ANSI 15kV Transformer Porcelain Bushing
Screw Thread Transformer Bushings
Product Overview
A 15 kV transformer porcelain bushing built to ANSI electrical and mechanical performance requirements. It gives the high voltage supply a safe passage into the transformer and forms the interface that protects the equipment from arcing damage. The shed profile is streamlined, which cuts the chance of flashover and helps heat dissipate from the terminal area.
Key benefits
Why Buyers Choose This Part
- Meets ANSI standards for both electrical and mechanical performance
- Streamlined profile that reduces flashover likelihood
- Improved heat dissipation around the terminal connection
- High-quality porcelain built for harsh outdoor environments
Application scenarios
Where It Is Used
- Power transformers at 15 kV in generation, transmission and distribution
- Switchgear and other electrical equipment needing an ANSI bushing interface
- Outdoor installations exposed to harsh weather
- Projects specified against ANSI rather than DIN or EN
Who it is for
Who It Suits
- Transformer manufacturers working to ANSI specifications
- Power generation, transmission and distribution operators
- Switchgear builders needing an ANSI-compliant bushing
Problems it solves
What Goes Wrong Without The Right Part
- Electrical arcing damage at the high voltage interface
- Flashover on bushings with a shed profile that traps dirt
- Heat build-up at the terminal under continuous load
- Non-ANSI parts offered where the specification requires compliance
Technical features
How It Is Built
- 15 kV rated transformer bushing
- Meets ANSI standards for electrical and mechanical performance
- Streamlined design reducing flashover likelihood
- Improved heat dissipation
- High-quality porcelain construction
- Screw thread terminal arrangement
Specifications
Published Figures For This Product
Every value below comes from the manufacturer data for this item. Figures not listed are confirmed against the drawing before an order is placed.
| Rated Transformer Bushing | 15 kV |
|---|
Materials
Materials
- High-quality electrical porcelain
- Copper or aluminium alloy conductor
Manufacturing
Process
- Forming
- Glazing
- Firing
- Conductor assembly
- Electrical and mechanical testing
Quality control
Testing
- Electrical performance testing to ANSI requirements
- Mechanical performance verification
- Glaze and surface inspection
Certifications
Certification
- Meets ANSI standards for electrical and mechanical performance
- ISO 9001 quality management system
Customisation
Customisation Options
- Produced to your transformer drawing
- Thread size cut to your terminal specification
- OEM and ODM supply
Comparison
How It Compares
| DIN pattern bushing at the same voltage | ANSI and DIN fix different dimensions and test values. Specify the one your transformer drawing follows, they are not interchangeable at the terminal board. |
|---|---|
| 18 kV ANSI transformer bushing | Same ANSI family, a step up in voltage class. Match the bushing class to the transformer HV rating. |
Use guide
Before You Order And After It Arrives
- Confirm the transformer drawing calls out ANSI before ordering
- Match the thread size to your terminal stud
- Keep the shed surface clean to preserve the flashover margin
- Check the seal at the tank interface during every service
Questions
ANSI 15kV Transformer Porcelain Bushing Questions
Does this bushing meet ANSI requirements?
Yes, it meets ANSI standards for both electrical and mechanical performance.
What is it rated for?
15 kV.
Why does the shed profile matter?
The streamlined design reduces the likelihood of flashover and improves heat dissipation at the terminal.
Where is it used?
Power transformers, switchgear and other electrical equipment across generation, transmission and distribution.
Can it be made to our specification?
Yes. We produce to customer drawings and samples, including special lengths and screw sizes.
Can you supply higher ANSI voltage classes?
Yes, including 18 kV ANSI transformer bushings.
