2M 5M 12M Graphics Accelerated SONY Microscope Camera

Name: 2M 5M 12M Graphics Accelerated SONY Microscope Camera
Brand: AMADA Microscope

The 2M 5M 12M Graphics Accelerated SONY Microscope Camera series includes three models with SONY sensors: AT2.0 (2MP), AT5.0 (5MP), and AT12.0 (12MP).

Request A Quote Ask An Engineer

Product Overview

The 2M 5M 12M Graphics Accelerated SONY Microscope Camera series includes three models with SONY sensors: AT2.0 (2MP), AT5.0 (5MP), and AT12.0 (12MP). Each model uses a C Mount optical interface and connects via USB2.0 to transfer image data and power. The cameras support 30fps at 2MP, 25fps at 5MP, and 15fps at 12MP, with auto or manual exposure control. They are designed for use with stereo, biological, and digital microscopes in inspection, documentation, and teaching environments.

ModelAT2.0, AT5.0, AT12.0
Sensor ModelSONY
Sensor Size1/2.9", 1/2.8", 1/2.33"
Resolution2MP (1920x1080), 5MP (2560x1920), 12MP (4000x3000)
Pixel Size2.8um x 2.8um, 2.0um x 2.0um, 1.34um x 1.34um
Color/MonoColor

Email For Price Compare In USB2.0 CMOS Microscope Camera

Key Benefits

2MP, 5MP, and 12MP resolution options to match inspection detail needs
SONY sensors with pixel sizes from 2.8um to 1.34um for improved light sensitivity and image clarity
USB2.0 interface powers the camera and transfers data, reducing cabling complexity
Rolling shutter type with frame rates up to 30fps at 2MP for smooth live viewing
Supports TIFF, JPG, PNG, and DICOM formats for image storage and compatibility with lab systems

Application Scenarios

Documenting solder joints and PCB defects with high-resolution images for quality reports
Capturing detailed views of biological specimens in teaching labs using 12MP resolution
Integrating with a microscope stand for real-time inspection in electronics rework
Using DICOM output for medical or clinical imaging applications requiring standard file formats
Combining multiple images with Mosaic V2.0 software for large-area inspection

Who It Is For

Electronics manufacturers doing PCB and SMD inspection
Teaching and research laboratories requiring image documentation
Clinical and veterinary labs using digital imaging for specimen analysis
Quality control departments needing consistent image capture for audits
Microscopy users integrating cameras into existing microscope systems

Problems It Solves

A microscope without a camera requires manual sketching or verbal description of defects
Low-resolution cameras fail to capture fine details in solder joints or microstructures
Separate power supplies and data cables increase setup complexity and cable clutter
Lack of DICOM support limits compatibility with medical or regulated lab systems
Fixed frame rates at high resolution cause lag during live inspection

Technical Features

SONY sensor with 1/2.9", 1/2.8", and 1/2.33" sizes across the three models
C Mount optical interface for direct attachment to microscope bodies
USB2.0 interface provides both data and power, eliminating need for external supply
Rolling shutter type with adjustable exposure mode: auto or manual
Frame rates of 30fps at 2MP, 25fps at 5MP, and 15fps at 12MP
Supports image formats: TIFF, JPG, PNG, DICOM
Operating temperature: 0 degC to 60 degC; storage: 10 degC to 40 degC
Humidity range: 10%-85% operating, 10%-70% storage
Camera size: 68x68x42.5mm; weight: 253g for all models

Specifications

Model	AT2.0, AT5.0, AT12.0
Sensor Model	SONY
Sensor Size	1/2.9", 1/2.8", 1/2.33"
Resolution	2MP (1920x1080), 5MP (2560x1920), 12MP (4000x3000)
Pixel Size	2.8um x 2.8um, 2.0um x 2.0um, 1.34um x 1.34um
Color/Mono	Color
Shutter Type	Rolling Shutter
Frame Rate	30fps @ 2MP, 25fps @ 5MP, 15fps @ 12MP
Exposure Mode	Auto / Manual
Picture Format	TIFF, JPG, PNG, DICOM
Operating System	Windows 7/8/10 (32 Bit/64 Bit)
PC Software	Mosaic V2.0
SDK	C/C++, C#, Directshow
Optical Interface	C Mount
Data Interface	USB2.0
Operating Temperature	0 degC - 60 degC
Storage Temperature	10 degC - 40 degC
Operating Humidity	10% - 85%
Storage Humidity	10% - 70%
Camera Size	68 x 68 x 42.5 mm
Camera Weight	253g

Specifications are taken from the AMADA product data for this item. Confirm critical dimensions with us in writing before ordering.

Customization Options

Choose between 2MP, 5MP, or 12MP models based on required resolution
Use C Mount interface to attach to any standard microscope with matching thread
Select frame rate and exposure mode to match inspection speed and lighting
Use Mosaic V2.0 software to stitch multiple images into a single high-resolution output
Integrate with C/C++, C#, or Directshow SDKs for custom inspection software

Comparison With Other Options

Standard USB2.0 CMOS microscope camera without SONY sensor	The SONY sensor provides better light sensitivity and lower noise, especially in low-light conditions, improving image quality at higher magnifications.
Camera with USB3.0 interface	This camera uses USB2.0, which limits maximum data transfer and frame rate at high resolution, but ensures compatibility with older systems and reduces cost.
Monochrome camera	This model is color, so it captures full color information, but may have lower sensitivity than a monochrome version under low light.

Use Guide

Ensure the microscope has a C Mount thread to attach the camera directly
Connect the camera to a USB2.0 port; the camera draws power from the same cable
Use Mosaic V2.0 software to combine multiple images for large-area inspection
Set exposure mode to manual if lighting is inconsistent across the field of view
Adjust frame rate based on inspection need: use 30fps for live viewing, 15fps for high-res capture
