KY-PC-MINI-T-DESK Stainless Steel Desktop Keyboard With Trackball or Touchpad
KY-PC-MINI-T-DESK is a desktop version of the compact stainless steel keyboard, supplied ready to place on a bench rather than cut into a panel.
Product Overview
KY-PC-MINI-T-DESK is a desktop version of the compact stainless steel keyboard, supplied ready to place on a bench rather than cut into a panel. It measures 320*118*39.5 mm overall and can be built with a 25mm or 38mm trackball or a 60x44mm touchpad. The approvals list includes BIS alongside RoHS, IP65, FCC and CE, which matters for shipments into markets that require it.
- Desktop mounting means no panel cutout and no enclosure redesign
- Choice of 25mm or 38mm trackball or a 60x44mm touchpad for the same chassis
- RoHS, IP65, FCC, CE and BIS approvals widen the export markets it can ship into
- Very rugged vandal proof design holds up in public areas as well as on a bench
- Buttons made of stainless steel with free layout customization
- Durability ≥2Million supports multi-shift workstation use
Application Scenarios
- Industrial work stations on the production floor
- Kiosk solutions where a loose keyboard is acceptable
- Medical equipment benches needing wipe-down input
- Control terminals in plant rooms
- Factories and public places with shared workstations
Who It Is For
- Plant engineers equipping industrial work stations
- Medical equipment suppliers
- Kiosk and control terminal integrators
- Exporters shipping to markets requiring BIS
Problems It Solves
- Panel mount keyboards that force an enclosure redesign for a bench application
- Office keyboards ruined by cleaning fluid in medical and food areas
- Fleet standardization when some sites want a trackball and others a touchpad
- Market access blocked by an incomplete approvals list
Technical Features
- Stainless steel desktop keyboard, water, dust and vandal resistant
- Trackball diameter 25mm/38mm or touchpad 60x44mm
- Key travel 2mm with operation force <3N
- Power supply DC5V±5% with working current <150mA
- Laser or etching procedure for key labeling
- Operation temperature -10℃~55℃ and storage temperature -30℃~85℃
Specifications
| Front Panel | 320*118 mm |
|---|---|
| Overall | 320*118*39.5 mm |
| Trackball Diameter | 25mm/38mm |
| Touchpad Size | 60x44mm |
| Key Travel | 2mm |
| Operation Force | <3N |
| Power Supply | DC5V±5% |
| Working Current | <150mA |
| Interface | USB, PS/2 |
| Durability | ≥2Million |
| Mounting Way | Desktop |
| Approval | RoHS, IP65, FCC, CE, BIS |
Materials
- Stainless steel panel
- Stainless steel buttons
Manufacturing Process
- Panel forming of the 320*118 mm stainless face
- CNC machining of the pointing device aperture
- Desktop housing forming to the 39.5 mm profile
- Laser or etching of key legends
- Pointing device fitting and sealing to IP65
Quality Control
- IP65 sealing verification on the completed desktop unit
- Key travel confirmed at 2mm and force kept under 3N
- Pointing device tracking test for both trackball and touchpad builds
- Cosmetic inspection of the brushed stainless face
Approvals And Test Documentation
- RoHS
- IP65
- FCC
- CE
- BIS
Customisation Options
- Free layout customization on the stainless button field
- Choice of 25mm or 38mm trackball or 60x44mm touchpad
- Laser or etching key labeling
- Cable and connector specification for USB or PS/2
- Customer branding etched on the panel
How It Compares
| Panel mount version | Desktop mounting ships ready to use on a bench with no fascia cutout or mounting kit |
|---|---|
| Sealed plastic desktop keyboard | A stainless steel panel with a vandal proof design survives impact that cracks a moulded desktop shell |
Use Guide
- Allow 39.5 mm of height clearance under any overhead shelf
- Choose the pointing device at order stage since the aperture is machined to suit
- Clean with a damp cloth; the unit is rated IP65
- Keep operation inside -10℃~55℃
Industries
Solutions
Related Reading
Related Products
16 Key Metal Desktop Keypad KY-2088A-DESK
View Specification
KY-FB-DT-B Explosion Proof Metal Desktop Keyboard With Touchpad
View Specification
KY-TB-38-C2 Stainless Steel Keypad With Waterproof Mechanical Buttons
View Specification
KY-PC-H-DESK Stainless Steel Desktop Keyboard With Cherry Mechanical Switches
View SpecificationQuestions About This Model
What size is KY-PC-MINI-T-DESK?
Front panel 320*118 mm and overall 320*118*39.5 mm.
Trackball or touchpad?
Both are available: trackball diameter 25mm/38mm or touchpad 60x44mm.
What approvals does it carry?
RoHS, IP65, FCC, CE and BIS.
How does it mount?
Desktop mounting, no panel cutout required.
What is the key travel?
2mm, with operation force under 3N.
Can the layout be changed?
Yes, buttons and layout are customized for free.
