Anti-Static IC tubes for IC, SOP,DIP,TO-220,PLCC
Anti-Static IC Tubes are extruded plastic channels designed for packaging through-hole and surface-mount electronic components including ICs, SOP, DIP, TO-220, and PLCC packages.
Anti-Static IC tubes for IC, SOP,DIP,TO-220,PLCC in One Paragraph
Anti-Static IC Tubes are extruded plastic channels designed for packaging through-hole and surface-mount electronic components including ICs, SOP, DIP, TO-220, and PLCC packages. They maintain device orientation from the component vendor to the pick and place machine, preventing jamming and misfeeds. SEWATE produces them in PVC, PS, PC, PETG, and ABS with oval or square profiles, wall thickness from 0.30mm to 1.85mm, and lengths from 50mm to 1000mm. Anti-static protection is achieved through surface treatment or built-in additives, ensuring ESD protection during handling, transport, and storage.
Why Buyers Specify Anti-Static IC tubes for IC, SOP,DIP,TO-220,PLCC
- Maintains fixed orientation of ICs, SOP, DIP, TO-220, and PLCC devices from vendor to feeder
- Anti-static protection via surface layer or additive in resin, stable over handling and storage
- Critical dimension control within 5 mils on PVC, and +/- 2 mils on PC for tight tolerance
- Wall thickness from 0.30mm to 1.85mm allows trade-off between cost and impact resistance
- Tubes cut to exact pitch matching your machine magazine or carton layout
- Stock profiles ship in 5-15 days, reducing line stoppage risk during supply gaps
Anti-Static IC tubes for IC, SOP,DIP,TO-220,PLCC on the Line
Shipping TO-220 and TO-252 power transistors from a semiconductor plant to an overseas EMS
Feeding DIP and SOP packages into tube feeders on automatic insertion machines
Protecting large or heavy devices like ceramic TO packages and microprocessor heat sinks
Storing high-value ICs and relays in a buffer stock with ESD and mechanical protection
Re-packing bulk devices into fixed-count tubes for traceability and kitting
Replacing a tube supplier whose profile no longer matches a device’s body or lead span
Anti-Static IC tubes for IC, SOP,DIP,TO-220,PLCC Is Built For
- IC distributors re-packaging bulk devices for their customers
- Semiconductor and passive component makers packaging finished goods
- EMS and SMT plants receiving tube-packed components and needing spares for rework
- Relay, switch, and connector manufacturers shipping large or heavy bodies not suited for tape and reel
- Purchasing teams replacing a tube supplier with mismatched profiles or inconsistent dimensions
What Goes Wrong Without Anti-Static IC tubes for IC, SOP,DIP,TO-220,PLCC
- Devices jam mid-tube due to internal profile drift or dimensional inaccuracy
- Electrostatic discharge damages sensitive components during handling and transit
- Bulk-packed parts arrive in random orientation, requiring manual re-orientation
- Tubes crack on drop or impact, spilling contents inside the carton
- Large or heavy packages like TO-220 and TO-252 cannot be held in tape and reel
- Anti-static performance degrades after repeated wiping or long storage with surface-only treatment
Technical Detail of Anti-Static IC tubes for IC, SOP,DIP,TO-220,PLCC
- Oval or square extruded profile matched to device body and lead span
- Anti-static achieved by surface layer process or additives built into the resin
- Critical dimension control within 5 mils on PVC, and +/- 2 mils on PC
- Smooth internal surface to prevent binding and allow free device movement
- Good impact strength and drop resistance for intact tubes after carton handling
- Available with rubber end plugs, plastic pins, nails, caps, or EPE plugs for closure
The Numbers for Anti-Static IC tubes for IC, SOP,DIP,TO-220,PLCC
Values are taken from the SEWATE product data for this item.
| Model Number | SE-IC-016 |
|---|---|
| Material | PVC / PS / PC / PETG / ABS |
| Wall Thickness | 0.30mm-1.85mm |
| Profile | Oval or square or customized |
| Dimension Control | Within 5 mils on PVC, +/- 2 mils on PC |
| Anti-Static Method | Surface layer treatment or additive in resin |
| Certification | RoHS |
| MOQ | 10000 pieces |
| Sample Time | 3-5 days or according to customers’ requirements |
| Lead Time | 5-15 days or depend on final quantity |
| Capacity | 50000 pcs per week |
| Supply Ability | Monthly output of finished products 150 tons |
| Packaging | Cartons or as customer requirement |
| Payment Terms | T/T, L/C, etc. |
| Place of Origin | Shenzhen, China |
Resins Used in Anti-Static IC tubes for IC, SOP,DIP,TO-220,PLCC
- PVC provides high strength, good flexibility, stable geometry, and long storage life; standard choice for most IC tubes
- PS is halogen free, low cost, and offers improved clarity and impact strength over standard PVC
- PC is used when tight tolerances, high impact resistance, or elevated temperature stability are required
- PETG offers the strongest impact strength and excellent clarity, ideal for heavy-duty or large packages
- ABS is selected when high impact resistance is needed and transparency is less critical
Production Route for Anti-Static IC tubes for IC, SOP,DIP,TO-220,PLCC
- Review of application requirements and tube function during quotation
- Drawing created from purchase order and sent for customer approval before tooling
- Mould making and tooling trial on the approved profile
- Sample production with 20-50 free tubes for fit testing on the actual device
- Extrusion of the approved profile followed by cutting to ordered length
- Anti-static treatment applied via surface layer process or additive as specified
- Plug fitting, counting, and packing into cartons as per customer requirement
How Anti-Static IC tubes for IC, SOP,DIP,TO-220,PLCC Is Checked
- Critical dimension control within 5 mils on PVC and +/- 2 mils on PC to prevent jamming
- Fit testing of sample tubes against the actual device or drawing before mass production
- Anti-static value verified to remain stable after handling and storage
- Drop and pressure tests performed on tube bodies before packing
- ISO14001 quality management system in place with after-sales support on shipped lots
What Can Change on Anti-Static IC tubes for IC, SOP,DIP,TO-220,PLCC
- Tube length customized to match magazine pitch or carton layout from 50mm to 1000mm
- Internal profile designed from customer drawing, device drawing, or physical sample
- Material selected from PVC, PS, PC, PETG, or ABS based on cost, clarity, and impact needs
- Colour chosen from transparent, blue, black, red, yellow, or purple for line identification
- Anti-static method specified as surface treated or additive loaded for long-term stability
- Surface printing of part numbers, symbols, or handling marks available
- Closure selected from rubber end plugs, plastic pins, nails, caps, or EPE plugs
Comparing Anti-Static IC tubes for IC, SOP,DIP,TO-220,PLCC
| Tape and reel | Tubes hold larger and heavier packages like TO-220 and ceramic TOs that tape pockets cannot support, but tape is better for high-volume SMD placement |
|---|---|
| Vacuum formed trays | Trays offer better protection for fragile or fine-pitch packages, but tubes are lower cost per unit and load directly into tube feeders |
| Bulk bag packing | Tubes cost more per unit than bulk bags but eliminate random orientation, ESD exposure, and manual loading time |
| Standard stock tubes | Custom profiles require one-time tooling and 4-6 weeks lead time, but stock profiles ship in 5-15 days and fit only devices they were designed for |
Working With Anti-Static IC tubes for IC, SOP,DIP,TO-220,PLCC
- Send a tube drawing, device drawing, or physical sample so the internal profile can be matched
- If no drawing exists, send the physical component for profile measurement
- Confirm tube length against the magazine pitch on your insertion or placement machine
- Specify whether anti-static must survive repeated wiping and long storage to select the right method
- Choose closure type: rubber plugs for repeated opening, pins for one-way shipping
- Store tubes flat and dry in cartons, away from direct sunlight to prevent deformation
- Plan for one-time tooling cost and 4-6 weeks lead time when introducing a new custom profile
