XLD Single Panel One Sided Walk Through Metal Detector
A single-panel gate takes half the width of a conventional archway, which is what makes it fit doorways and corridors that cannot accept a full frame. It uses an infrared sensor with mechanical interference rejection, sensitivity adjustable anywhere from 0 to 255, and a display panel showing the alarm area and exact location of the detected item.
Key benefits
- Single panel design fits doorways too narrow for a full archway
- Sensitivity adjustable from 0 to 255 per area
- Display shows alarm area and exact location of the detected item
- Password protection stops unauthorised parameter changes
- Alarm time 0 to 25 s, volume 0 to 255 and tone 1 to 10 all adjustable
Problems it solves
- A full archway will not fit an existing doorway
- Staff change gate settings without authority
- Operators cannot tell where on the body the alarm came from
- One fixed alarm volume and tone does not suit every venue
Who it is for
- Sites with entrances too narrow for a two-panel gate
- Operators needing statistics on passage and alarm counts
- Facilities where unauthorised setting changes have been a problem
Application scenarios
- Hotels and building entrances
- Railway, bus and subway stations
- Stadiums and exhibition halls
- Schools and other sites with narrow entrances
Technical features
- Infrared sensor with mechanical interference rejection
- Imported synthetic panel material, moisture and fire resistant
- Thin film operation panel with high brightness display
- Intelligent statistics on people counted and alarm times
- Designed for easy installation and removal
Specifications
| Configuration | Single panel, one sided |
|---|---|
| Sensitivity Range | 0 to 255, adjustable per area |
| Alarm Time | 0 to 25 seconds, adjustable |
| Alarm Volume | 0 to 255, adjustable |
| Alarm Tone | 1 to 10 |
| Panel Material | Imported synthetic, moisture and fire resistant |
| Sensing | Infrared sensor with mechanical interference rejection |
| Access Control | Password protected parameters |
| Statistics | People counted and alarm times |
Figures are those published by the factory for this model. Where a value is shown as TBC it is not published, and we will confirm it with the factory before you order rather than estimate it.
Customisation options
- Sensitivity set from 0 to 255 according to the user's requirement
Compared with other models in the range
A two-panel archway such as the VIBOO-24D gives more zones and fuller body coverage. This single-panel gate is what to specify when the entrance physically will not take a full archway, and it still gives location indication and 0 to 255 sensitivity control.
Use guide
- Mount the single panel beside the doorway where a full archway will not fit
- Set sensitivity on the 0 to 255 scale for the items being screened
- Set alarm time, volume and tone to suit the venue
- Assign a password so only authorised staff can change parameters
- Review the passage and alarm statistics at shift end
Product images
Where this product is used
Part of Metal Detectors for Schools ยท typically specified for:
XLD Single Panel One Sided Walk Through Metal Detector FAQ
Why choose a single panel gate
It takes half the width of a conventional archway, so it fits doorways and corridors that cannot accept a full frame.
How fine is the sensitivity adjustment
0 to 255, adjustable by area.
Can the alarm be adjusted
Alarm time from 0 to 25 seconds, volume from 0 to 255 and tone from 1 to 10.
Can staff change the settings
Parameters are password protected so only authorised personnel can change them.
Is it safe for people with pacemakers
The source specification states it is harmless to the human body, including heart pacemakers, pregnant women and magnetic media. Confirm your local requirement with us.
Is it difficult to install
The XLD series is designed for ease of installation and removal.
Does it count how many people passed
Yes, it keeps statistics on the number of people and alarm times.
