High Quality Design LED Tree Light
The FD-TL020S72 is a 72W surface-mounted LED tree light designed for landscape and facade lighting projects where adjustable beam angles and colour flexibility are required. The fixture uses an aluminium body for heat dissipation and is rated IP65 for outdoor use in exposed positions. It operates on DC24V, making it suitable for low-voltage systems common in landscape and architectural lighting. The beam angle is selectable at 10, 15, 30, 45, or 60 degrees, and the colour temperature ranges from 2800K to 6500K, with options for RGB and RGBW for dynamic lighting effects. Control is available via ON/OFF or DMX for integration into larger lighting systems.
| Model | FD-TL020S72 |
|---|---|
| Power | 72W |
| Input Voltage | DC24V |
| IP Rating | IP65 |
| Dimension | 530 x 370 x 300 mm |
| Material | Aluminium |
| Colour Temperature | 2800-6500K/RGB/RGBW |
| Beam Angle | 10/15/30/45/60° |
| Control System | ON/OFF, DMX |
| Warranty | 3 Years |
Key Benefits
- Beam angle options allow precise control over light spread for different tree shapes and facade details
- DC24V input supports low-voltage systems common in landscape and facade projects
- IP65 rating provides protection against dust and water jets, suitable for exposed outdoor positions
- Multiple colour temperature and RGB/RGBW options enable dynamic lighting for landscape and architectural features
- DMX control allows integration into larger lighting sequences and automated systems
- Aluminium body ensures effective heat dissipation and long-term reliability in outdoor conditions
Application Scenarios
- Highlighting tree trunks and canopies in residential and public park landscapes
- Accentuating architectural features on building facades with adjustable beam angles
- Creating dynamic lighting effects on trees and structures in urban plazas and commercial developments
- Lighting trees and columns in hotel entrances and shopping mall courtyards
- Integrating into DMX-controlled lighting sequences for seasonal or event-based displays
Who It Is For
- Landscape lighting contractors installing tree lights in parks and public spaces
- Facade lighting designers specifying adjustable beam angles for building features
- Electrical wholesalers supplying outdoor lighting for architectural projects in Europe and the Middle East
- Brand owners sourcing OEM tree lights under their own label with custom control options
Problems It Solves
- Fixed beam angle lights require multiple SKUs to cover different tree and facade shapes
- Lack of DMX control limits integration into automated lighting sequences for events or seasonal displays
- Low-voltage systems need fixtures compatible with DC24V input to avoid transformer losses
- Exposure to rain and dust requires protection beyond basic IP44 for long-term reliability
- Inconsistent colour rendering across fixtures affects visual consistency in large-scale projects
Technical Features
- 72W power with DC24V input for low-voltage system compatibility
- IP65 rating for protection against dust and water jets in outdoor environments
- Selectable beam angles: 10, 15, 30, 45, or 60 degrees to match target object size and distance
- Colour temperature range: 2800K to 6500K, with RGB and RGBW options for dynamic lighting
- Control system: ON/OFF or DMX for manual or automated operation
- Aluminium body for effective heat dissipation and structural durability
Materials
- Aluminium body for heat dissipation and structural strength
- Weather-resistant housing with IP65 sealing for outdoor durability
- Internal components designed for DC24V operation and long-term reliability
Manufacturing Process
- Aluminium body machining and surface finishing
- Assembly of LED modules with OSRAM or CREE chips
- Installation of control circuitry for ON/OFF and DMX functions
- Sealing and IP65 testing before final assembly
- Powered ageing and performance testing before packing
Quality Control
- Incoming inspection of LED chips and control components
- IP65 sealing verification using pressure and spray tests
- Powered ageing run under rated voltage for 72 hours
- Stated defective rate below 0.2%
Certification
Only the certification the factory publishes is listed here.
- CE certificate and report
- Stated conformity with CE, RoHS and FCC
Customisation Options
- Customer logo printing available, confirmed against an approved sample before production
- Beam angle selected at time of order from 10, 15, 30, 45, or 60 degrees
- Colour temperature and control system (ON/OFF or DMX) specified at order stage
- OEM and ODM production available for buyers selling under their own brand
Compared With the Alternatives
Fixed beam angle tree light
Requires multiple SKUs for different lighting needs, but offers lower cost per unit
Mains-powered tree light
DC24V input reduces voltage drop over long cable runs, but requires a compatible power supply
Non-DMX controlled tree light
Lacks integration into automated sequences, but simpler to install and commission
Use Guide
- Mount the fixture securely on a tree trunk or support structure using the provided brackets
- Select the beam angle based on the distance to the target and desired light spread
- Ensure the DC24V power supply is sized to handle the total load of multiple fixtures
- For DMX control, connect the fixture to a DMX network with proper termination
- Clean the lens periodically to maintain light output and prevent dirt buildup
High Quality Design LED Tree Light Questions
What is the input voltage for this tree light?
The fixture operates on DC24V, suitable for low-voltage landscape and architectural lighting systems.
Can the beam angle be changed after installation?
The beam angle is fixed at the time of order. It cannot be adjusted after installation, so select the correct angle during specification.
Is DMX control included?
Yes. The fixture supports both ON/OFF and DMX control. DMX is available as an option at order stage.
What is the IP rating and is it suitable for outdoor use?
The fixture is rated IP65, which protects against dust and water jets. It is suitable for exposed outdoor positions.
What is the warranty period?
This model carries a 3 year warranty. Across the FENGDIAN range, the warranty is 2 to 5 years depending on the product.
Can I order a sample before placing a bulk order?
Yes. Sample orders are accepted, mixed samples are acceptable, and samples typically ship within 3-5 days.
How long does mass production take?
Mass production is typically 1-2 weeks, and goods normally ship by DHL, UPS, FedEx or TNT with 3-5 days in transit, or by air or sea freight.
