength and stiffness of a production composite part so the structure can be tested before a mould is cut.
View details
Carbon Fiber Gasket
A real carbon fiber gasket produced to a dimensional tolerance of plus or minus 0.01 mm, so it can form part of a small high-precision assembly rather than a loose fit-check.
View detailsWhy Buyers Come to This Range
A printed or machined plastic sample tells you nothing about how a composite part will behave under load. Verification needs a sample in the real material.
Who It Suits
- Structural engineers validating stiffness before tooling
- Teams that need an assembly-grade sample at plus or minus 0.01 mm
- Projects where the sample has to survive real testing
Where Carbon Prototypes Parts Are Used
Robotics and Automation
A variety of high strength structural parts are made from carbon fiber composite combined with traditional metal materials. In automation the argument is cycle time: less moving mass means faster acceleration and less residual vibration.
About 40 per cent lighter airframesUAV and Drone
Carbon fiber parts reduce airframe weight by about 40 per cent against traditional materials, which largely increases the duration of flight while high strength keeps the platform stiff and stable.
Bicycles, scooters and sports goodsSports and Leisure Equipment
Carbon fiber bike and scooter products are one of the four main product groups CarbonWizer builds, alongside drone, auto and medical accessories, and industrial and consumer electronics components.
What CarbonWizer Brings to This Category
Nine Moulding Routes
Compression moulding, autoclave, roll wrapping, vacuum infusion and five more, chosen by the part rather than by habit.
In-House Tooling
Mould design and making sit in the same one-stop service as design, model making and spray finishing.
Verified Before Tooling
Structural samples in the real material prove strength and precision before a mould is cut.
Sample in One Week
Sample orders normally ship within one week; normal production orders take 15 to 25 days.
Projects Built From This Range
Carbon Fiber Drone Parts Programme
Carbon fiber drone parts is one of the success case areas developed by the CarbonWizer team, spanning six-rotor and four-rotor airframes, aerial and police drone platforms.
Read the case
Carbon Fiber Bicycle Programme
Carbon fiber bike is one of the success case areas developed by the CarbonWizer team, covering aerodynamic road bicycle frames and components.
Read the case
Industrial and Electronics Parts
Industrial and electronics parts is one of the success case areas developed by the CarbonWizer team, covering wallets and key cases, signal transceivers, watch dials, motorcycle tail boxes, phone cases, headset caps, laptop cases and equipment containers.
Read the caseQuestions About Carbon Fiber Prototypes
Do I need a mould for this sample?
No. In the design and verification phase the arm is produced without opening a mould, which is what allows structure and precision to be checked before tooling is committed.
Will the sample behave like the production part?
It is made from full carbon fiber material and carries the strength and rigidity of a carbon fiber part, so it can be used as an industrial article for testing and use.
What tolerance can you hold?
Where the drawing calls for it, the part is produced to a dimensional tolerance of plus or minus 0.01 mm, which lets it form part of a high-precision assembly.
Do I have to pay for a proofing mould first?
No. The part can be opened without proofing and can still be mass produced afterwards.
How quickly can you deliver carbon fiber prototypes?
Sample orders are usually shipped out within one week and normal orders take 15 to 25 days. Delivery after despatch depends on the shipping method chosen.
Get a Quote for Carbon Fiber Prototypes
Email the drawing, the quantity and the finish you need. If the part is not in the catalogue it is quoted against your geometry.
