Resin LED Letters
Stainless steel side and back, inner LED lights, resin front face
Sidelit LED Letters start as your vector artwork and leave the bench as finished, ready-to-mount signage. Material: brushed stainless steel face and 30mm thick white frosted acrylic back and inner LED lights. Fabrication: cNC router cutting for acrylic. Finish: painted metal face and lights pass through the side of 30mm thick frosted acrylic. The light escapes through the acrylic edge, giving a thin line of color around the letter return.
Size and font: any size and font. 20mm and 30mm thick available. On site they fix by back screw pins. Every order ships with 1:1 scale mounting template and screw pins, 12V DC CE and RoHS approved transformer. The build is specified for outdoor use.
Share the logo file and the site conditions, and we will confirm build, finish and fixing before anything is cut.
Taken from the factory catalogue record for this build. Where a value is not listed here, it was not recorded — ask and we will confirm it in writing.
| Material | Brushed stainless steel face and 30mm thick white frosted acrylic back and inner LED lights |
|---|---|
| Fabrication | CNC router cutting for acrylic |
| Finish | Painted metal face and lights pass through the side of 30mm thick frosted acrylic |
| Size & font | Any size and font. 20mm and 30mm thick available |
| Fixing method | Back screw pins |
| Supplied with | 1:1 scale mounting template and screw pins, 12V DC CE and RoHS approved transformer |
| Suitable for | Outside use |
| Minimum order | No MOQ — any quantity accepted |
| Shipping service | DHL or UPS express door to door delivery service available |
| Lead time | Normal 5–7 days on producing and 4 days by DHL or UPS express |
Send a vector file (AI, EPS, PDF or DXF), the finished height of the tallest letter and the wall it is going on. Quotations include the 1:1 mounting template and fixings, and the 12V DC CE and RoHS approved transformer.
Payment by T/T, PayPal or Western Union. No minimum order.
This item is listed at 20, 30 mm. If your drawing calls for something outside that range, send it over and we will confirm what the process allows.
Back screw pins. A 1:1 scale mounting template goes in the box, so the installer drills from the template rather than measuring letter by letter.
No. The source terms state no MOQ — single letters and one-off logo signs are accepted alongside multi-site rollouts.
Normal 5–7 days on producing and 4 days by DHL or UPS express.
Stainless steel side and back, inner LED lights, resin front face
Metal profile and inner LED lights, double-sided acrylic
Metal front and 30mm thick white acrylic back and inner LED lights
Aluminum return and back, no rim, inner LED lights, acrylic face
Artwork in, specification and price back. Production is typically 5–7 days, then about 4 days door to door by express.
