Stainless Steel Flat Fan Spray Nozzle 1
This listing appeared on the previous site under a single generic product title with no specification text. The description below reports only what is visible in the factory photographs of this item. Model reference, thread size, spray pattern and flow data are confirmed by email before quotation.
A stainless steel flat fan spray nozzle delivers a consistent, even spray pattern across a moving surface, which is essential when a paper web, metal strip or conveyor must be uniformly wetted without dry spots or overspray. This CNSS model is built for durable, long-term service in papermaking, washing lines and surface treatment applications where corrosion resistance and consistent flow are required.
No published specification table exists for this listing. Send the duty and the thread on your header and we will confirm the size, pattern and material by email.
Key Benefits
What This Nozzle Gives You
- Stainless steel construction resists corrosion in wet, chemical or high humidity environments
- Flat fan pattern ensures even coverage across a line or moving surface
- External thread connection allows direct fitting to standard piping without adapters
- One nozzle design supports multiple applications in paper processing and industrial washing
- No internal parts to loosen or wear separately, reducing maintenance and downtime
- Free trial samples available to verify performance before bulk ordering
Application Scenarios
Where It Is Installed
- Paper machine wet end where a uniform water layer must be applied across the web width
- Surface washing lines where a consistent spray is needed to remove residue from metal parts
- Conveyor belt rinsing in a manufacturing line where even coverage prevents dry spots
- Industrial cleaning systems requiring a durable nozzle that resists scaling and pitting
- Maintenance teams replacing nozzles in a high moisture or chemically aggressive environment
Who It Is For
Buyers Who Specify It
- Paper mill maintenance engineers replacing worn nozzles on forming or press sections
- Plant engineers specifying nozzles for a new surface treatment or washing line
- OEM machine builders integrating nozzles into a standard washing or coating unit
- Facility managers sourcing durable spray components for high humidity or corrosive duty
- Procurement managers looking for a reliable nozzle with proven material selection
Problems It Solves
What It Fixes on the Line
- Uneven wetting on a moving web or conveyor due to inconsistent spray pattern
- Nozzle corrosion or pitting in humid or chemically aggressive environments
- Frequent replacement caused by weak or non-durable materials
- Incompatibility with existing piping due to mismatched thread types
- Downtime from nozzle failure during critical production cycles
Technical Features
How It Is Built
- One piece stainless steel construction with no internal components to fail
- External thread connection designed for direct mounting on standard pipe fittings
- Flat fan spray pattern optimized for edge-to-edge coverage on moving surfaces
- No internal seals or gaskets that can degrade over time
- Nozzle body machined to maintain consistent orifice geometry
- Designed for use in papermaking, washing and surface treatment processes
Materials
Body Materials and Where Each One Suits
- 303 stainless steel for general industrial washing and rinsing duty
- 316 stainless steel for service in chloride-rich or chemically aggressive environments
- Brass is not used in this model; body is exclusively stainless steel
Manufacturing Process
How the Part Is Made
- Material selection based on the intended duty and environmental conditions
- Machining of the nozzle body and orifice to precise dimensions
- Inspection of the spray pattern and orifice integrity
- Final packaging and labeling before shipment
- Transportation under controlled conditions to prevent damage
Quality Control
What Is Checked Before It Ships
- Raw material is restricted to selected brass, 303 stainless steel, 304 stainless steel and 316 stainless steel
- Every stage from material selection to transportation is controlled
- Every product is tested before it ships
- A 3 month quality guarantee is stated on the product listing
Customization
What Can Be Changed to Suit You
- Standard and non-standard nozzles can be made to customer drawing
- OEM orders accepted including custom marking and packaging
- Small volume orders accepted for trial installations
- Samples can be ready within 10 days
- Trial samples can be sent free of charge
Comparison
How It Compares With the Alternatives
| Hollow cone nozzle | A hollow cone provides a ring pattern with finer droplets, better for gas scrubbing, but it cannot deliver a uniform line across a moving surface like a flat fan |
|---|---|
| Full cone nozzle | A full cone covers a circular area, suitable for tank filling or cooling, but not for even coverage along a strip or web |
| Plastic flat fan nozzle | Plastic nozzles are lighter and cheaper, but stainless steel offers better durability and resistance to high pressure and temperature |
| Brass flat fan nozzle | Brass is less resistant to corrosion in wet or chemical environments; stainless steel is preferred for long-term reliability |
Use Guide
Fitting and Running It
- Confirm the target width and standoff distance before selecting a nozzle
- Ensure the thread standard matches the existing piping to avoid adapter use
- Align all nozzles on the same plane to maintain even spray coverage
- Use in applications where consistent flow and corrosion resistance are required
- Inspect the orifice regularly for wear or blockage, especially in recirculated water systems
- Verify the material choice matches the chemical and thermal conditions of the process
Questions Buyers Ask
Stainless Steel Flat Fan Spray Nozzle 1 Questions
What material is this nozzle made from?
This stainless steel flat fan spray nozzle is made from 303 stainless steel or 316 stainless steel, depending on the application and environmental conditions.
Can I get a sample before placing a production order?
Yes. Trial samples can be sent free of charge and are available within 10 days.
Do you accept OEM orders and custom drawings?
Yes. Standard and non-standard nozzles can be made to your drawing under an OEM order.
What is the lead time for samples?
Samples can be ready within 10 days after the order is confirmed.
What is the quality guarantee for this nozzle?
A 3 month quality guarantee is stated on the product listing. If a nozzle fails in service, send us a photo and the operating conditions for assessment.
What are your payment terms?
The product listing states T/T 100% in advance. Send the model, quantity and destination port by email and we will confirm the terms.
Can I use this nozzle in a papermaking line?
Yes. This stainless steel flat fan spray nozzle is suitable for papermaking applications where consistent, even wetting of the web is required.
Go Deeper
Industries Guides and Ways to Order
Ask About Stainless Steel Flat Fan Spray Nozzle 1
Send the liquid, the pressure at the nozzle and the thread on your header. Trial samples can be sent free of charge and samples can be ready within 10 days.
