HP Misting Nozzle
MFD High Pressure Anti Drip Misting Nozzle
A high pressure misting nozzle delivers a fine, uniform fog without dripping, which is essential when maintaining consistent humidity in a textile workshop, cooling livestock in a poultry house, or preventing dust in a farm environment. This MFD series nozzle uses internal guide vanes and anti-drip equipment to produce a stable mist under pressure, ensuring no residual liquid forms after shutdown. It operates in the 20 to 70 KG/m² (290 to 1015 PSI) range, forming a centrifugal vortex that breaks liquid into droplets between 3 and 70 microns.
| Operating Pressure | 20 to 70 KG/m² (290 to 1015 PSI) |
|---|---|
| Droplet Size | 3 to 70 microns |
| Inlet Size | 10/24, 12/24, 3/16, 1/8 |
| Feature | Anti-drip, no air supply required, non-blocking |
Dimensions and materials outside this table are confirmed against your duty sheet before quotation.
Key Benefits
What This Nozzle Gives You
- Anti-drip design prevents liquid from forming after system shutdown
- Guide vanes create a stable centrifugal vortex for consistent fine droplet formation
- No external air supply required, simplifying system design
- Droplet size between 3 and 70 microns ensures even coverage and rapid evaporation
- Wear-resistant tip extends service life to 2.5 times that of similar nozzles
- Low water and energy consumption with effective performance across multiple applications
Application Scenarios
Where It Is Installed
- Textile workshops where consistent humidity prevents fiber breakage and static
- Poultry houses requiring dust control and cooling during high ambient temperatures
- Artificial fog systems for visual effects in entertainment or landscaping
- Vegetable storage areas where moisture retention maintains freshness
- Stock farms needing disinfection and cooling without wetting surfaces
Who It Is For
Buyers Who Specify It
- Maintenance engineers managing misting systems in agricultural or industrial facilities
- Facility managers installing or upgrading cooling and humidification systems
- OEMs building fog systems for greenhouses, livestock housing, or entertainment venues
- Contractors specifying nozzles for outdoor cooling or dust suppression projects
- Procurement managers sourcing reliable, low-maintenance misting components
Problems It Solves
What It Fixes on the Line
- Dripping after system shutdown that causes water marks or surface wetting
- Inconsistent fog patterns due to poor droplet formation or clogging
- High maintenance from frequent nozzle replacement in abrasive or corrosive environments
- System complexity from needing compressed air for atomization
- Uneven humidity or cooling due to variable droplet size or spray distribution
Technical Features
How It Is Built
- Guide vanes inside the body create a centrifugal vortex for fine droplet formation
- Anti-drip equipment prevents residual liquid from forming after pressure release
- No external air supply needed, reducing system complexity and cost
- Wear-resistant tip designed for extended service life under high pressure
- Internal flow path minimizes blockage risk with clean liquid input
- Compact design allows integration into tight spaces or dense nozzle arrays
Materials
Body Materials and Where Each One Suits
- Brass for general water service in low to moderate pressure systems
- Stainless steel for corrosion resistance in humid, chemical, or outdoor environments
Manufacturing Process
How the Part Is Made
- Material selection based on the operating environment and liquid type
- Machining of the body and internal guide vanes
- Inspection of orifice and flow path for consistency
- Assembly of anti-drip components and tip fitting
- Testing under pressure to verify anti-drip and spray pattern
- Packaging and shipping with protection against impact and moisture
Quality Control
What Is Checked Before It Ships
- Raw material is selected from brass, 303 stainless steel, 304 stainless steel, and 316 stainless steel
- Every process from material selection to transportation is controlled
- Every product is tested before it ships
- A 3 month quality guarantee is stated on the product listing
Customization
What Can Be Changed to Suit You
- Standard and non-standard nozzles can be made to customer drawing
- OEM orders accepted including customer marking and packaging
- Small volume orders accepted for trial installations
- Samples can be ready within 10 days
- Trial samples can be sent free of charge
Comparison
How It Compares With the Alternatives
| Air atomizing nozzle | An air atomizing nozzle requires compressed air and is more complex, while this MFD nozzle operates on liquid pressure alone |
|---|---|
| Low pressure misting nozzle | Low pressure nozzles produce larger droplets and are less effective for cooling or fog effects, while this high pressure version creates finer, evaporative mist |
| Full cone nozzle | A full cone covers a circular area, suitable for tank filling, but does not provide the directional, even fog coverage this nozzle delivers |
| Standard high pressure nozzle | This MFD model includes anti-drip equipment and guide vanes, reducing maintenance and improving reliability compared to standard high pressure designs |
Use Guide
Fitting and Running It
- Confirm inlet size and pressure range match your system before selecting a nozzle
- Ensure liquid is filtered to prevent clogging, especially in recirculated systems
- Install nozzles with the tip facing the target to maintain consistent spray pattern
- Check for dripping after system shutdown; if present, verify anti-drip function is intact
- Inspect the wear-resistant tip periodically, especially in high use or abrasive conditions
- Align nozzles in arrays to avoid overlapping or dead zones in fog coverage
Questions Buyers Ask
MFD High Pressure Anti Drip Misting Nozzle Questions
What pressure range does this nozzle operate under?
The MFD high pressure anti drip misting nozzle operates under 20 to 70 KG/m² (290 to 1015 PSI). Confirm your system pressure matches this range before installation.
Which materials are available for this nozzle?
Choose based on the environment and liquid type.
Can I get a sample before placing a production order?
Yes. Trial samples of the MFD high pressure anti drip misting nozzle can be sent free of charge and are ready within 10 days.
Do you accept small volume orders and OEM customization?
Yes. Small volume orders are accepted, and standard or non-standard versions of the MFD high pressure anti drip misting nozzle can be made to your drawing under an OEM order.
What happens if the nozzle fails in service?
A 3 month quality guarantee is provided. Send the nozzle photo and service conditions by email, and we will assess the failure mode.
What are your payment terms?
The product listing states T/T 100% in advance. Send the model, quantity, and destination port by email to confirm the terms for your order.
What inlet sizes are available?
The MFD high pressure anti drip misting nozzle is available in 10/24, 12/24, 3/16, and 1/8 inlet sizes. Confirm your system’s fitting standard before ordering.
