ESD Shipping Tubes
ESD shipping tubes are extruded plastic channels designed to protect electronic components from electrostatic discharge, mechanical shock, and environmental damage during transport and storage.
ESD Shipping Tubes in One Paragraph
ESD shipping tubes are extruded plastic channels designed to protect electronic components from electrostatic discharge, mechanical shock, and environmental damage during transport and storage. SEWATE manufactures them in PVC, PS, PC, PETG, and ABS, with oval or square profiles matched to device bodies, from 50mm to 1000mm in length and 0.30mm to 1.85mm wall thickness. The tubes provide consistent internal dimensions with critical control within 5 mils on PVC and +/-2 mils on PC, ensuring reliable feeding into automated assembly machines. Anti-static properties are achieved through surface treatment or additives built into the resin, maintaining protection over handling and storage.
Why Buyers Specify ESD Shipping Tubes
- Protects components from ESD, dust, and mechanical shock from vendor to assembly line
- Critical dimension control within 5 mils on PVC and +/-2 mils on PC ensures consistent feeding
- Oval or square profiles matched to device body prevent rotation and piggybacking
- Tight tolerances on PC tubes reduce machine downtime and rework
- Wall thickness from 0.30mm to 1.85mm allows trade-offs between cost and impact resistance
- Stock profiles ship in 5-15 days, minimizing line stoppages during supply gaps
ESD Shipping Tubes on the Line
Shipping relays, switches, and connectors from a component plant to an overseas EMS or SMT line
Protecting power modules, sensors, and medical instruments during long-distance transport
Holding QFN, MLF, LPCC, MSOP, and TSSOP packages with tight tolerance requirements
Storing high-value ICs and passive components in a warehouse with controlled ESD conditions
Re-packing bulk devices into fixed-count tubes for traceability and kitting
Using green materials like PS PC and PETG to meet environmental compliance goals
ESD Shipping Tubes Is Built For
- IC distributors repackaging bulk devices for their customers
- Semiconductor and passive component manufacturers shipping finished goods
- EMS and SMT plants receiving tube-packed components and needing spares for rework
- Connector and relay manufacturers handling large or heavy bodies unsuitable for tape and reel
- Purchasing teams replacing a supplier whose tube profile no longer matches the device
What Goes Wrong Without ESD Shipping Tubes
- Devices jam mid-tube due to inconsistent internal dimensions across a production run
- Electrostatic discharge damages sensitive components during handling and transit
- Random orientation of bulk-packed parts increases manual loading time and error risk
- Tubes crack on drop during transit, spilling contents and risking contamination
- Large or heavy packages like TO-220 or ceramic modules cannot be held in standard tape pockets
- Anti-static performance degrades after repeated wiping or long storage with surface-only treatment
Technical Detail of ESD Shipping Tubes
- Oval or square extruded profile matched to device body and lead span
- Anti-static achieved by surface layer process or additives built into the resin
- Critical dimension control within 5 mils on PVC and +/-2 mils on PC
- Smooth internal surface prevents binding and ensures consistent sliding
- Good impact strength maintains tube integrity after carton handling
- Available in transparent, clear, or translucent finishes for visual inspection
The Numbers for ESD Shipping Tubes
Values are taken from the SEWATE product data for this item.
| Model Number | SE-IC-002 |
|---|---|
| Wall Thickness | 0.30mm-1.85mm |
| Profile | Oval or square or customized |
| Material | PVC / PS / PC / PETG / ABS |
| Colour | Transparent, clear, translucent |
| Dimension Control | Within 5 mils on PVC, +/-2 mils on PC |
| Certification | RoHS |
| MOQ | 10000 pieces |
| Sample Time | 3-5 days or according to customers’ requirements |
| Lead Time | 5-15 days or depend on final quantity |
| Capacity | 50000 pcs per week |
| Supply Ability | 150 tons per month |
| Packaging | Cartons or as customer requirement |
| Payment Terms | T/T, L/C, etc. |
| Place of Origin | Shenzhen, China |
Resins Used in ESD Shipping Tubes
- PVC provides high strength, good flexibility, stable geometry, and long storage life; standard choice for general use
- PS is halogen free, offers improved clarity and impact strength, and reduces environmental impact
- PC delivers tight tolerances of +/-2 mils, high impact strength, and superb clarity, ideal for MSOP and TSSOP packages
- PETG offers the strongest impact resistance and excellent transparency, suitable for heavy-duty and large packages
- ABS is used when high impact strength is needed, though it is less transparent than other options
Production Route for ESD Shipping Tubes
- Review of application requirements and tube function during quotation
- Drawing created from purchase order and issued for customer approval before tooling
- Mould making and tooling trial on the approved profile
- Sample production with 20-50 free tubes for fit testing on the actual device
- Extrusion of the approved profile followed by cutting to the ordered length
- Anti-static treatment applied via surface layer process or built-in additive as specified
- Fitting of closures (rubber plugs, plastic pins, nails, caps, EPE plugs) and packing into cartons
How ESD Shipping Tubes Is Checked
- Critical dimension control within 5 mils on PVC and +/-2 mils on PC to prevent feeding issues
- Fit testing of sample tubes against the device or drawing before mass production
- Anti-static value verified to remain stable after handling and storage
- Drop and pressure tests performed on the tube body before packing
- Quality management system compliant with ISO14001, with after-sales support on shipped lots
What Can Change on ESD Shipping Tubes
- Tube length cut to match your magazine or carton pitch, from 50mm to 1000mm
- Internal profile designed from your tube drawing, device drawing, or physical sample
- Material selected from PVC PS PC PETG or ABS based on cost, clarity, and impact needs
- Colour chosen from transparent clear or translucent for line identification and inspection
- Anti-static method specified as surface treatment or additive-loaded resin for long-term stability
- Surface printing of part numbers symbols or handling marks available
- Closure type selected from rubber end plugs plastic pins nails plastic caps or EPE plugs
Comparing ESD Shipping Tubes
| Tape and reel | Tubes handle larger and heavier bodies that tape pockets cannot hold, but tape is better suited for high-volume SMD placement |
|---|---|
| Vacuum formed trays | Trays offer better protection for fine-pitch and fragile packages, but tubes cost less per unit and load directly into tube feeders |
| Bulk bag packing | Tubes cost more per unit than bulk bags but eliminate random orientation ESD exposure and reduce manual loading time |
| Standard stock tubes | Custom profiles require one-time tooling and 4-6 weeks lead time, but stock profiles ship in 5-15 days and fit only pre-defined device types |
Working With ESD Shipping Tubes
- Send a tube drawing, device drawing, or physical sample so the internal profile can be matched
- If no drawing exists, send the physical component for profile measurement
- Confirm tube length against the magazine pitch on your insertion or placement machine before tooling
- Specify whether anti-static must survive repeated wiping and long storage to select the right treatment
- Choose closure type based on tube usage: rubber plugs for repeated opening, pins for one-way shipping
- Store tubes flat and dry in cartons, away from direct sunlight to prevent deformation
- Plan for one-time tooling cost and 4-6 weeks lead time when introducing a new custom profile
