Frontlit LED Channel Letters
Aluminum return and back, no rim, inner LED lights, acrylic face
Frontlit, backlit, sidelit, edgelit or resin-faced: the choice changes the look far more than the price does.
Metal return and back, LEDs inside, acrylic face. The whole letter glows. Returns run typically 60mm to 100mm deep — the slimmer end suits thin and slim fonts. Returns are built in painted aluminum or brushed stainless depending on the build.
A solid metal face over a frosted acrylic back, pinned off the wall so the light washes the surface behind. By day it reads as plain metal. Halo builds in the catalogue use a 30mm thick frosted acrylic back.
Sidelit and edgelit builds put the light out through the acrylic edge — a thin line of color rather than a lit face. Resin-faced letters take a stainless side and back with a resin front, and go down to a 25mm minimum depth, which is the slimmest lit build listed.
Every illuminated build ships with a 12V DC CE and RoHS approved transformer, a 1:1 scale mounting template and the screw pins or bolts for that fixing method.
Pictured: Halo Illumination LED Aluminum Sign Lettering
1:1 scale mounting template · screw bolts or pins · 12V DC CE and RoHS approved transformer on illuminated builds · DHL or UPS door to door · no minimum order.
Aluminum return and back, no rim, inner LED lights, acrylic face
Stainless steel front and inner LED lights and 30mm thick frosted acrylic back
Brushed stainless steel face and 30mm thick white frosted acrylic back and inner LED lights
Metal front and 30mm thick white acrylic back and inner LED lights
Frontlit, comfortably. If the sign must be legible across a car park at night, that is the build. Halo is about atmosphere at close and medium range, not distance legibility.
A 12V DC CE and RoHS approved transformer, included with every illuminated build along with the 1:1 mounting template and fixings.
The resin-faced build is listed with a 25mm minimum depth, the slimmest lit option in the catalogue. Standard frontlit returns run typically 60mm to 100mm.
Send the artwork and the site details and we will specify the build before quoting it.
