IP44 Recessed LED Downlight
The IP44 recessed LED downlight is designed for commercial interiors where moisture resistance and consistent light output are required. Available in five power levels from 7W to 40W, each model delivers 90 lumens per watt with a system lumen output ranging from 630 to 3600 lumens. The fixture uses an Osram LED chip with CRI above 80 and a Lifud driver, ensuring stable performance. The housing is diecast aluminium with a white or silver reflector, and the IP44 rating allows installation in areas with light splash exposure such as kitchens, bathrooms, and covered outdoor spaces. Beam angle is fixed at 90 degrees across all models, and the cut-out size matches the fixture diameter for flush installation. The downlight is available in 3000K, 4000K and 6000K colour temperatures. UGR is below 19, reducing glare in visual environments.
Ask for the IES file or a Dialux calculation with your enquiry.
What This Fixture Does For You
- IP44 rating allows use in damp locations like kitchens, bathrooms and covered outdoor areas
- 90lm/w efficiency across all models ensures high output from low power input
- CRI above 80 maintains accurate colour rendering for retail and hospitality spaces
- UGR below 19 reduces glare in open-plan offices and retail zones
- Diecast aluminium housing provides structural rigidity and effective heat dissipation
- Osram LED chip ensures long life and stable lumen maintenance over time
- Lifud driver provides reliable constant current output with minimal flicker
- Fixed 90 degree beam angle gives consistent light spread without hotspot
- Cut-out size matches fixture diameter for easy installation in standard ceiling openings
| Model | FX-2, FX-3, FX-4, FX-6, FX-8 |
|---|---|
| Input Voltage | 220-240VAC |
| Frequency | 50Hz / 60Hz |
| System Power | 7W, 10W, 15W, 30W, 40W |
| Power Factor | >0.5, >0.5, >0.5, >0.9, >0.9 |
| Driver | Lifud |
| LED Chip | Osram |
| CRI | >80 |
| System Lumen | 630lms, 1350lms, 2160lms, 2700lms, 3600lms |
| Efficiency of Fixture | 90lm/w |
| Colour Temperature | 3000K, 4000K, 6000K |
| Beam Angle | 90° |
| Housing Material | Diecast Aluminium |
| Optic | Aluminium Reflector |
| IP Rating | IP44 |
| UGR | <19 |
| Cut Hole Size | Ø70mm, Ø85mm, Ø105mm, Ø165mm, Ø200mm |
| Fixture Dimension | Ø90x45mm, Ø105x65mm, Ø130x68mm, Ø190x95mm, Ø220x105mm |
Buyers And Applications
Who Buys It
- Lighting importers sourcing recessed downlights for commercial projects
- Electrical wholesalers needing IP44-rated fixtures for wet location applications
- Lighting designers specifying low-UGR, high-CRI downlights for interior layouts
- Contractors installing fixtures in kitchens, bathrooms and covered outdoor zones
- Hospitality and retail FF&E buyers requiring durable, low-glare lighting
Where It Is Used
- Commercial kitchens and service areas where moisture exposure is present
- Bathrooms in hotels and fitness centres requiring damp-rated lighting
- Covered outdoor patios and verandas with partial weather protection
- Retail stores and showrooms where low glare and consistent colour are needed
- Office corridors and reception areas with ceiling-mounted recessed lighting
- Supermarkets and convenience stores with ceiling-mounted fixtures in high-traffic zones
- Villas and residential commercial spaces with integrated lighting design
What Goes Wrong Without It
- Halogen downlights that fail in damp environments due to lack of IP rating
- Low-CRI LEDs that make skin tones and product colours appear unnatural
- High-UGR lighting that causes visual discomfort in open-plan spaces
- Inconsistent lumen output from low-efficiency fixtures requiring more units
- Cheap drivers that cause flicker or early failure in enclosed ceiling voids
- Fittings that cannot be installed in areas with light moisture exposure
How It Is Built
- IP44 rating for protection against water splashes and dust ingress
- Osram LED chip with CRI above 80 for accurate colour rendering
- Lifud driver with stable constant current output for long life
- 90lm/w efficiency across all power levels for energy savings
- Fixed 90 degree beam angle for consistent light distribution
- Diecast aluminium housing for structural strength and heat dissipation
- White or silver reflector for even light spread and reduced glare
- UGR below 19 for low visual discomfort in commercial interiors
- Cut-out size matches fixture diameter for simple installation
- Available in 7W, 10W, 15W, 30W and 40W with matching lumen outputs
- Colour temperature options: 3000K, 4000K and 6000K
- Input voltage 220-240VAC, compatible with 50Hz/60Hz mains
Materials
- Diecast aluminium housing for strength and thermal management
- Aluminium reflector with white or silver finish for even light distribution
- Polycarbonate lens or diffuser (implied by optic and IP44 rating)
- Internal wiring and terminal block with heat-resistant insulation
Certifications
- CE
- RoHS
- CCC
- CQC
- ISO 9001:2015 quality system
How It Is Made And Checked
Manufacturing Process
- Diecast aluminium housing formed and machined to final dimensions
- Internal reflector installed and finished in white or silver
- LED board mounted and thermally bonded to the housing base
- Lifud driver wired and secured inside the housing
- Optic and beam angle lens fitted to ensure 90 degree spread
- IP44 sealing applied at the junction and gasket interface
- Final inspection for visual defects and electrical continuity
- Aging test on one of two automatic aging lines before packing
Quality Control
- Incoming inspection of LED chips, drivers and diecast housings
- Photometric testing to confirm lumen output and colour temperature
- Temperature testing on assembled fixtures under load
- Aging test on one of two automatic aging lines
- Reliability testing before batch release
- 100% inspection of every fixture before shipment
What We Can Change For You
- Colour temperature selected from 3000K, 4000K or 6000K at order
- Reflector finish available in white or silver
- 3D drawing provided within 2 days of customer request
- Mock-up sample delivered within 3 days for new designs
- IES files and Dialux calculations available on request
How It Compares With The Alternatives
| Standard recessed downlight without IP rating | Suitable for dry indoor spaces only; not for kitchens, bathrooms or covered outdoor areas |
|---|---|
| Low-efficiency downlight at 60lm/w | Requires more units to achieve same lumen output, increasing installation and energy cost |
| LED downlight with CRI below 80 | Makes product colours appear dull or inaccurate in retail and hospitality settings |
| Recessed fixture with UGR above 22 | Causes visual discomfort and glare in open-plan or high-traffic zones |
Before You Order And Before You Install
- Confirm the ceiling cavity depth is sufficient for the fixture depth before installation
- Use the correct cut-out size to ensure a flush fit and avoid gaps
- Select 3000K for warm ambient spaces, 4000K for neutral, 6000K for cool and bright
- Ensure the electrical circuit supports the total power draw of multiple fixtures
- Do not install in fully exposed outdoor areas where water can directly impact the fixture
- Verify the IP44 rating is sufficient for the intended environment
Where This Fixture Is Specified
Other Fixtures For The Same Ceiling
Anti Glare COB LED Downlight
COB Recessed LED Downlight
SMD Recessed LED Downlight
3 Wire LED Track Rail
Read Before You Specify
UGR And Glare Control In Recessed LED Downlights
UGR below 19 is written into most office and hospitality specifications. This explains what produces the figure and how to hit it.
How To Plan Downlight Cut Holes And Spacing
Cut hole and spacing are set on the ceiling drawing long before the fittings arrive. Get them from the fixture, not from a rule of thumb.
A LED Downlight Buying Guide For Importers
What to check on a downlight quotation before it becomes a container of fittings you have to sell.
Frequently Asked Questions
What is the IP rating of this downlight?
IP44, which protects against water splashes and dust ingress. Suitable for kitchens, bathrooms and covered outdoor areas.
Can I use this in a bathroom?
Yes, if the area is covered and not directly exposed to water jets. IP44 is suitable for bathroom zones 2 and 3.
What colour temperatures are available?
3000K, 4000K and 6000K. Choose based on the desired ambient tone for the space.
Is the beam angle adjustable?
No, the beam angle is fixed at 90 degrees. It cannot be adjusted after installation.
Which driver brand is used?
Lifud. The driver is constant current and flicker-free, ensuring stable performance over time.
Can you provide IES files or Dialux data?
Yes, we supply IES files and can run Dialux calculations for your layout upon request.
Can the reflector finish be changed?
Yes, the reflector is available in white or silver. Specify your preference when placing the order.
Request A Quote On The IP44 Recessed LED Downlight
Send the quantity, colour temperature and beam angle. If you are matching an existing installation, send a photo of the rail end or the ceiling aperture with the enquiry.
