Plastic Packaging Tubes
Plastic Packaging Tubes are extruded protective channels for electronic components, designed to prevent electrostatic discharge, mechanical shock, and environmental damage during transport and storage.
What Plastic Packaging Tubes Actually Is
Plastic Packaging Tubes are extruded protective channels for electronic components, designed to prevent electrostatic discharge, mechanical shock, and environmental damage during transport and storage. SEWATE manufactures them in PVC, PS, PC, PETG, and ABS, with internal profiles matched to through-hole, SMT, and leadless devices such as QFN, MLF, and LPCC. Tubes are available in lengths from 50mm to 1000mm, wall thicknesses from 0.30mm to 1.85mm, and can be customized to exact device dimensions. Anti-static performance is achieved through surface treatment or built-in additives, ensuring protection throughout handling and storage.
What Plastic Packaging Tubes Buys You
- Prevents ESD damage to sensitive components during shipping and handling
- Critical dimension control within 5 mils on PVC tubes reduces jamming and feeder stoppages
- Tight tolerance of +/- 2 mils on PC tubes enables high-speed, unattended feeding without misalignment
- Stable geometry and smooth internal surface allow parts to slide without binding
- Available in multiple materials to match impact, clarity, and environmental requirements
- Short lead time of 5-15 days for standard profiles supports fast replenishment
Where Plastic Packaging Tubes Is Used
Shipping relays, switches, and connectors from a component manufacturer to an overseas EMS
Protecting power modules and sensors during long-distance transport and warehouse storage
Feeding QFN, MLF, and LPCC packages into high-speed placement machines with minimal rework
Re-packing bulk components into fixed-count tubes for traceability and kitting
Using PC tubes with tight tolerances to reduce scrap and downtime in automated assembly lines
Protecting heavy-duty packages like ceramic TO and microprocessor heat sinks with PETG tubes
Who Buys Plastic Packaging Tubes
- IC distributors re-packaging bulk components for their customers
- Semiconductor and passive component makers shipping finished goods
- EMS and SMT plants receiving tube-packed parts and needing spares for rework
- Connector and relay manufacturers handling large or heavy bodies unsuitable for tape and reel
- Medical instrument and LED producers requiring ESD-safe packaging with visual inspection clarity
- Purchasing teams replacing a supplier whose tube profile no longer matches the device
Problems Plastic Packaging Tubes Removes
- Devices jam mid-tube due to dimensional drift in the internal profile across a production run
- Electrostatic discharge damages components during manual handling and transit
- Bulk-packed parts arrive in random orientation, increasing operator time and error risk
- Tubes crack on drop during carton handling, spilling components and causing contamination
- Large or heavy packages like TO and QFN bodies cannot fit into standard tape pockets
- Anti-static performance degrades after wiping or long storage when only surface treatment is used
How Plastic Packaging Tubes Is Built
- Extruded internal profile matched to device body and lead span for secure fit
- Anti-static by surface layer process or built-in additives, selected for storage duration
- Critical dimension control within 5 mils on PVC tubes and +/- 2 mils on PC tubes
- Smooth internal surface and stable geometry prevent binding and part rotation
- Good impact strength and drop resistance maintain integrity after carton handling
- Available in transparent, blue, black, red, yellow, purple, or customized colors for line ID
Plastic Packaging Tubes Specification
Values are taken from the SEWATE product data for this item.
| Model Number | SE-IC-006 |
|---|---|
| Length | 50mm-1000mm as customized |
| Wall Thickness | 0.30mm-1.85mm |
| Material | PVC / PS / PC / PETG / ABS |
| Colour | Transparent, Blue, Black, Red, Yellow, Purple and customized etc |
| Dimension Control | Within 5 mils on PVC, +/- 2 mils on PC |
| Certification | RoHS |
| MOQ | 10000 pieces |
| Sample Time | 3-5 days or according to customers’ requirements |
| Capacity | 50000 pcs per week |
| Supply Ability | Monthly output of finished products 150 tons |
| Payment Terms | T/T |
| Place of Origin | Shenzhen, China |
| Application | ICs, relays, switches, connectors, sensors, toys, power modules, LEDs, medical instruments, etc |
| Lead Time | 5-15 days depending on quantity |
Material Choice for Plastic Packaging Tubes
- PVC offers high strength, good flexibility, stable geometry, and long storage life; standard choice for most applications
- PS is halogen free, low cost, and improves clarity and impact strength; suitable for general-purpose packaging
- PC provides tight dimensional tolerance of +/- 2 mils, high impact strength, and clarity; ideal for MSOP and TSSOP packages
- PETG has the strongest impact resistance and excellent transparency; used for heavy-duty and large packages
- ABS is selected for high impact strength and durability, though less transparent than other materials
How Plastic Packaging Tubes Is Made
- Review of application requirements and tube function during quotation
- Drawing created from purchase order and sent for customer approval before tooling
- Mould making and tooling trial on the approved profile
- Sample production with 20-50 free tubes for fit testing on the actual device
- Extrusion of the approved profile followed by cutting to the ordered length
- Anti-static treatment applied via surface layer process or built-in additive as specified
- Closures fitted (rubber plugs, plastic pins, nails, caps, or EPE plugs), counted, and packed into cartons
Quality Control on Plastic Packaging Tubes
- Critical dimension control within 5 mils on PVC tubes and +/- 2 mils on PC tubes to prevent jamming
- Fit testing of sample tubes against the actual device or drawing before mass production
- Anti-static value verified to remain stable after handling and storage
- Drop and pressure tests performed on tube bodies before packing
- Quality management system to ISO14001 with after-sales support on shipped lots
Customising Plastic Packaging Tubes
- Tube length cut to match magazine pitch from 50mm to 1000mm
- Internal profile designed from device drawing, tube drawing, or physical sample
- Material selected from PVC, PS, PC, PETG, or ABS based on impact, clarity, and environmental needs
- Colour chosen from transparent, blue, black, red, yellow, purple, or customized for line identification
- Anti-static method specified as surface treatment or additive-loaded resin for long-term stability
- Surface printing of part numbers, symbols, or handling marks available
- Closures selected from rubber end plugs, plastic pins, nails, plastic caps, or EPE plugs
Plastic Packaging Tubes Against the Alternatives
| Tape and reel | Tubes handle larger and heavier bodies that tape pockets cannot hold, but tape is better suited for high-volume SMD placement |
|---|---|
| Vacuum formed trays | Trays offer better protection for fragile or fine-pitch packages, but tubes cost less per unit and load directly into tube feeders |
| Bulk bag packing | Tubes cost more per unit than bulk bags but eliminate random orientation, ESD exposure, and manual loading time |
| Standard stock tubes | Custom profiles require one-time tooling and 4-6 weeks lead time, but stock profiles ship in 5-15 days and fit only pre-defined devices |
Using Plastic Packaging Tubes
- Send a tube drawing, device drawing, or physical sample so the internal profile can be matched
- If no drawing exists, send the physical component for profile measurement
- Confirm tube length against the magazine pitch on your insertion or placement machine
- Specify storage duration and handling frequency to select the right anti-static method
- Choose closure type: rubber plugs for repeated opening, pins for one-way shipping
- Store tubes flat and dry in cartons, away from direct sunlight to prevent deformation
- Plan for one-time tooling cost and 4-6 weeks lead time when introducing a new custom profile
