Stainless Steel Flat Fan Spray Nozzle 4
This listing appeared on the previous site under a single generic product title with no specification text. The description below reports only what is visible in the factory photographs of this item. Model reference, thread size, spray pattern and flow data are confirmed by email before quotation.
A stainless steel flat fan spray nozzle delivers a consistent, even spray pattern across a moving surface, which is essential when a paper web, metal strip or conveyor must be uniformly wetted without dry spots or overspray. This CNSS model is built for durability in continuous industrial washing, rinsing or coating processes where corrosion resistance and mechanical stability are required.
No published specification table exists for this listing. Send the duty and the thread on your header and we will confirm the size, pattern and material by email.
Key Benefits
What This Nozzle Gives You
- Stainless steel construction resists corrosion and wear in continuous washing or rinsing duty
- Flat fan pattern ensures even coverage across a target width without dry stripes
- Threaded base allows direct mounting on existing pipework without adapters
- One nozzle design can replace multiple types when the process requires consistent spray geometry
- No internal parts to loosen or dislodge during operation
- Free trial samples available to verify performance before bulk purchase
Application Scenarios
Where It Is Installed
- Paper machine wet end where a uniform water curtain must be applied across the web width
- Steel mill rinsing line requiring consistent water coverage on a moving strip
- Parts washing system where a stable spray plane ensures complete surface wetting
- Surface treatment line needing a durable nozzle that resists chemical and mechanical stress
- Maintenance team replacing worn nozzles on a high-use washing bar without redesign
Who It Is For
Buyers Who Specify It
- Maintenance managers replacing nozzles in a paper machine or steel mill washing line
- Plant engineers specifying nozzles for a new or upgraded rinsing system
- OEM machine builders integrating a reliable spray nozzle into a production line
- Process engineers looking for a durable nozzle in a corrosive or high-temperature environment
- Procurement teams sourcing a consistent, long-life nozzle for high-volume operations
Problems It Solves
What It Fixes on the Line
- Dry stripes between nozzles on a spray bar due to misaligned or inconsistent spray patterns
- Corrosion of brass or plastic nozzles in continuous water or chemical service
- Frequent nozzle failure requiring line downtime and replacement
- Inconsistent spray width caused by worn or misaligned nozzles
- Need to use multiple nozzle types for different sections of a single line
Technical Features
How It Is Built
- One piece stainless steel body with no internal components to fail
- Flat fan spray pattern designed for edge-to-edge coverage on moving surfaces
- Threaded base for direct installation on standard piping
- Nozzle tip geometry optimized for consistent spray distribution
- Construction suitable for moderate pressure and continuous operation
- No internal filter or strainer unless specified in custom order
Materials
Body Materials and Where Each One Suits
- 303 stainless steel for general industrial washing and rinsing
- 316 stainless steel where chlorides or aggressive chemicals are present
- 304 stainless steel for moderate chemical and temperature duty
Manufacturing Process
How the Part Is Made
- Material selection based on the customer's process conditions
- Machining of the nozzle body and orifice
- Inspection of spray pattern and orifice integrity
- Packaging in protective material
- Transportation with handling controls to prevent damage
Quality Control
What Is Checked Before It Ships
- Raw material is restricted to selected brass, 303 stainless steel, 304 stainless steel and 316 stainless steel
- Every process from material selection to transportation is controlled
- Every product is tested before it ships
- A 3 month quality guarantee is stated on the product listing
Customization
What Can Be Changed to Suit You
- Standard and non-standard nozzles can be made to customer drawing
- OEM orders accepted including customer marking
- Small volume orders accepted for trial or replacement use
- Samples can be ready within 10 days
- Trial samples can be sent free of charge
Comparison
How It Compares With the Alternatives
| Hollow cone nozzle | A hollow cone produces a ring of droplets and is better for gas scrubbing or cooling, but it cannot deliver a continuous line of spray across a moving web or strip |
|---|---|
| Full cone nozzle | A full cone covers a circular area, making it suitable for tank filling or cooling towers, but it does not provide edge-to-edge coverage on a linear target |
| Plastic flat fan nozzle | Plastic nozzles are lighter and cheaper but less durable under high pressure or temperature; stainless steel is better for continuous industrial use |
| Spiral nozzle | A spiral nozzle handles solids better due to its external vane, but its conical spray pattern is not suitable for uniform linear coverage |
Use Guide
Fitting and Running It
- Confirm the target width and standoff distance before selecting a nozzle
- Ensure adjacent nozzles are aligned so their spray fans overlap evenly
- Match the thread standard to the existing header to avoid adapters
- Use 303 or 316 stainless steel where chemicals or chlorides are present
- Inspect the nozzle tip for wear if spray pattern becomes uneven
- Specify a filter or strainer if spraying recirculated or dirty water
Questions Buyers Ask
Stainless Steel Flat Fan Spray Nozzle 4 Questions
What materials are available for this stainless steel flat fan nozzle?
This nozzle is available in 303 stainless steel, 304 stainless steel, and 316 stainless steel. Choose based on the chemical and temperature conditions of your process.
Can I get a sample before placing a production order?
Yes. Trial samples can be sent free of charge and are ready within 10 days.
Do you accept OEM orders and custom drawings?
Yes. Standard and non-standard nozzles can be made to your drawing. OEM orders including customer marking are accepted.
What is the lead time for samples?
Samples can be ready within 10 days after order confirmation.
What is the quality guarantee for this nozzle?
A 3 month quality guarantee is stated on the product listing. If a nozzle fails in service, send a photo and details of the operating conditions for assessment.
What are your payment terms?
The product listing states T/T 100% in advance. Send the model, quantity, and destination port by email to receive a confirmed quote and payment terms.
Are thread sizes and spray angles available for this model?
Thread sizes and spray angles are confirmed against the customer's drawing or duty sheet. Dimensions and materials are not standardized and must be specified for each order.
