CB250 Outdoor Transformer Porcelain Bushing
Low Voltage Transformer Bushings
Product Overview
An outdoor low voltage transformer porcelain bushing supplied under the CB250 reference. It carries the transformer winding lead through the tank into open air, insulating it from the tank and holding it in position. Detailed dimensions for the CB250 are confirmed against the drawing before an order is placed, and the bushing can be produced to a customer specification.
Key benefits
Why Buyers Choose This Part
- Outdoor duty construction for tank-mounted low voltage terminals
- CB250 reference held in the catalogue for direct ordering
- Produced to customer specification including special lengths
- Supplied alongside the DIN and EN low voltage ranges
Application scenarios
Where It Is Used
- Low voltage side of outdoor distribution transformers
- Pole-mounted transformers with exposed LV terminals
- Replacement of aged outdoor LV bushings
- Transformer builds specified against the CB250 reference
Who it is for
Who It Suits
- Distribution transformer manufacturers
- Transformer repair workshops
- Distributors supplying outdoor LV bushings
Problems it solves
What Goes Wrong Without The Right Part
- Indoor-rated LV bushings fitted to outdoor tanks
- Winding leads that move because the bushing does not fix them
- Sourcing a specific catalogue reference from a general supplier
- Non-standard terminal lengths that catalogue parts will not cover
Technical features
How It Is Built
- CB250 outdoor transformer bushing reference
- Low voltage transformer bushing class
- Porcelain shell construction
- Outdoor service duty
- Manufactured to customer specification where required
Materials
Materials
- Electrical porcelain shell
- Copper or aluminium alloy conductor
Manufacturing
Process
- Forming
- Glazing
- Firing
- Conductor assembly
- Routine electrical test
Quality control
Testing
- Dimensional check against the confirmed CB250 drawing
- Insulation test between conductor and mounting
- Glaze and surface inspection
Certifications
Certification
- ISO 9001 quality management system
Customisation
Customisation Options
- Special lengths and connection types produced to order
- Conductor metal matched to your busbar
- OEM and ODM marking
Comparison
How It Compares
| DIN 42530 low voltage bushings | The DIN series publishes fixed creepage and weight figures per current rating. The CB250 is ordered against its own reference, so we confirm the drawing with you first. |
|---|---|
| Indoor LV bushings | This part is specified for outdoor service. Do not substitute an indoor bushing onto an outdoor tank. |
Use guide
Before You Order And After It Arrives
- Ask for the dimensioned drawing before confirming the order
- Confirm the terminal length needed for your tank
- Match the conductor metal to your LV lugs
- Keep the shed surface clean on pole-mounted transformers
Questions
CB250 Outdoor Transformer Porcelain Bushing Questions
Is this bushing for indoor or outdoor use?
Outdoor. It is specified as an outdoor transformer porcelain bushing.
What dimensions does the CB250 have?
The published listing is brief. Message us on WhatsApp with the reference and we will send the dimensioned drawing before you order.
Can you make a special length?
Yes. We manufacture bushings to customer specifications including special lengths and different screw sizes.
What voltage class is it?
It sits in the low voltage transformer bushing range.
What material is the shell?
Electrical porcelain, with copper or aluminium alloy conductor components.
Do you supply matching high voltage bushings?
Yes. The DIN 42531 and EN 50180 high voltage ranges cover the other side of the same transformer.
