Process
How It Runs, Step by Step
Send what you have
A physical sample, a drawing, a 3D file or a clear dimensioned photograph. A sample is enough on its own.
Review
Wall section, draft, flange flatness and machining allowance are reviewed against the casting method proposed.
Choose the method
Die casting, sand casting or gravity casting, depending on volume, wall section and surface requirement.
Tooling
Tooling built to the agreed method. Tooling cost, lead time and ownership are agreed in writing before work starts.
First article
A first sample is produced and measured against the reference before any series run.
Series production
Released only after the first article is signed off.
Finishing
Chrome plating and vacuum metallization are listed among the processes available where the part calls for them.
Delivery
Packed to the specification agreed for the programme.
Outcome
A part that did not exist in the catalogue, produced from what you already have on the bench.
Every figure and capability named on this page is one RUIFAN recorded on its original site. Where a detail was never recorded, it is agreed per programme rather than stated here.
What the factory records
- Founded 1994 in Ruian, Zhejiang
- Stated annual oil pan output of 500,000 pieces
- Quality systems recorded as ISO 9001 and TS 16949
- Deep and shallow draw stamping; die, sand and gravity casting
- Chrome plating and vacuum metallization
- Development of oil pans and aluminum castings from customer samples or drawings
Background Reading
Oil Pan Sealing Surface and Gasket Basics
Flange flatness, gasket choice and torque sequence — why most replacement pans that leak were fitted, not made, badly.
Sourcing Replacement Oil Pans for Distribution
A buyer's checklist for adding an oil pan programme: number coverage, identification evidence, packing, and the questions to ask before the first container.
What Is an Oil Pan
What an oil pan is, where it sits on the engine and what it does — the original RUIFAN explainer, kept as it was published in 2009.
Questions About Custom Aluminum Casting
How long does custom aluminum casting take?
Lead time was not recorded in the archived catalogue and is confirmed per programme, because it depends on whether tooling exists, how many references are in the order and where it is shipping.
What do you need from us to start?
For catalogue references, the number list, quantities and destination market. For anything not in the catalogue, a sample, a drawing or a dimensioned photograph.
Who owns the tooling?
Tooling cost, lead time and ownership are agreed in writing before any work begins. Nothing on that is assumed.
Can this run alongside a catalogue order?
Yes, and it usually should. Consolidating is what makes low-volume references economic to produce and to ship.
What quality systems apply?
ISO 9001 and TS 16949 are the systems RUIFAN recorded on its original site. Certificate numbers and validity dates are supplied on request.
Start With Custom Aluminum Casting
Send what you have — a number list, a drawing or a sample. We will tell you what the catalogue covers and what needs tooling.
