Air Atomizing Nozzle
Air Atomizing Nozzle Made in China
An air atomizing nozzle breaks liquid into fine droplets using compressed air, which is required for consistent misting in processes like humidification, cooling, dust suppression, or surface treatment. This CNSS air atomizing nozzle uses internal mixing to create a fine spray with droplets around 30 microns, suitable for applications where low liquid pressure and high air pressure are available. The nozzle can be adjusted to vary flow rate while maintaining spray pattern, and it operates across pressure, siphon, and gravity types depending on the system setup.
No published specification table exists for this listing. Send the duty and the thread on your header and we will confirm the size, pattern and material by email.
Key Benefits
What This Nozzle Gives You
- Internal mixing design produces fine droplets around 30 microns for effective humidification and cooling
- Adjustable liquid flow rate allows spray pattern control without changing air or liquid pressure
- Operates under pressure, siphon, or gravity types to suit different system configurations
- Spray distance reaches up to 3 meters, reducing the need for high-pressure lines and pumps
- Two inlets clearly marked as LIQUID and AIR to prevent incorrect installation
- Available in flat fan, round, and wide-angle round spray patterns for different coverage needs
Application Scenarios
Where It Is Installed
- Humidification in high-temperature wax, cement, or ceramic factories where fine mist is needed without wetting surfaces
- Cooling of hot surfaces or materials in metallurgical or injection molding plants using low-liquid-pressure systems
- Dust suppression in dry material handling lines where a fine, long-range mist is required
- Disinfection or surface treatment in industrial workshops using low liquid pressure and compressed air
- Misting systems in large spaces where long spray reach and low maintenance are priorities
Who It Is For
Buyers Who Specify It
- Maintenance engineers replacing worn nozzles in existing air-assisted misting systems
- Process engineers designing low-pressure humidification or cooling systems for high-temperature environments
- OEM machine builders integrating nozzles into equipment with limited liquid pressure
- Facility managers seeking long-life, low-maintenance misting solutions for large industrial spaces
- Installers of dust control or disinfection systems needing reliable, adjustable nozzles
Problems It Solves
What It Fixes on the Line
- High liquid pressure requirements that increase pump cost and system complexity
- Short spray reach that forces close nozzle placement and increases clogging risk
- Nozzle failure due to incorrect inlet connection or improper mixing type selection
- Lack of adjustability in flow rate when system pressure remains fixed
Technical Features
How It Is Built
- Inner mixed type design for fine droplet formation under various operating conditions
- External mixed type available for higher viscosity liquids when needed
- Adjustable liquid flow rate without changing air or liquid pressure
- Two clearly marked inlets: LIQUID and AIR, with labels L and A for easy identification
- Spray patterns include flat fan, round, and wide-angle round to match target coverage
- Can operate in pressure, siphon, or gravity atomizing modes depending on system design
Materials
Body Materials and Where Each One Suits
- Stainless steel body for use in humid, corrosive, or high-temperature environments
- Knurled cap and hex body for secure hand adjustment and installation
- Air cap and liquid cap design allows for modular maintenance and cleaning
Manufacturing Process
How the Part Is Made
- Material selection based on the operating environment and liquid type
- Machining of internal mixing chamber and inlet ports
- Assembly of air cap and liquid cap with alignment of inlets
- Inspection of inlet markings and flow path integrity
- Testing of spray pattern and adjustment range before packaging
- Packaging and shipment with protection against damage during transit
Quality Control
What Is Checked Before It Ships
- Raw material is selected from brass, 303 stainless steel, 304 stainless steel, and 316 stainless steel
- Every process from material selection to transportation is controlled
- Every product is tested before it ships
- A 3 month quality guarantee is stated on the product listing
Customization
What Can Be Changed to Suit You
- Standard and non-standard nozzles can be made to customer drawings
- OEM orders accepted including custom marking and packaging
- Adjustable flow rate design allows for field tuning to match process needs
- Small volume orders accepted for trial installations
- Samples can be ready within 10 days
- Trial samples can be sent free of charge
Comparison
How It Compares With the Alternatives
| High pressure fog nozzle | High pressure nozzles require expensive pumps and piping, while this air atomizing nozzle uses compressed air and operates at lower liquid pressure, reducing system cost and maintenance |
|---|---|
| Pressure atomizing nozzle | Pressure atomizing nozzles need high liquid pressure to break the stream, but this air atomizing nozzle uses air to atomize, making it suitable for low-pressure liquid systems |
| Siphon type nozzle | Siphon type relies on liquid suction, which limits flow control; this adjustable air atomizing nozzle allows direct flow rate adjustment without changing pressure |
| Gravity type nozzle | Gravity type depends on head height and is limited in reach; this nozzle achieves 3 meter spray distance using air pressure, enabling longer coverage |
Use Guide
Fitting and Running It
- Confirm whether your system uses pressure, siphon, or gravity atomizing mode before selecting the nozzle type
- Ensure compressed air is available at the required pressure to achieve fine droplet formation
- Check that the liquid inlet is connected to the LIQUID or L port and air to AIR or A
- Adjust the liquid flow rate using the knurled cap to match the required mist density
- Align the nozzle so the spray pattern covers the target area evenly, especially for flat fan or wide-angle rounds
- Inspect the air cap and liquid cap regularly for clogging, especially when using dirty or viscous liquids
Questions Buyers Ask
Air Atomizing Nozzle Made in China Questions
What droplet size can this air atomizing nozzle achieve?
The nozzle can produce droplets around 30 microns when air pressure is increased or liquid pressure is reduced, depending on the system setup.
Can I adjust the flow rate after installation?
Yes. The adjustable air atomizing nozzle allows flow rate variation through the knurled cap without changing air or liquid pressure.
Which types of atomizing modes are supported?
The nozzle supports pressure, siphon, and gravity atomizing modes, depending on the system configuration and liquid delivery method.
What spray patterns are available?
Available spray patterns include flat fan, round, and wide-angle round, suitable for different coverage requirements.
Can I get a sample before placing a production order?
Yes. Trial samples can be sent free of charge and are available within 10 days.
Do you accept OEM orders and custom drawings?
Yes. Standard and non-standard nozzles can be made to your drawing, and OEM orders with custom marking are accepted.
What are your payment terms?
The product listing states T/T 100% in advance. Send the model, quantity, and destination port by email to confirm the terms.
