DC24V Silicone LED Strip Light
The FD-NO020L08 is a 8W DC24V silicone LED strip light designed for linear lighting in commercial office interiors, building facades, and architectural cove applications. The strip uses 120 SMD 2835 LEDs per metre and is rated IP68 for installation in wet or high-moisture environments. It is supplied without a driver, allowing integration into systems where centralised power supplies are already in place. The flexible silicone body conforms to curved surfaces and resists abrasion and UV exposure in both indoor and outdoor settings.
| Model | FD-NO020L08 |
|---|---|
| Power | 08W |
| Input Voltage | DC24V |
| IP Rating | IP68 |
| Dimension | W10 mm |
| Material | Silicon |
| LED Chip | 2835 SMD |
| LED Quantity | 120 LEDS/M |
| Driver | Not included |
| Warranty | 3 Years |
Key Benefits
- IP68 rating allows installation in wet areas such as bathrooms, kitchens, or outdoor coves without risk of water ingress
- DC24V input matches low-voltage systems already specified in office and facade projects
- No driver supplied, so the strip integrates directly with existing central power supplies or control panels
- Silicone body is flexible and can follow curved surfaces, reducing the need for custom brackets
- 120 SMD 2835 LEDs per metre deliver consistent linear light output with minimal hotspots
- 8W power draw supports energy-efficient lighting in long runs without excessive heat build-up
Application Scenarios
- Linear cove lighting in commercial office ceilings where a continuous, even light band is required
- Facade edge lighting on building corners or horizontal bands where moisture exposure is possible
- Under-cabinet lighting in kitchens or wet rooms with high humidity and splash risk
- Recessed linear lighting in architectural coves or soffits with curved or irregular profiles
- Indirect lighting in retail spaces and lobbies where a clean, seamless light line is needed
Who It Is For
- Lighting project contractors installing linear LED strips in commercial office and facade projects
- Facade and interior designers specifying low-profile, continuous light lines in architectural details
- Electrical wholesalers supplying LED strips for office and architectural applications in Europe and the Middle East
- Brand owners sourcing OEM linear strips under their own label with custom logo printing
Problems It Solves
- Fixed-voltage or AC-powered strips require separate transformers, increasing complexity in low-voltage projects
- Non-flexible strips cannot follow curved or irregular surfaces without additional support hardware
- Standard PVC strips degrade under UV exposure or abrasion in high-traffic or outdoor areas
- IP65 or lower-rated strips are not suitable for wet or splash-prone environments like kitchens or outdoor coves
- Strips with built-in drivers limit integration with centralised power systems used in large-scale projects
Technical Features
- DC24V input voltage for compatibility with low-voltage systems and central power supplies
- IP68 sealing for full protection against dust and continuous immersion in water
- Silicone body provides flexibility, UV resistance, and abrasion resistance
- 120 SMD 2835 LEDs per metre for even light distribution along the strip
- No driver supplied, so the strip can be powered from a central DC24V source
- Flexible design allows installation on curved or irregular surfaces without breaking the light line
Materials
- Silicone body for flexibility, UV resistance, and protection against abrasion and moisture
- SMD 2835 LED packages for consistent light output and reliability
- Conductive copper traces embedded in the silicone for stable electrical connection
- Protective silicone coating over the LED array to prevent environmental damage
Manufacturing Process
- Silicone extrusion and curing to form the flexible strip body
- SMD 2835 LED placement and soldering onto the copper trace layer
- Application of protective silicone coating over the LED array
- IP68 sealing verification through water immersion testing
- Final power and continuity test before packaging
Quality Control
- Incoming inspection of SMD 2835 LED packages and copper traces
- IP68 sealing test with water immersion for each batch
- Powered ageing test under DC24V for 72 hours before packing
- Stated defective rate below 0.2%
Certification
Only the certification the factory publishes is listed here.
- CE certificate and report
- Stated conformity with CE, RoHS and FCC
Customisation Options
- Customer logo printing available, confirmed against an approved sample before production
- Supplied without driver to match centralised power systems
- Available in standard 5m or 10m reels, with custom lengths possible on request
- OEM and ODM production for buyers selling under their own brand
Compared With the Alternatives
AC-powered LED strip
Requires a separate transformer, increasing system complexity and cost; DC24V strip integrates directly with low-voltage systems
PVC-based LED strip
Less flexible and more prone to cracking or UV degradation; silicone offers better durability and weather resistance
IP65-rated strip
Not suitable for continuous immersion; IP68-rated strip can be used in fully submerged or high-moisture areas
Use Guide
- Install on clean, dry surfaces free of dust and oil before applying adhesive backing
- Ensure the DC24V power supply matches the total strip length and current draw
- Avoid sharp bends or kinks in the strip to prevent damage to internal traces
- For outdoor or wet applications, ensure all joints are sealed with waterproof connectors
- Clean the strip surface periodically with a damp cloth to maintain light output and appearance
DC24V Silicone LED Strip Light Questions
What is the input voltage for this strip light?
The strip operates on DC24V, making it suitable for low-voltage systems commonly used in office and facade projects.
Is the driver included?
No. The strip is supplied without a driver, so it can be powered from a central DC24V source or existing power panel.
What does IP68 mean for this product?
IP68 means the strip is protected against dust and can be continuously immersed in water, suitable for wet or outdoor applications.
Can I cut the strip to length?
Yes, the strip can be cut at marked intervals, but only with a clean cut and proper reconnection using waterproof connectors.
What is the warranty period?
This model carries a 3-year warranty. Across the FENGDIAN range, the warranty is 2 to 5 years depending on the product.
Can I order a sample before placing a bulk order?
Yes. Sample orders are accepted, mixed samples are acceptable, and samples typically ship within 3-5 days.
How long does mass production take?
Mass production is typically 1-2 weeks, and goods normally ship by DHL, UPS, FedEx or TNT with 3-5 days in transit, or by air or sea freight.
