30W 3900lm LED Track Light
The GD885H is a 30W LED track light with built-in driver, designed for commercial interiors requiring high lumen output and consistent colour rendering. It operates on 220-240VAC, delivers 3900 lumens at 130lm/w efficiency with CRI above 90, and uses a Bridgelux LED chip. The beam angle is selectable at order as 15, 30, 45 or 60 degrees. It is compatible with European standard track systems and supports optional dimming. The die-cast aluminium housing provides stable thermal performance and mechanical strength. The adapter is configured for 3-phase 4-wire track systems.
Ask for the IES file or a Dialux calculation with your enquiry.
What This Fixture Does For You
- 130lm/w efficiency at 30W means higher output than lower-efficacy fixtures for the same power draw
- 3900 lumens from 30W allows fewer heads per bay in retail and showroom layouts
- CRI above 90 maintains accurate colour for merchandise, skin tones and materials under the beam
- Bridgelux LED chip ensures consistent lumen output and long-term stability
- 3-phase 4-wire adapter enables use on multi-circuit track systems already installed
- Optional dimming is declared at order, so the fixture is ready for integration with control systems
- Die-cast aluminium housing provides structural rigidity and effective heat dissipation
| Model | GD885H |
|---|---|
| Input Voltage | 220-240VAC |
| Frequency | 50Hz / 60Hz |
| System Power | 30W |
| Power Factor | >0.95 |
| Driver Brand | Lifud, Osram, Philips |
| Output | DC30-40V 750mA |
| LED Chip Brand | Bridgelux |
| Efficiency of Fixture | 130lm/w @ Ra90 |
| CRI | >90 |
| System Lumen | 3900lms |
| Colour Temperature | 2700K, 3000K, 3500K, 4000K, 5000K, 6000K |
| Beam Angle | 15°, 30°, 45°, 60° |
| Housing Material | Die-cast aluminium |
| Adapter | 3-phase 4-wires |
| Dimming | Optional, declared at order |
| Function | Dimmable optional |
| Dimension | Ø94x190mm |
Buyers And Applications
Who Buys It
- Lighting importers sourcing high-efficiency track lights for European and global markets
- Electrical wholesalers needing 3-phase 4-wire compatibility in a single fixture family
- Lighting designers specifying beam angle and dimming type per layout zone
- Shopfitting contractors replacing halogen or low-efficiency LED spots on tight schedules
- Hospitality and FF&E buyers requiring fixtures with consistent colour and high output
Where It Is Used
- Retail stores and showrooms where consistent colour rendering is needed for clothing and accessories
- Supermarkets and boutique spaces requiring high lumen output from a compact fixture
- Hotel lobbies and reception areas with multi-circuit track systems needing reliable, dimmable heads
- Villas and private galleries where beam angle flexibility supports accent lighting on art and architecture
- Commercial spaces with existing European standard track rails that require direct replacement
What Goes Wrong Without It
- Low-efficiency track lights that draw more power for the same visual brightness
- Fixtures with CRI below 90 that make reds, browns and skin tones appear dull or inaccurate
- Non-dimmable fixtures that cannot be integrated into modern lighting control systems
- Incompatible adapters that prevent use on existing 3-phase 4-wire track rails
- Poor thermal management in plastic housings that causes lumen depreciation over time
How It Is Built
- Built-in driver with DC30-40V 750mA output for stable performance
- Bridgelux LED chip with CRI above 90 for accurate colour rendering
- 130lm/w efficiency at 30W, delivering 3900 lumens
- Beam angle selectable at order: 15°, 30°, 45°, 60°
- 3-phase 4-wire adapter for compatibility with European standard track systems
- Optional dimming declared at order, not field-retrofittable
- Die-cast aluminium housing for heat dissipation and mechanical durability
Materials
- Die-cast aluminium housing and structural base
- Polycarbonate and aluminium reflector assembly
- Powder coated finish applied in our own coating plant
Certifications
- CE
- RoHS
- CCC
- CQC
- ISO 9001:2015 quality system
How It Is Made And Checked
Manufacturing Process
- Die-cast aluminium housing produced and machined to GD885H profile
- Powder coating applied in house to ensure consistent finish colour across batches
- Bridgelux LED chip mounted and thermally bonded to the die-cast housing
- Driver (Lifud, Osram or Philips) wired and secured inside the fixture
- Optical assembly and beam angle lens fitted per order
- 3-phase 4-wire adapter installed based on order specification
- Final inspection and aging test on one of two automatic aging lines
Quality Control
- Incoming inspection of LED chips, drivers and die-cast housings before assembly
- Photometric testing to verify lumen output and colour temperature
- Temperature testing on the assembled fixture under load
- Aging test on one of two automatic aging lines
- Reliability testing before batch release
- 100% inspection of every fixture before shipment
What We Can Change For You
- Beam angle selected from 15°, 30°, 45° or 60° at order
- Colour temperature selected from 2700K to 6000K
- Driver brand selected from Lifud, Osram or Philips at order
- Dimming version (Triac or DALI) declared at order
- Housing colour changed in our own powder coating plant
- 3D drawing provided within 2 days and mock-up sample within 3 days for OEM designs
How It Compares With The Alternatives
| 30W halogen track spotlight | Delivers 3900 lumens at 130lm/w, uses less than half the power for similar visual output |
|---|---|
| 30W LED track light with 90lm/w efficiency | Higher lumen output and better energy use, but requires a higher initial fixture cost |
| 20W zoomable track light | Higher fixed output than zoomable models, but beam angle is not adjustable on site |
| Recessed downlight | Surface-mounted and re-aimable, better for changing layouts, but more visible than flush ceiling fixtures |
Before You Order And Before You Install
- Confirm the installed track is 3-phase 4-wire before ordering the adapter
- Use 15° or 30° for accent lighting on merchandise and 45° or 60° for general wash
- Mount the fixture on a track with a minimum clearance of 100mm between heads
- Specify dimming type (Triac or DALI) at order, as it cannot be changed after production
- Group heads on the same circuit if you plan to dim them together
- Request IES files and Dialux calculations before finalising head count and spacing
Where This Fixture Is Specified
Other Fixtures For The Same Ceiling
2 Wire 30W LED Track Light
20W LED Track Light Built-In Driver
4 Wire 40W LED Track Light
4 Wire 10W LED Track Light
Read Before You Specify
What CRI Means For Retail And Hospitality Lighting
CRI is the number that decides whether merchandise looks like the catalogue. Here is what to specify and why the difference between 80 and 90 is visible.
How To Read An IES File And A Dialux Report
The two documents that turn a lighting proposal from an opinion into a calculation, and what to look for in each.
Frequently Asked Questions
What beam angles are available for this track light?
15°, 30°, 45° and 60°. The beam angle is fixed at production, so specify the mix per container when placing the order.
Is it compatible with my existing track system?
The adapter is designed for 3-phase 4-wire European standard track systems. Send a photo of the track end and adapter for confirmation before production.
Is dimming available?
Yes, dimming is optional and must be declared at order. The standard version is not dimmable.
What CRI and lumen output can I expect?
CRI above 90 with 3900 system lumens at 30W, which is 130 lumens per watt at fixture level.
Which driver brands are used?
Lifud, Osram or Philips drivers are used. The brand is selected at order.
Can you supply photometric files?
Yes, we supply IES files and can run Dialux calculations for your layout.
Can you make an OEM version with a different housing colour?
Yes. We have an in-house powder coating plant, so housing colour changes are done in-house. We can provide a 3D drawing in 2 days and a mock-up sample in 3 days.
Request A Quote On The 30W 3900lm LED Track Light
Send the quantity, colour temperature and beam angle. If you are matching an existing installation, send a photo of the rail end or the ceiling aperture with the enquiry.
