IP68 Stainless steel 316 Linear Shape LED Underground Light
The FD-U010L12 is a 12W linear in-ground luminaire designed for architectural and landscape applications where permanent submersion or frequent flooding is expected. The fixture uses stainless steel 316 for the entire body, providing corrosion resistance in harsh outdoor environments. It is rated IP68, suitable for installations in areas that remain submerged for extended periods. The linear shape allows for continuous lighting along pathways, edges, or architectural features. It operates on AC85-265V or DC24V, making it compatible with both mains and low-voltage systems. The driver is included with the fixture.
| Model | FD-U010L12 |
|---|---|
| Power | 12W |
| Input Voltage | AC85-265V/DC24V |
| IP Rating | IP68 |
| Dimension | L300/600/1000 mm x W65 x H90 mm |
| Material | Stainless steel 316 |
| LED Chip | CREE |
| Driver | Included |
Key Benefits
- IP68 rating ensures operation in permanently submerged or frequently flooded conditions
- Stainless steel 316 body resists corrosion in saltwater, chlorinated water, and high-moisture environments
- Linear shape provides continuous, even illumination along edges, paths, or architectural features
- AC85-265V or DC24V input supports integration into both mains-fed and low-voltage site wiring
- Driver is included, reducing on-site installation complexity and wiring errors
- Available in multiple lengths to match site-specific layout requirements
Application Scenarios
- Continuous edge lighting along paved walkways in coastal or flood-prone areas
- Underwater or submerged path lighting in garden ponds, fountains, or water features
- Architectural accent lighting along building edges or steps that may be exposed to standing water
- Landscape lighting in areas with high rainfall or poor drainage, such as urban plazas
- Installation in marine or seaside developments where salt spray and moisture are constant
Who It Is For
- Facade and landscape lighting contractors installing in-ground fixtures in high-moisture or submerged zones
- Lighting designers specifying durable, long-life solutions for exposed or wet environments
- Electrical wholesalers supplying products for projects in the Middle East and Europe with high humidity or coastal exposure
- Brand owners sourcing OEM linear in-ground luminaires under their own label
Problems It Solves
- Standard IP67 fixtures fail when exposed to prolonged immersion, leading to early failure
- Aluminium or lower-grade stainless steel bodies corrode in saltwater or chlorinated environments
- Fixtures without integrated drivers require additional on-site wiring and component matching
- Fixed-length fixtures limit layout flexibility in long or irregularly shaped paths
- Non-linear in-ground lights create gaps in illumination where continuous lines are needed
Technical Features
- IP68 sealing for permanent submersion and continuous exposure to water
- Stainless steel 316 body for maximum corrosion resistance in harsh environments
- Linear shape with multiple length options: 300mm, 600mm, 1000mm
- CREE LED chip for consistent light output and long life
- AC85-265V or DC24V input voltage range for compatibility with different site power systems
- Driver included with the fixture, eliminating the need for separate driver supply
Materials
- Stainless steel 316 body for full corrosion resistance in wet, salted, or chemically exposed environments
- Tempered glass lens to protect the LED array while maintaining optical clarity
- Sealing gaskets and O-rings rated for continuous water exposure
Manufacturing Process
- Stainless steel 316 body fabrication and polishing
- LED board assembly with CREE packages
- Sealing and gasket fitting to achieve IP68 rating
- Integrated driver installation
- Final pressure and immersion test before packing
Quality Control
- Incoming inspection of CREE LED packages and drivers
- IP68 sealing verification through pressure and immersion testing
- Powered ageing run under full load before packing
- Stated defective rate below 0.2%
Certification
Only the certification the factory publishes is listed here.
- CE certificate and report
- Stated conformity with CE, RoHS and FCC
Customisation Options
- Customer logo printing, confirmed against an approved sample before production
- Available in 300mm, 600mm, or 1000mm lengths to match site layout
- AC85-265V or DC24V input version
- OEM and ODM production for buyers selling under their own brand
Compared With the Alternatives
IP67 linear in-ground light
IP68 allows permanent submersion, while IP67 only supports temporary immersion
Aluminium-bodied linear light
Stainless steel 316 resists corrosion better in saltwater and chlorinated environments
Fixture without integrated driver
Built-in driver reduces on-site wiring complexity and ensures compatibility
Use Guide
- Cast or core a trench of sufficient depth and width to accommodate the fixture and allow drainage
- Ensure the installation site is free of debris and water before placing the fixture
- Position the fixture so the top is flush with the finished surface to avoid tripping hazards
- For DC24V runs, size the cable to account for voltage drop over the full circuit length
- Clean the glass lens periodically during maintenance to maintain light output
IP68 Stainless steel 316 Linear Shape LED Underground Light Questions
What is the IP rating of this fixture?
It is rated IP68, suitable for permanent submersion and continuous exposure to water.
Can it be used in saltwater or chlorinated environments?
Yes. The stainless steel 316 body provides resistance to corrosion in saltwater and chlorinated water.
Is the driver included?
Yes. The driver is included with the fixture, so no additional driver is needed on site.
What lengths are available?
The fixture is available in 300mm, 600mm, and 1000mm lengths to suit different layout needs.
What is the warranty?
The warranty ranges from 2 to 5 years depending on the product, as stated in the company's commercial terms.
Can I order a sample before placing a bulk order?
Yes. Sample orders are accepted, mixed samples are acceptable, and samples typically ship within 3-5 days.
How long does mass production take?
Mass production typically takes 1-2 weeks, with shipping via DHL, UPS, FedEx, or TNT taking 3-5 days in transit.
