54*3W RGB DMX LED Stage Flood Light
The FD-S914R54 is a 54*3W RGB DMX-controlled stage flood light designed for architectural and outdoor lighting projects requiring dynamic colour effects. It delivers full RGB colour mixing via DMX512 protocol, allowing precise control of colour and animation sequences. The fixture is built for outdoor use with an IP66 rating, making it suitable for exposed positions on facades, stages, and landscape features. It operates on AC85-265V, compatible with standard mains supply across regions. The unit is constructed with a robust metal body and includes a DONE driver for stable operation.
| Model | FD-S914R54 |
|---|---|
| Power | 54*3W |
| Input Voltage | AC85-265V |
| IP Rating | IP66 |
| LED Chip | OSRAM |
| Driver | Included |
| Colour Temperature | RGB |
| Control System | DMX512 |
| Warranty | 3 Years Warranty |
Key Benefits
- Full RGB colour mixing via DMX512 allows dynamic lighting effects for architectural and stage applications
- IP66 rating ensures protection against dust and powerful water jets, suitable for exposed outdoor positions
- AC85-265V input supports global mains voltage without need for transformers
- 54*3W configuration delivers high brightness in a single compact unit
- DONE driver ensures stable performance under variable voltage conditions
- DMX512 control enables integration into larger lighting control systems for coordinated effects
Application Scenarios
- Dynamic colour washing on building facades during events or seasonal lighting schemes
- Stage and performance lighting where animated colour sequences are required
- Landscape lighting installations with programmable colour effects on fountains or sculptures
- Outdoor architectural features such as columns, arches, and entranceways needing variable lighting
Who It Is For
- Facade and landscape lighting contractors installing programmable lighting in public or commercial projects
- Lighting designers specifying dynamic colour effects for architectural or event-based installations
- Electrical wholesalers supplying DMX-controlled lighting for stage and architectural applications
- Brand owners sourcing OEM stage flood lights under their own label for distribution
Problems It Solves
- Fixed colour or static lighting cannot meet the need for animated or event-specific lighting effects
- Non-DMX fixtures require manual control or separate controllers, increasing complexity on site
- Lack of IP66 protection limits outdoor use in areas exposed to rain or high-pressure washing
- Inconsistent driver performance under fluctuating voltage can cause flickering or failure
- Multiple fixtures with different control systems increase cabling and programming effort
Technical Features
- 54*3W RGB LED array for high-output, full-colour lighting
- DMX512 control system for precise colour and animation programming
- IP66 rating for protection against dust and water jets
- AC85-265V input for compatibility with standard mains supply worldwide
- OSRAM LED chips for consistent colour and long life
- DONE driver integrated into the fixture for reliable power management
Materials
- Metal body for structural rigidity and heat dissipation
- IP66-rated housing with sealed joints for outdoor durability
- OSRAM LED packages for consistent colour output
- DONE driver for stable electrical performance
Manufacturing Process
- Metal body fabrication and surface treatment
- Assembly of OSRAM LED modules in 54*3W configuration
- Integration of DONE driver and internal wiring
- Sealing and testing for IP66 compliance
- DMX512 protocol programming and functional testing
- Aging test under full load before packing
Quality Control
- Incoming inspection of OSRAM LED chips and DONE drivers
- IP66 sealing verification using pressure and spray tests
- DMX512 signal response and colour accuracy check
- Powered ageing run for 24 hours before packing
- Stated defective rate below 0.2%
Certification
Only the certification the factory publishes is listed here.
- CE certificate and report
- Stated conformity with CE, RoHS and FCC
Customisation Options
- Customer logo printing, confirmed against an approved sample before production
- Available with or without driver to match site control strategy
- OEM and ODM production for buyers selling under their own brand
- DMX512 protocol support ensures compatibility with existing control systems
Compared With the Alternatives
Fixed-colour flood light
Higher cost per unit, but enables dynamic colour changes without replacing the fixture
Non-DMX RGB flood light
Requires separate controller or manual operation, but DMX512 allows centralised programming and automation
IP65-rated flood light
Less protection against water jets, but IP66 suits exposed outdoor positions with high-pressure cleaning or heavy rain
Use Guide
- Mount the fixture securely on a stable structure or rigging system with proper load support
- Connect to a DMX512 controller using standard 3-pin or 5-pin XLR cables
- Set the DMX address using the built-in DIP switches or control panel
- Ensure the power supply is within AC85-265V range and properly grounded
- Avoid direct exposure to high-pressure water jets during cleaning; use low-pressure wash only
- Perform regular visual checks on seals and connectors to maintain IP66 integrity
54*3W RGB DMX LED Stage Flood Light Questions
What is the input voltage range?
The fixture operates on AC85-265V, compatible with standard mains supply across most regions.
Is the driver included?
Yes. The fixture includes a DONE driver, but it can be omitted if centralised drivers are used in the system.
What does IP66 mean for outdoor use?
IP66 means the fixture is dust-tight and protected against powerful water jets, suitable for exposed outdoor positions.
Can it be controlled via DMX512?
Yes. The fixture supports DMX512 protocol for precise control of colour, brightness, and animation sequences.
What is the warranty period?
This model carries a 3-year warranty. Across the FENGDIAN range, warranty varies from 2 to 5 years depending on the product.
Can I order a sample before placing a bulk order?
Yes. Sample orders are accepted, mixed samples are acceptable, and samples typically ship within 3-5 days.
How long does mass production take?
Mass production typically takes 1-2 weeks, with goods shipping via DHL, UPS, FedEx, or TNT in 3-5 days, or by air or sea freight.
