Large Mobile Truck Containerized Energy Storage And Charging

Name: Large Mobile Truck Containerized Energy Storage
Brand: ZP LITHIUM

Product Overview

Large Mobile Truck Containerized Energy Storage

A containerised battery on a trailer, so the storage goes to the load instead of the load coming to a fixed substation. Three builds cover 1380 kWh, 860 kWh and 250 kWh, each with integrated DC charging guns rated 160 kW to 320 kW, card, code scanning and app payment built in. Used for mobile power demand, events, construction and charging surge cover.

Key Benefits

Trailer-mounted, so the same asset serves several sites in a year
Integrated charging piles with four guns on the 1380 kWh build and two on the 860 kWh build
Dual-gun parallel charging supported
Payment by swipe card, code scanning and app already integrated

Large Mobile Truck Containerized Energy Storage manufactured by ZP LITHIUM in Wuxi — 250 kWh to 1380 kWh trailer-mounted storage with integrated DC fast charging guns.

Who It Is For

Buyers Who Specify This System

Charging network operators covering demand peaks without a new grid connection
Event, film and construction contractors running on diesel generators today
Government and emergency agencies holding standby power capacity
Industrial parks and factories that need temporary power at a changing location

Problems It Solves

What Usually Goes Wrong Without It

A fixed substation upgrade takes longer than the project it is meant to serve
Diesel generators run loud, dirty and expensive for loads that only peak a few hours a day
Charging demand moves between sites faster than infrastructure can be built
Payment and access control are usually bolted on afterwards instead of built in

Technical Features

How The System Is Built

Every figure below is taken from the product specification we quote from. Where a value depends on the configuration, all configurations are listed.

Battery cluster voltage of 691.2 V or 614.4 V depending on build
DC output power of 320 kW across four guns at 160 kW each
AC input 380 V plus or minus 10%, three phase
Charging gun cable length of 8 m on the large builds and 5 m on the 250 kWh build

System parameter	1380 kWh / 860 kWh / 250 kWh
Size (LWH)	6058x2438x2791 mm / 6058x2438x2896 mm / 4200x2100x2100 mm
Installed power	1382.4 kWh / 860 kWh / 258 kWh
Rated voltage of battery cluster	691.2 V / 614.4 V / 614.4 V
Battery cluster number	4 / 5
Rated capacity of battery cluster	500 Ah / 280 Ah
System working voltage range	626.4-788.4 V / 537.6-691.2 V
DC output power	320 kW, four guns x 160 kW
AC input power	0-600 adjustable
DC maximum input power	180 kW single gun
Parallel charging	Supported
Product weight	16.3 T / 8.5 T
Rated charging power	320 kW single gun 160 kW / 160 kW single gun 160 kW / 160 kW
Number of charging piles	2 sets of AC/DC integrated double-gun pile
Number of charging guns	4 / 2
DC input voltage range	500-800 V / 600-800 V
AC input voltage	380 V plus or minus 10%, three phase
DC output voltage	150-800 V constant power 400-800 / 200-750 V
Maximum output current of charging gun	250 A / 213 A
Dual-gun parallel charging	Supported
Payment method	Swipe card, code scanning, app
Length of gun line	8 m / 5 m

Process

From Your Requirement To A Shipped System

The four stages every order of this product passes through.

Demand and duty study

Peak kW, daily kWh and how often the unit moves decide which build fits.

Charging interface specification

Gun count, connector standard and payment method are set for the destination market.

Container and trailer integration

Clusters, charging piles and the trailer are integrated and tested as one unit.

Handover and training

The operator is trained on move, connect and payment reconciliation.

Quality Materials And Certification

What We Can Evidence And What We Cannot

Cell Chemistry

Lithium iron phosphate (LiFePO4). We have 20 years of experience producing iron lithium battery cells and hold 452 technology patents in LiFePO4 batteries.

Certification

MSDS and UN38.3 are held as the basis of any certificate. Further market certificates are applied for according to each market policy requirement, so tell us the destination country at quotation stage.

Warranty And Recycling

Two years warranty on lithium battery products. We hold national qualification for lithium battery recycling and are one of four nationally licensed cell recycling enterprises in China.

Large Mobile Truck Containerized Energy Storage - Production and assembly of this system at the Wuxi plant. — Production and assembly of this system at the Wuxi plant.

Large Mobile Truck Containerized Energy Storage - Finished units staged for testing before shipment. — Finished units staged for testing before shipment.

Large Mobile Truck Containerized Energy Storage - The workshop line where this product is built. — The workshop line where this product is built.

Customisation

What Can Be Changed

The model can be customised according to the specific needs of the market. In practice that means voltage window, capacity, enclosure dimensions, connector and charging standard, communication protocol and branding.

We private label your brand, and products can be customised for you. Sole agency is available depending on your project plan, market plan and operation.

Use Guide

Before The First Order

Send four things and we can configure without a second round of questions: the application and duty cycle, the energy required per day or per charge, the voltage window your system expects, and the destination market.

Minimum order quantity normally starts from one 40 HC container. Delivery is within 60 days on a first order and 30 days from the second. Payment is TT or LC at sight depending on the market.
