Track Geometry Measurement Systems
Track geometry measurement system designed for precise assessment of rail alignment, gauge, level, and profile during routine inspections and maintenance windows. Built for integration into dual-rail and hi-rail vehicles, or used as a standalone platform for manual or trolley-based measurement.
Equipment in This Category
RAILWAY PLATFORM GAUGE
The Railway Platform Gauge is a portable measuring tool designed for precise measurement of the horizontal distance...
View Product →
Track Geometry Measurement
The GJY-H-CK-22CM Track Geometry Measurement system is integrated into an electric flaw detection vehicle and runs at a...
View Product →Problems This Equipment Solves
- Track geometry deviations cause ride quality issues, increase wear, and can lead to derailments if uncorrected
- Manual measurement with tape and level tools is slow, inconsistent, and cannot cover long distances efficiently
- Lack of digital data recording makes trend analysis and compliance reporting difficult
- Measurement during daylight hours limits inspection windows on busy lines
- Inconsistent data formats between inspection teams hinder centralized monitoring
Who This Category Is For
Railway bureaus conducting scheduled track maintenance and condition assessment
Urban metro operators requiring frequent geometry checks during limited night windows
Private and industrial railways with high-frequency operations and tight maintenance schedules
Port and mine operators managing heavy haul track with high wear and alignment sensitivity
Rail maintenance contractors responsible for multiple lines with standardized reporting needs
Core Advantages
- Digital track geometry data is recorded continuously during inspection runs
- Measurement data can be exported and analyzed for trend tracking and compliance reporting
- Compatible with dual-rail and hi-rail vehicles for use at operating speeds
- Supports both automated and manual operation depending on the vehicle platform
- Enables repeatable, objective measurements across different crews and locations
Where It Is Used
- Routine track geometry inspection on main line railways during scheduled possession windows
- Preventive maintenance on urban metro lines with high passenger volume and tight tolerances
- Periodic assessment of industrial railway track subject to heavy axle loads and frequent use
- Verification of track geometry after rail replacement, grinding, or realignment work
- Data collection for long-term track condition monitoring and asset management planning
Related Cases and Industries
UR18-D Pass the review of standard measurement technology
UR18-D became the first enterprise in China to obtain certification for special railway measuring instruments in ultrasonic rail t
Dual Rail Ultrasonic Flaw Detection Vehicle Enters African Market
First use of the UR18-D dual-rail ultrasonic flaw detection vehicle on the Mombasa-Nairobi Railway in September 2017 Successful in
State Owned Railways
State-owned main line railways require reliable, repeatable ultrasonic rail flaw detection to identify internal defects such as tr
Urban Metro and City Rail
Urban metro and city rail systems operate under strict night maintenance windows, where track inspection must be fast, reliable, a
Frequently Asked Questions
What track geometry parameters does it measure?
It measures gauge, alignment, level, profile, twist, and curvature, with data recorded continuously during operation.
Can it be used on both main line and industrial track?
Yes. The system is designed for use on standard gauge and narrow gauge tracks, including those in industrial, port, and mining environments.
How is the data recorded and accessed?
Data is recorded digitally during the inspection run and can be transferred to a computer for analysis, reporting, and long-term storage.
Is it compatible with existing detection vehicles?
Yes. It is designed to integrate with dual-rail and hi-rail vehicles, as well as hand push trolleys, depending on the configuration.
Can it be used at night?
Yes. The system includes lighting and display features suitable for night operation, and data recording is unaffected by lighting conditions.
Do you provide technical support for setup and use?
Yes. We provide pre-sales, in-sales, and after-sales technical service, on-site engineer training, and construction team support.
How do I get a quotation?
Email [email protected] with your rail profile, line type, and annual inspection volume, and our engineers will provide a configuration and pricing.
Ask an Engineer About Track Geometry Measurement Systems
Tell us the line type, rail profile and possession window you work with and we will recommend the right model from this category.
